SCALES & MEASURES
53
•
27322 GIMA BODY FAT ANALYZER
Ideal for dieticians, gymnasia and sports centres, it is perfect
also for homecare. It will help manage nutrition, fitness and
weight control and can indicate if you are at the right weight
and also whether or not you are nutritionally healthy.
Advanced technology in your hands.
GIMA Body Fat Analyzer measures the flow of electrical signals
(total body electrical resistance or impedance) as they pass
through FAT, LEAN (muscle, bones, vital organs) or WATER.
When the amount of fat, lean or water changes, so does the
Body Fat signal, giving you a highly reliable and accurate
measure of the amount of each of these components that
make up your total weight. Specifically, 4 electrodes are placed
over metacarpus and metatarsus where a 50 kHz current is
introduced. The detected signal level will be an index of total
body water and fat free mass.
Only 2 minutes for an essential and easy test
Testing and results take less than two minutes and have the
same accuracy as other more expensive devices.
A lot of meaningful data
FAT:
actual weight of fat on the body
LEAN:
actual weight of lean, mostly muscle and vital organs
WATER:
water content in the body
% FAT:
percentage of fat weight in total body weight
% LEAN:
percentage of lean weight in total body weight
BMR:
basal metabolic rate
Target Weight:
weight goal under optimal condition
Target % Fat:
normal percent for sex and age
Portable, for performing test everywhere
Small size and light weight for portability.
Body Fat Analyzer helps to get and stay fit.
It helps to maximize personal level of fitness if you want to
lose weight, build muscle, tone and trim, or simply be sure you
are maintaining your current level of fitness:
- enables you to check effectiveness of weight loss program, telling
exactly where your weight loss is coming from (fat-lean-water)
- it helps monitoring improvements in muscle mass as a result
of exercise and/or diet
- establishes a baseline for your body composition, so that
nutritional and fitness improvements can be regularly
monitored.
Frequent calibration
(code 27324 calibration kit) is
necessary for accurate results in the time.
TECHNICAL SPECIFICATIONS
Size: 66x176x208 mm
Weight: 1,500 g (unit, battery and probe)
Test frequency: approx. 50 kHz Test current: less than 1mA
Power source: two 9 Volt DC batteries or 230 V (by transforrner)
27322
BODY FAT ANALYZER
WITH CARRYING CASE
BODY FAT MONITOR
•
27348 BODY FAT MONITOR
Portable and convenient body fat monitor for private use.
Main features:
- body fat analyzer function
- body fat ratio function
- BMI function
- calorie calculation function
- auto power off
(when no operation is detected for approximate 2 minutes)
- memory function stores up to 9 personals data
- 1 personal data for guest (will be initial after power off)
TECHNICAL SPECIFICATIONS
Size: 240x160x43 mm
Weight: 305 g
Power supply: 2xAAA batteries - not included
Supplied with a carrying case, kit of 2 sensor cable, sensor pads
(box of 20), 2x9 V batteries, transformer and manual (GB, IT, FR, ES).
• 27321 SPARE SENSOR CABLES (kit of two) units sold after 06/02
• 27323 SENSOR PAD (box of 20) - replacement
Each sensor can be reused 5-6 times.
• 32205 9V ALKALINE BATTERY • 27324 CALIBRATION KIT
- two automatic traning programs per
age input:
Fat burning program &
Build cardiovascular strength program
- freely programmable target zone &
exercise time
- three different audible alarms
- two different visual alarms
- current heart rate intensity %
- efficiency percentage of preset
exercise time
- preset exercise time countdown <over
low limit>
- current heart rate display 35~250
beats per minute
- maximum heart rate recorded 35~250
beats per minute
- average heart rate in 6 optional
periods <10~60 minutes>
- total time over high limit of target
zone <up to 9:59:59>
- total time over low limit of target zone
<hour / minute / second>
- stopwatch 9:59:59 <hour/minute/second>
- unique transmission LED indicator
- 12/24 hour clock
- Target Zone indicator
- Target Zone re-settabIe and
re-checkable
- current cardiovascular strength level
- time bar in seconds
- EL backlight
TECHNICAL SPECIFICATIONS
30 meters water-resistant <watch>
Weak battery detection
3V batteries changeable
Auto power saving
• 28400 HEART RATE MONITOR - 20 functions
*
- with belt
HEART RATE MONITOR
20 FUNCTIONS
*
Suitable for person up to 60 years.
BODY FAT CALIPER
•
27318 BODY FAT CALIPER
Plastic body fat caliper.
Size 16.5x10x0.5 cm. Weight 22 g.
Supplied into a polybag
in a paper box.
