FURNITURE
88
• 27827 PROFESSIONAL PATIENT TROLLEY - with adjustable
backrest and side rails
Trolley made of anodized aluminium with steel perimetral
frame with rigid PVC profile.
Coated with epoxy powder RAL 103 ivory.
Rigid mattress platform made of powder coated steel welded
mesh. Main frame, side rails and shove handle bar made of
anodized aluminium. Nylon components with handle shape.
Swivelling castors Ø 200 mm, 2 of which with brake.
Delivered in kit from.
Made in Italy.
• 27830 IV STAND - fixed height 100 cm - 2 plastic hooks
• 27831 STEEL BASKET - 56x38x9h cm
• 27832 OXYGEN BOTTLE HOLDER - Ø18x37 cm
• 27834 FIRE RETARDANT MATTRESS 7 cm - black - 185x58x7h cm
• 27828 ADJUSTABLE HEIGHT PATIENT TROLLEY
with Trendelenburg (TR), Reverse Trendelenburg (RTR) and side rails.
Platform composed by two epoxy powder coated steel RAl 1013
ivory welded mesh sections, detachable for cleaning, fitted on
nylon supports and placed on steel crossbar covered with rigid
PVC profile. Raising and lowering by gas spring with lever set on
the same section.
Trolley structure with a rounded section profile coated with epoxy
powder RAl 1013 ivory. Adjustable height by oleodinamic pump
from 50 cm to 80 cm with foot control lever. TR-RTR position
controlled by handle at the foot of the trolley. Mechanical
braking. Inclination and platform check by a level bubble. TR 14°
RTR11°. Swivelling castors Ø 200 mm, one of which directional.
Simultaneous braking with foot control lever with 3 positions: total
brake, swivelling total, swivelling and directional. Made in Italy.
• 27830 IV STAND - fixed height 100 cm - 2 plastic hooks
• 27833 OXYGEN CYLINDER HOLDER (max. 7 l) andWIRE BASKET -
multifunction
• 27835 FIRE RETARDANT MATTRESS 10 cm - 2 sections - 185x58x10h cm
PROFESSIONAL PATIENT TROLLEYS
WITH ADJUSTABLE BACKREST
ADJUSTABLE HEIGHT PATIENT TROLLEY
WITH TR AND RTR
• 27913 INSTRUMENT TABLE 2 SHELVES
Operating room instruments table
made of stainless steel AISI 304 scotch
brite finish.
125 mm Ø revolving castors (2 with brake).
Weight: 28 kg.
Load for shelf: 40 kg.
Size: 120x65xh 95 cm.
Delivered in kit form (123x13x68 cm).
Made in Italy.
• 27909 INOX WORKING TABLE
Working table, equipped with
two drawers (47x30x12 cm) each side, to
work on both sides. Stainless steel AISI
304 frame, structure made of square
tubular, table top and lower shelf made
of smooth stainless steel. Mounted on 4
castors Ø 100 mm, two with brakes.
Weight 50 kg. Size 120x70xh 95 cm
Max load (x shelf): 40 kg
Delivered in kit form 122x35x72 cm
Made in Italy.
• 27914 INSTRUMENT TABLE 1 SHELF
Operating room instruments table made
of stainless steel AISI 304, scotch brite
finish. Stainless steel adjustable 105-136
cm upper part with 4 instrument hooks.
125 mm Ø revolving castors (2 with brake).
Weight: 21 kg. Load: 40 kg.
Size: 120x65xh 95 cm.
Delivered in kit form (123x13x68 cm).
Made in Italy.
27914
27913
27909
INOXWORKINGTABLE OPERATINGTHEATREINSTRUMENTTABLES
Overall size: 202x76x75 h cm
Mattres platform size: 190x60x50/80 h cm
Weight: 88 kg - Shipping volume 0.65 m
3
Load: 120 kg
Easy and fast lock of IV stand
at main frame 4 corners
Shelf size: 120x65 cm
Shelf size: 120x65 cm
Safety protection
on 3 sides
Overall size: 202x76x75 h cm
Mattres platform size: 190x160x75 h cm
Weight: 47 kg - Shipping volume 0.30 m
3
Load: 120 kg
27828
27827
