SCALES & MEASURES
56
LED PODOSCOPE
• 27353 LED PODOSCOPE
Device for the plantar analysis
of the feet. It has a Iacquered
wooden structure and a crystal
top with an inclined mirror
below it for a real view of the
sole of the feet, which hi-
ghlights the points of greatest
and least load. Double lateral
illumination with high level
effect lamps. Max Load 135 kg.
Strong reliable and professio-
nal product, made in Italy.
Size: 46x55xh 33 cm
Weight: 15.5 kg
Power: 100-240 V, 50/60 Hz
Working
surface
32x36 cm
27353
SCOLIOMETER
• 27351 SCOLIOMETER
Plastic instrument for the evaluation of the scoliosis (deviation
of the spinal column on the lateral, left and right planes).
The instrument detects the anomaly and its gravity. It also
allows to compare reports during the time and define the
evolution of the measured pathological process, thus reducing
the need of frequent radio
graphical tests. The small
sphere oscillating within an
air space indicates the spine
inclination degree, compa-
red to the horizontal plane.
• 27352 POSTURAL ANALYZER
The postural analyser consists of a
bilaminated footboard with
adjustable feet.
The two lateral aluminium rods are
equipped with millimetric scales,
measuring sliders and strings to
allow correct body
alignment (Barré's vertical).
Adjustable upper mirror.
27352
Size:
80x72xh 225 cm
POSTURAL ANALYZER
PLUMBING
WEIGHT
TECHNICAL SPECIFICATIONS
Capacity: 135 kg - 297 lbs
Dimensions: 43.5x42.5xh 22 cm - 17.12x16.75x8.67 inch
Weight: 8 kg - 17.63 lbs
Operating voltage: 220 V-50/60 Hz (110 V on request)
Fluorescent lamp with 10,000 hours lifetime
GIMA PODOSCOPE
WITH POLARIZED LIGHT
Highly resistant, easy maintenance
The GIMA Podoscope with polarized light has been designed
for a long lasting duration. High-quality material and
components, serial assembly and control checks constantly
performed during production and at final test, provide
superior accuracy. Its structure is resilient and can bear charges
up to 135 kgs - 297 lbs. Its green-light lamp has a life of 10,000
hours (duration indicated by the manufacturer). Spare bulbs
are easy to be replaced.
Easy to use, light and practical
The GIMA podoscope becomes operative at once simply
switching it on. Just after the patient has stepped on it, in real
time you can proceed with the study. The device is meant to
be practical and easy to use. Since methacrylate is light and
resistant at the same time, the device can be comfortably
moved from a place to another, also thanks to its limited
dimensions. The step is low: 22 cm from ground level, so that
even elderly patients can easily step on it.
• 27354 GIMA PODOSCOPE
The GIMA Podoscope with polarized light allows operators
to observe the foot plant highlighting the points with the
heaviest pressure. The patient stands on the methacrylate
platform, an excellent light conductor, provided with an inner
light source to detect variations of colour intensity on the foot
plant, corresponding to higher or lower plant charge.
27354
Methacrylate
• 27338 GONIOMETER WITH
ARMS (tolerance 1°)
To measure analytical motility
of various body segments
in degrees (from 0 to 360
clockwise or anti-clockwise
direction). Consists of two
perspex arms (3 mm thick)
that will remain open at any
given position due to the
friction at the joint between
them. Two graded scales:
one increasing scale and one
decreasing scale.
30 cm
• 27340 GONIOMETER - 205x45 mm
With circular scale used to check
the size of hip joints and the
angle of the femoral neck on
x-rays. Personalisation with your
logo for minimum 2,500 pcs.
Used by orthopaedic surgeons to measure the range of movement
of joints: elbows, knees and fingers.
GONIOMETERS
27340
27339
27339
27338
27351
• 27355 PLUMBING WEIGHT
Made of stainless steel (magnet)
with wire length 150 cm.
Supplied in wooden case.
Size: 6.2x2.3 cm.
Weight: 140 g.
• 27339 GONIOMETER WITH
PAIN SCALE RULER -
203x45x7 mm
27355
