FURNITURE
93
PROFESSIONAL CARTS
GIMA
code
PROFESSIONAL CARTS
PRO CART 2 shelves - h 80 cm
PRO CART 2 with insulation transformer 800VA
PRO CART 2 + keyboard, monitor support
PRO CART 4 shelves - h 146 cm
PRO CART 4 with insulation transformer 1600VA
PRO CART 4 + keyboard, monitor support and drawer
27885
27886
27887
27890
27892
27893
• 27440 EXCEL TROLLEY -
3 shelves (60x45cm)
Size: 60x45x h78 cm.
• 27441 EXCEL TROLLEY -
4 shelves (60x45cm)
Size: 60x45x h110 cm.
Delivered in kit form.
Made in Italy.
27441
Excel Trolleys are now produced
without upstands at four sides
for an easier cleaning of the
trolley.
110 cm
Capacity
max 80 kg
Castors
Ø 100 mm
(2 with brake).
EXCEL TROLLEY
TECHNICAL SPECIFICATIONS
Load capacity:
- total load 240kg
- shelf 35kg
Base: 60.8x50 cm
Shelves: 2 or 4 shelves 50x50 cm + base
Material:
- vertical extrusions in aluminium
- plastic parts in ABS
Made in Italy
GIMA
code
ACCESSORIES
Basket
Infusion stand
Arm
Oxygen tank support
Push-handle
Extra shelf 50x50 cm
27873
27874
27876
27877
27878
27879
27876 SILVER ARM
- 330 mm, (13”) height range
- display tilts +5/-75° forward back
- display rotate 90° portrait/landscape
- display pans 360° right/left
- arm extends/retracts display (610 mm)
- weight capacity adjust to hold display
between 3.22 - 9.1 kg (7-20 lbs)
- internal cable management routes
cables neatly under arm
All professional carts are
supplied with cable pipe
inside lateral columns.
27887
+
27873
27877
27893
27874
CARTS
FOR ELECTROSURGICAL UNITS
Trolley designed to hold and carry electrosurgical units
(including Argon units). Ergonomics has been
particularly considered for the design, for
example the height of 900mm with inclined top
shelf allows easy reading of the unit's display.
The trolley is provided with a second shelf with
antiskid raised edges, two drawers placed at the
base and a rear space with securing straps to hold
two Argon cylinders. The upright stands holding
the shelves are designed to take possible optional
accessories. All parts of the trolley are made of
epoxy-painted, tempered steel and aluminum.
Available version with 4 socket group, fuses
box, independent grounding plug, power cable
3m.
TECHNICAL SPECIFICATIONS
Load capacity:
- Total load 200 kg
- Inclined shelf 50 kg
Inclined shelf:
42x45 cm (27864/6)
50x50 cm (27865/7)
Drawers and shelf: 42x31 cm (27864/6)
50x36 cm (27865/7)
90 cm
TOP QUALITY
Power available
with 27866/7
GIMA
code
CARTS FOR ELECTROSURGICAL UNITS
DIATERMO CART - medium
DIATERMO CART - large
DIATERMO CART with power - medium
DIATERMO CART with power - large
27864
27865
27866
27867
All professional carts are
supplied with cable pipe
inside lateral columns.
