GINEX CHAIRS, STOOLS AND WORKSTATIONS
GYNEX PROFESSIONAL - GYNAECOLOGICAL CHAIR
Gynex professional chair offers fuctionality, aesthetics, ergonomics.
It can satisfy all patient and user needs for a professional
gynaecologic visit. Gynex professional is provided with versatile
accessories: back paper-roll dispenser, metal basin, chromed
handles, leg-supports. 3 engines allow, in addition to lifting,
electric back-rest and leg-rest movements. Thanks to the combined
movement of backrest and seat by means of self-balancing system
(operated by 2 silent low tension actuators of 1,000 N each). Gynex
Professional grants maximum comfort to the patient. The padded
and pelted arm-rests allow a relaxing protecting sitting position,
arm-rests are individually revolving and removable.
Backrest is provided with removable height-adjustable head-rest.
The wide and soft backrest has independent adjustment movement
through silent low tension actuators (1,000 N each one). This chair
is moved by a silent low tension engine which allows a vertical
excursion of 40 cm from zero position. The electrical drives are
controlled by an ergonomic hand switch control, connected to the
chair by a cable. Gynex professional can be easily transformed into
an examination bed (horizontal position).
• 27529 PAPER ROLL HOLDER
Lifting
capacity
180 kg
Back-rest can be
adjusted to 180° by
a gas spring
1 OR 3 ENGINES GYNAECOLOGICAL CHAIRS AND STOOLS
GYNEX
GYNEX PROFESSIONAL
with 3 engines
GYNEX
• 27518 WORK STATION SW2
- steel structure, painted with
epossidic powder
- 4 antistatic pivoting
wheels
Made in Italy.
TECHNICAL SPECIFICATIONS
GYNEX
GYNEX PROFESSIONAL
Power supply tension:
230V - 50 Hz (110V - 60 Hz on request)
Motor tension:
24 V
24 V
Lifting motor push:
4,000 N
4,000 N
Backrest motor push:
800 N
2,000 N
Legrest motor push:
-
2,000 N
Lifting capacity:
180 kg
180 kg
Maximum power:
90 VA
90 VA
Fuses protection:
1.6 A
1.6 A
GYNEX - GYNAECOLOGICAL CHAIR
GYNEX: a chair offering a unique
combination of functional, aesthetic
and working characteristic. Thanks
to its self-balancing seat and back-
rest, GYNEX can be adjusted to
any build for the greatest patient
comfort. The chair is provided with
an electromechanical lifting device,
having a secondary power supply
at 24V. The electric actuators enable the movement up and
down from 57 cm off the floor (“0” position) up to a maximum
of 96 cm. The back-rest is supplied with adjustable head-rest
and paper roll holder (excluding 27520). The leg-rest can be
indipendently adjusted and it has an automatic-locking device.
The chair can be flattened to a bed position for examination
activity, the arm-rest can be removed and independently
oriented. The electric control of the chair for upright position
is operated by means of a foot pedal. Operating power
230V-50Hz (available on request 110 V-60Hz). Made in Italy.
All chairs are supplied with paper roll holder.
GYNEX PROFESSIONAL
27515
27523
STANDARD ACCESSORIES
GYNEX
GINEX PROFESSIONAL
Poliuretane leg-rest
•
Padded leg-rest (colour coordinated)
•
Paper-roll holder
•
•
Metal basin
•
Remote control
•
STOOL - with or without ring
For professional use, completely built
in stainless steel, 360° pivoting self-
braking castors, rubber-tyred.
Height can be comfortably adjusted
by means of a gas pump; back-rest is 180°
revolving and depth-adjustable.
Seat is balanced density padded and
Peltex-lined.
Made in Italy.
500 mm
385 mm
Minimum/maximum height:
530/660 mm.
27528
810 mm
27532
“Linak”
top quality
engine inside
Armrest
26.5x17 cm
Ginex professional
27514
27512
**
27513 27512
**
27515
27512
**
Ginex
27521
27522
27523
27524
27525 27526
27520
**
Stool with ring
27531
27532
27533
27534
27535 27536
27530
**
Stool without ring
27527
27528
**
Workstation
27517
**
27519
27517
**
27518
27517
**
**
Available in 60 days, specify colour with order
