ELECTROMEDICAL DEVICES
121
• 28363 I-TECHAR TECAR THERAPY
Diathermy, also known as TECAR Therapy (meaning Capacitive
and Resistive Energy Transfer), is a therapy stimulating the
physiological healing process by accelerating the recovery time
of motor function.
Diathermy stimulates tissues endogenous heat production
through the interaction of electromagnetic field and
tissue. The heat is increased in a uniform controlled way.
The electromagnetic interaction results in a ionic flow and
consequently increases blood flow in the treated area.
This process stimulates endogenous substances release (in
particular cortisol and endorphins) that are necessary to
reduce inflammations, pain and edemas.
The new I-TECH.AR resistive/capacitive diathermy is a modern
and highly performing device easy to use by professionals.
Pre-programmes help use the device from the start.
Moreover the device can set parameters (power, time therapy,
capacitive/resistive modes) according to therapeutic needs.
It is provided with SMART CARD to allow the memorization
of customized programmes. In this way patient protocols are
easily consulted by therapists at any time.
I-TECH.AR is equipped with a wide graphic display showing
therapy parameters and different working modes.
Menu can be easily scrolled by a comfortable control knob.
• 33251 CONDUCTIVE CREAM DISPENSER 1 kg
Moisturizing conductive cream ideal for Tecar therapy.
TECHNICAL SPECIFICATIONS
Power supply 220-240 V, 50/60 Hz
Power consumption 100 W
Working maximum power consumption 120 W
Peak power consumption 200 W
Peak voltage:
Resistive 105 V max
Capacitive 300 V max
Peak current:
Resistive 1.3 A max
Capacitive 500 mA max
Carrier frequency 455 kHz
Adjustable power 0-100%
Touch screen graphic display
Preset programmes, free memories, Smart Card
Capacitive mode
Electrode coated with ceramic material
(mobile) and return plate (fixed).
Indicated especially for soft tissues
(muscle mass and lymphatic/vascular
system). Benefits: specific intervention:
easy control of the treated area.
Resistive mode
Non isolated electrode (mobile) and re-
turn plate (fixed). Indicated especially for
tissues with greater resistance (bones,
joints, tendons, ligaments, cartilages).
Benefits: high level of diathermy; chronic
diseases with fibrosis and degeneration
STANDARD ACCESSORIES
Power supply cable
Kit 3 capacitive electrodes
Spare fuses
(Ø 30 mm, 50 mm and 70 mm)
Resistive probe
Bottle of conductive cream 1 kg
Kit 3 resistive electrodes
Steel plate
(Ø 30 mm, 50 mm and 70 mm)
Smart-card
Capacitive probe
User Manual: GB, IT, ES
STANDARD ACCESSORIES
1 handle with 5 cm
2
probe
1 power supply 15 V, 3 A
1 handle with 1 cm
2
probe
1 ultrasound gel
1 power supply cable
User manual: GB, IT, ES
APPLICATIONS
Contusions - Cervical brachialgia - Cervicalgy - Coxarthrosis - Distorsions
Epicondylitis - Gonarthrosis - Lumbago - Lumbo-sciatica - Metatarsalgy
Muscle pathologies - Muscle sprains - Myalgia - Painful phantom limb
Patellar chondropathy - Plantar fasciitis - Relief treatment of muscles
Tendinitis - Tendon lesions
28363
0476
Metal
plate
Resistive
electrodes
Resistive and
capacitive
probes
Capacitive
electrodes
APPLICATIONS
Tendinitis - Bursitis/Capsulitis - Hematomas and tissue reconstruction -
Muscle contractures/Cramps - Neuralgias - Periarthritis - Cervicalgias -
Sciatalgy/Lumbalgy - Carpal tunnel syndrome - Epicondylitis/epitrochleitis -
Contusions/sprains - Chondropathy - Massage - Arms/abdomen/legs/gluteus
cavitation - Acne
I-TECHAR - PROFESSIONAL TECAR THERAPY
TECHNICAL SPECIFICATIONS
Operating voltage: 100-240 V, 47/63 Hz, 1.35A, output 15V 3A max
Ultrasound frequency: 1 MHz ± 10% and 3 MHz ±10%
Output power: 0.5-10 W ± 20% when duty cycle ≥ 80% for 5 cm
2
ultrasound head
0.5-15 W ±20% when duty cycle ≤ 70% for 5 cm
2
ultrasound head
0.1-2 W ±20% when duty cycle ≥ 80% for 1 cm
2
ultrasound head
0.1-3 W ±20% when duty cycle ≤ 70% for 1 cm
2
ultrasound head
Max Power: 3 W/cm
2
± 20% (1 MHz)
3 W/cm
2
± 20% (3 MHz)
Working frequency: 100 Hz
Duty cycle: 10%-100% stepping 10%
Maximum adjustable therapy time 30 minutes
Effective radiating area 5 cm
2
± 20%; 1 cm
2
±20%
Collimated beam type
Ultrasound head (material) aluminium
Direct contact and water immersion use
Led indicator
Size: 350x186x86 mm
• 28358 I-TECH UT2 ULTRASOUND THERAPY - 2 probes
Professional ultrasound device equipped with 2 handles
respectively with 5 cm
2
and 1 cm
2
probe. Its equipment and
parameters setting allow high performance suitable for
professional users.
It is provided with 10 preset programmes within which
professional user can adjust following parameters:
- Frequency (1 or 3 MHz)
- Effective intensity (up to 3 W/cm
2
)
- Duty cycle (10%÷100% stepping 10)
- Therapy time (up to 30 minutes)
Handle with
1 cm
2
probe
Handle with
5 cm
2
probe
0476
I-TECH UT2 - PROFESSIONAL ULTRASOUND THERAPY
28358
