DIAGNOSTICS
217
Danger
Normal
• 32774 VITAL VISION MS-1200
The first unit in the world measuring artery stiffening.
Arterial hardness measurement complements blood pressure
management.
Both are needed to ensure a long and healthy life.
Measuring arterial hardness and blood pressure on a regular
basis will help you to gain knowledge of your cardiovascular
condition and provide early diagnosis for treatment.
Size: 175x90x105 mm with cuff storage compartment 30 sets of
memories with date/time stamp for blood pressure and pulse
rate monitor.
ARTERIAL HARDNESS AND BLOOD PRESSURE MONITOR
• 32780 DAILY ABPM + software
A simple, economic and small size unit for 24 hours ambulatory blood
pressure monitoring. Main features:
- 4 - memory zones, 99 - readings each (total 396 measurements)
- patient-friendly performance at affordable price
- automatic measurement by two predetermined intervals
- irregular Heartbeat detector, detect a disturbance in the regular rhythm
of the heartbeat
- big LCD display showing measuring date and time
- 5 - mode average function, by hour, day, week, month and overall
- transfer to PC via software and USB plug of measured values
- lithium battery, long - time measurement
Supplied with arm cuff (22-34 cm) carrying bag and software.
• 32783 ADULT CUFF - spare
• 32784 LITHIUM BATTERY - spare
TECHNICAL SPECIFICATIONS
Measuring type: Oscillometric system
Measuring range: Pressure: 20~80 mmHg ± 3 mmHg
Pulse: 40~195 beats/min ± 5%
Power supply: Lithium Battery, 3.7 V 1050mA
Weight: Approx. 260g (including cuff, ex. batteries)
External dimension: 184x84x33 mm Arm cuff: 22-34 cm
Artery
24 HOURS BLOOD PRESSURE MONITOR SYSTEM
32774
0476
0044
• 32930 OMRON M3 HEM-7200-E2 (V)
• 32933 ADULT CUFF 22-32 cm - HEM-CR24 - spare
• 32929 ADAPTOR
• 32931 OMRON M6 COMFORT - HEM-7223-E
• 32935 COMFORT CUFF 22-42 cm - spare for M6 COMFORT, M7, M10
• 32929 ADAPTOR
• 32932 OMRON RS3 HEM-6130-E
Dual check
sensor for
double
measurement
(standard
and control)
for superior
accuracy
The Intellisense™ technology ensures
that the right inflation pressure is
automatically detected. It detects irregular
pulses and decides fully automatically if
the measurement result is usable or the
measurement needs to be repeated.
Only accurate results are displayed.
B.P. level indicator easily
identifies possible hypertension
Full size display with all
parameters at once
Comfort cuff fits
normal and large arms
0197
0197
OMRON DIGITAL BLOOD PRESSURE METERS
TECHNICAL SPECIFICATIONS
32930 M3
32931 M6
32932 RS3
Measuring method:
oscillometric
Measuring range:
Pressure:
0 mmHg to 299 mmHg ± 3 mmHg
Pulse:
40 to 180 min ± 5% of display reading
Memory (with data and time):
60x 2 users
100x2 users
60
Inflation:
fuzzy logic controlled by electric pump
automatic
Deflation:
automatic pressure release valve
automatic
Rating:
Power source:
4 "AA" batteries 1.5V
2 "AAA"batteries 1.5 V
Battery life (N° of measurements): 1500
1000
300
Protection against electric shock:
Weight (console+cuff) whitout batteries: 340+120 g
380+210 g
101 g
Size:
123x141xh 85 mm
123x158xh 85 mm
78x60h 21 mm
Cuff materials:
nylon and polyester
Measurable circumference:
22-32 (arm)
22-42 (arm)
13.5-21.5 (wrist)
internally powered ME equipment
(when using batteries)
Irregular heartbeat detection
(sensibility comparable to ECG
12 lead)
0197
