ENT CABINETS
ENT CHAIRS
• 27545 OTO/PV ENT CHAIR with head support - colour on request
• 27546 OTO/PV ENT CHAIR with head support - green Marbella
• 27547 OTO/PV ENT CHAIR with head support - sky blue Parigi
Patient chair with Peltex-lined seat and backrest.
Electric up and down movements by silent engine controlled
through foot switch.
Back-rest can be adjusted up to 180° by a gas spring. Chair rotates
360° and is provided with a rotation locking device placed at the
bottom. Power: 230 V - 50 Hz (Available 110 V - 60 Hz). Made in Italy.
• 27550 OTOPEX ENT CHAIR with head support - colour on request
• 27551 OTOPEX ENT CHAIR with head support - blue Chicago
• 27552 OTOPEX ENT CHAIR with head support - green Vancouver
ENT chair designed also for ambulatory operations.
Moved by very silent electrical engines operated by joystick foot-
control. Also provided with button to re-set to previously selected
working position. Upholstery made of simulated leather, high
density undeformable foam padding (50 kg/cm
3
).
Seat and leg-rest are joined in a single piece.
Power: 230 V - 50 Hz (Available 110 V - 60 Hz). Made in Italy.
• 27540 OTOPLUS - ENT UNIT
The E.N.T. unit has rubber pivoting castors, a working surface
made of scratch-proof rolled sections, 2 small and one large
drawers provided of removable internal partitions, one drawer
with inside germicidal lamps to keep instrument sterilization.
Otoplus is provided with a silent suction pump of 34 l/min,
with power supply complete with dim adjustment device
for Clar/Storz lamp, larynx-mirror warmer, twin-cylinder dry
compressor for tubal insufflation, 2-litres distilled water tank
with acoustic signal for reseve level. The articulated arm with
instrument holding tray is complete with terminal suction
cannula and terminal insufflation cannula, ear rinsing syringe
with automatic water temperature control, (a microprocessor
keeps temperature at a constant level of 37 °C).
Power 230 V - 50 Hz (Available 110 V - 60 Hz). Made in Italy.
• 27539 OTOPLUS COMPLETE
Same as code 27540 with included vasister drawers (code
27541) and endoscope support (code 27543).
• 27554 OTOPLUS DC ENT UNIT
650 mm
490 mm
Supplied with
head-rest
1160mm
480 mm
850
mm
1,250 mm
27555
27550-1
27546
850 mm
850 mm
Compartment
for water tank
Pivoting castors
Suction pump of 34 l/
min with safety
control valve to
prevent overflow
Insufflator
Water temperature
control
Larinx-mirror warmer
Drawer with
germicidal
lamp
Dimmer for
Clar/Storz lamp
Ear rinsing
medication syringe
Space for optional
syringe medication kit
(27542)
Trendelenburg
position +5°
Revol-
ving and
removable
arm-rests in
light grey
expanded
polyuretane
Backrest synchronized
to the leg-rest move-
ment can be adjusted
at 90° and inclined
until 190°
Optional footrest
on request
The seat is adjustable
(42 cm vertical
excursion)
Seat base in heavy metal painted in epoxydic
powders, with support of pantograph arm - 90°
left and right rotation - lever locking device
Two indipendent hopper frame drawers
27540
CHAIRS AVAILABLE
IN 24 COLOURS
Space for
optional
hopper
frame
drawers
(same as
27555)
Support pole for monitor
1220mm
Foot switch for up
and down movements
138 mm
68 mm
540 mm
27551
27544
Otoplus unit with additional column, to be used for diagnostic
equipment (light source, camera or printer) and a support pole
for monitor.
• 27555 OTOPLUS DC ENT UNIT - complete
Same as code 27554 with included hopper frame drawers
(code 27541) and endoscope support (code 27543)
• 27541 HOPPER FRAME DRAWERS - 2 indipendent drawers
• 27543 ENDOSCOPE SUPPORT - 2 transparent plastic tubes
1 tube 50 cm long and 1 tube 25 cm long both closed at the
bottom.
• 27542 SYRINGE MEDICATION KIT
composed of 1 syringe,
2 atomizers (1 for liquid and 1 for powder) and 3 ampoules
in dark glass. To be ordered with ENT unit.
• 27544 LED LIGHT SOURCE
Makes cold white light (5500 °K, 180 lumen) for endoscopy use.
It can be connected to endoscopes
without necessity of F.O.
cable.
