DIAGNOSTICS
218
• 33351 AM100 GIMA ABPM with adult cuff
The AM100 is a compact, lightweight instrument that provides
a cost-effective solution for monitoring patient's blood
pressure outside the clinical environment.
AM100 employs the popular oscillometric technique of blood
pressure measurement. The simplicity of this technique provi-
des for the quickest patient hook-up. AM100 interfaces with
Win Pro PC
Software for monitor programming as well as
report editing and generation.
Oscillometric technology:
quick hook-up, making it easy to
use, saving your staff time
Compact and quiet:
silent operation and compact size aid
patient compliance.
Low power consumption:
requires only two "AA" batteries,
making this unit much less expensive than others.
AM100 is supplied complete with software, standard cuff,
carrying-bag, English manual and PC connection cable.
• 33348 PEDIATRIC CUFF - arm circumference 18-27 cm
• 33349 ADULT CUFF - arm circumference 25-35 cm
• 33353 ADULT LARGE CUFF - arm circumference 33-40 cm
• 35110 GIMA ABPM + Pulse rate with software
• 35112 GIMA ABPM + Pulse rate with software and Bluetooth
• 35111 GIMA ABPM + Pulse rate + SpO
2
with software
GIMA ABPM module measures the blood pressure using the
oscillometric method. Two modes of measurement: manual and
automatic. Each mode displays the diastolic,
systolic and mean blood pressure.
In the MANUAL mode, only one measurement is
conducted for each time.
In the AUTO mode, the measurement is cycled; you can
set the interval time to 5/10/15/20/30/45/60/90 minutes
- compact and portable, easy to use
- suitable for adult, pediatric and neonatal patient
- large color LCD display of ABPM, SpO
2
and pulse rate
- adjustable audible and visual alarms
- real-time ambulatorymonitoring 24 hours storage and reviewof date
- oscillometry with step deflation
- clinically proven accuracy
- all data can be transferred to a PC through Windows-based sof-
tware or Bluetooth (35112) for review and print (English, Italian)
• 35113 CHILDREN CUFF - arm circumference 18-26 cm
• 35114 ADULT CUFF - arm circumference 25-35 cm
• 35115 ADULT LARGE CUFF - arm circumference 33-47 cm
• 35116 THIGH CUFF - thigh circumference 46-66 cm
• 35118 ADULT SpO
2
PROBE - reusable - spare
PG WIN PRO PC INTERFACE
- creates a monitoring plan tailored to an individual patient
with up to 3 specific time periods
- generates concise clinical reports.
PG Win reports include full disclosure of blood pressure
readings, heart rate, mean arterial pressure, blood pressure
load and trend of BP values vs. time. Compatible with
Windows 95, XP and Windows 7.
TECHNICAL SPECIFICATIONS
Tecnique: Oscillometry with step deflation
Blood pressure range: 25-260 mmHg ±3 mmHg
Heart rate range: 40-200 bpm
Display: Liquid crystal
Recording duration: Up to 52 hours
Sample quantity: Over 250 sample of systolic, diastolic, MAP and heart rate
Sampling periods: 3 time periods
Power source: 3 VDC/Two 1.5 V “AA” Alkaline
Display: color LCD
Power: two "AA", 1.5V alkaline batteries
Dimension: 120x80x32 mm
Weight: <350 g (including batteries)
SpO
2
(35111 only)
Measurement range: 0-100%
Resolution: 1%
Accuracy: 70-100% ±2%
Alarm range: 0-100%
NIBP
Method: oscillometry
Mode: manual/automatic/continuous
Measurement range: 25-260 mmHg
(max 280 mmHg)
Automatic measurement interval:
5, 10, 15, 30, 45, 60, 90, 120 minutes
Resolution: 1 mmHg
Overpressure protection: 300 mmHg
Alarm: systolic, diastolic
Mean alarm range: 10-270 mmHg
Pulse rate
Range: 0-254 bpm
Resolution: 1 bpm
Accuracy: ±1 bpm
Alarm range: 0-254 bpm
Operating system
Windows XP/Seven,
8, 8.1 (only at 32 bit)
Carrying bag
Software (English - Italian)
3 nylon cuffs (pediatric, adult, adult large) - latex free
SpO
2
probe (only code 35111)
Cuff connection tube 1.5 m
User manual
Batteries
Compact size: 12x7x3 cm, and light,
350 g only, including batteries
UP TO 52 HOURS AMBULATORY BLOOD PRESSUREMONITOR
24HOURSABPM,SpO
2
ANDPULSERATEAMBULATORYMONITOR
TECHNICAL SPECIFICATIONS
STANDARD ACCESSORIES
0123
35111
Hose
Cuff
SpO
2
sensor
Device
0068
