DIAGNOSTICS
210
32691
• 32691 BLACK KOBOLD with gray cuff - 223.20493
• 32695 GREY KOBOLD SET with 3 ped. "Superb" cuffs - 227.71.393
• 32696 GREY KOBOLD SET with 6 "Superb" cuffs - 227.71.195
Elegant and compact, single tube sphygmomanometer for
frequent use in clinic and consu lting room. Precision manometer,
anodised aluminium Ø 48 mm. Sensitively adjustable air reduction
valve, high quality chrome finish. Scale: 300 mmHg, 2 mm scale
division. New technology with air intake via the manometer
capsule in the specially tempered copper-beryllium membrane.
Codes 32693, 32695, 32696 are latex free. Made in Germany.
ERKA “SUPERB“ GREEN CUFFS
All ERKA Green cuff products are PVC, demp and latex-
free, every one is individually tested prior to delivery and
guaranteed for 50,000 inflation cycles. They are equipped
with clearly marked size and positioning features for the most
accurate possible measurements. The soft, easy to disinfect,
biocompatible materials ensure maximum patient comfort.
Conform to ANSI/AAMI SP10 standard
• 32891 PEDIATRIC "SUPERB" CUFF 1 TUBE 20.5 - 28 cm - gray
• 32892 ADULT "SUPERB" CUFF 1 TUBE 27-35 cm - gray - spare
• 32688 ERKA PERFECT - 201.204.82
dial Ø 48 mm - 2 tubes
Sphygmomanometer with screw valve for
sensitive adjustments, velcro cuff and case.
- manometer housing brass chromed
plated
- membrane-protection 2-tube technology
- measuring range 0-300 mmHg ±1%
Made in Germany. 3 year warranty.
“SUPERB“ GREEN CUFFS 2 TUBES
• 32898 PEDIATRIC "SUPERB" CUFF 20.5-28
*
cm
• 32899 ADULT "SUPERB" CUFF 27-35
*
cm
• 32900 ADULT LARGE "SUPERB" CUFF 34-43
*
cm
*
Circumference of upper arm
• 32698 ERKA SWITCH 2.0 CONFORT -
dial Ø 56 mm - 1 tube - 293.204.93
It offers oustanding ergonomics and
simple adaptation for left and right-
handle users. It is manufactured from
shock-resistant polycarbonate and has
passed the shock test according to AAMI
SP9. The sight glass is chemically stable
and unbreakable. The brass valve screw
works smoothly and is adjustable to
exact settings. Measuring range 0-300
mmHg ±1%. Supplied with pouch.
Made in Germany. 4 year warranty hand
held, 2 year manometer.
• 32697 ERKA SWITCH SIMPLEX -
dial Ø 56 mm - 2 tubes - 294.408.94
It is manufactured from shock-resistant
polycarbonate and has passed the
shock test according to AAMI SP9. The
sight glass is chemically stable and
unbreakable. The brass valve screw
works smoothly and is adjustable to
exact settings.
Measuring range 0-300 mmHg ±1%.
Black velcro cuff. Supplied with pouch.
Made in Germany.
2 year warranty.
PERFECTANEROID ERKA SWITCH
Erka Superb Green
cuff. Latex, PVC
and DEHP free
Erka Superb
Green cuff.
Latex, PVC
and DEHP
free
32696
32695
Includes 6 cuffs for below
indicated circumferences
of upper arm
Thigh
42-54 cm
Adult large
34-43 cm
Adult
27-35 cm
Child
20.5-28 cm
Child
20.5-28 cm
Baby
13-20 cm
Baby
13-20
cm
Infant
10-15 cm
Infant
10-15 cm
32688
32698
32697
0124
0124
0124
ERKA
SWITCH SIMPLEX
0124
0124
KOBOLD SPHYGMOMANOMETER BY ERKA
