BIPAP R200 THERAPY SYSTEM
|
|
| 53722 | |
| 1 pc | |
| 1 | |
| Medical device | |
| II A |
| No | |
| No |
| 2952453 | |
| Z1203010502 | |
| 6934440103103 | |
| 42411 | |
Download Area
Operator Manual
CE Certificate + extension letter
Declaration of conformity
BiPAP R200 THERAPY SYSTEM2
This innovative sleep therapy system is designed to enhance patient comfort and treatment outcomes through smart features and real-time monitoring.
3.5” colour LCD display
The device features a 3.5” colour LCD touch screen designed for intuitive and easy operation. It offers multiple real-time monitoring and statistical parameters, enhancing both the
efficiency and effectiveness of therapy.
Wide range of NIV modes
It supports a wide range of NIV modes, including CPAP, APAP, S, S/T, and T, ensuring flexibility for different patient needs. The system provides accurate event detection for an improved respiration experience, identifying events such as OA, CA, H, RERA, Snoring, PB, LL, and especially central respiratory events.
Intelligent humidification system
An intelligent humidification system maintains optimal air humidity while minimizing condensation. With preheated water, the system delivers comfortable humidity immediately after startup.
LeRes-Control
LeRes-Control algorithm control technology affords patients the maximum comfort for ventilation.
Firmware languages: GB, FR, IT, ES, RO, GR.
Mode: CPAP, APAP, S, T, S/T
Pressure range: 4-25 cmH2O
Pressure accuracy: 0.5 cmH2O
Ramp time: 0-60 min
Humidification level: 1-5 levels
Tube diameter: Ø 22 mm
Noise level: < 30 dB
Data storage: 8 GB
Connection: Bluetooth BLE, Wi-Fi 2.4 Ghz
Voltage: AC input 100-240 V, 50/60 Hz
Auto On/Off: Auto On when patient wears a mask, Auto Off within
5 seconds after mask removal
Size - weight: 270x168x91 mm - 1.6 kg
Protection: type BF applied part; Class II; IP22
1 face mask
1 breathing tube 1.8 m
1 filter PM2.5
Power cable
Carrying case
USB flash drive 8 G
PC software
User manual: GB, IT
