AUDIOMETRY & SPIROMETRY
220
TECHNICAL SPECIFICATIONS
Type of device
Hybrid audiometer
Class (EN 60645-1, ANSI S3.6)
3 diagnostic
Output
AC, BC
Masking
NBN, WN
Insert masking earphone
Yes
Warble tone
Yes
Pulsed tone
0.5 Hz, 1 Hz, 2 Hz
Frequency range
125 - 8,000 Hz
Maximum output intensities
AC: -10 to 120 dB HL
BC: -10 to 80 dB HL
Attenuator step
5 dB
Automatic audiometry
HW auto threshold
Talk over
Internal or external microphone
Display type
Colour graphic
Display size resolution
4.3", 480x272
Internal memory
100 patients
Operating voltage
100-240 V, 50/60 Hz
Dimensions
32x32x9 cm (12.6x12.6x3.5 in)
Weight
1.8 kg (4.0 lbs)
Piccolo Basic
Piccolo Plus
Piccolo Speech
Type of device
Pc control
PC (33615) or Pc and iPad
®
control (33616)
Pc and iPad
®
control
Class EN 60645-1, ANSI S3.6
4-screening
3-diagnostic
3-diagnostic
Output
AC
AC, BC
AC, BC, Live Speech
Masking
NBN
NBN
NBN, WN, SN
Warble tone
Yes
Yes
Yes
Pulsed tone
0.5 Hz, 1 Hz, 2 Hz
0.5 Hz, 1 Hz, 2 Hz
0.5 Hz, 1 Hz, 2 Hz
Frequency range
125 - 8,000 Hz
125 - 8,000 Hz
125 - 8,000 Hz
Maximumoutput intensities
AC: -10 to 120 dB HL
AC: -10 to 120 dB HL
AC: -10 to 120 dB HL
BC : -10 to 80 dB HL
BC: -10 to 80 dB HL
Attenuator step
5 dB
5 dB
5 dB
Automatic audiometry
HW auto threshold
HW auto threshold
HW auto threshold
Speech audiometry
No
No
Yes
Speech inputs
-
-
EXT1, EXT2, Mic
Talk over
External microphone
External microphone
External microphone
Connection to PC
USB [driverless]
USB [driverless]
USB [driverless]
Controlling software |------------------------------------------------Daisy or Noah with Maestro module ----------------------------------------------|
Connection to iPad
-
Bluetooth 4 (only 33616)
Bluetooth 4
Controlling app
-
Maestro (App Store)
Maestro (App Store)
Dimensions
|-----------------------------------------------------16x16x3cm (16.3 x 6.3 x 1.2 in) ------------------------------------------------------|
Weight
300 g (10.6 oz)
300 g (10.6 oz)
300 g (10.6 oz)
Operating voltage
100-240 V, 50/60 Hz
100-240 V, 50/60 Hz
100-240 V, 50/60 Hz
BELL PLUS DIAGNOSTIC AUDIOMETER
PC OR PC-iPAD CONTROLLED PORTABLE AUDIOMETERS
TECHNICAL SPECIFICATIONS
33613
Piccolo Basic screening audiometer - air + mask
PC
33615
Piccolo Plus diagnostic audiometer - air + bone + mask
PC
33616
Piccolo Plus Aero diagnostic audiometer - air + bone + mask PC + iPad
33618
Piccolo Speech Aero diagnostic audiometer -
air + bone + live speech + mask
PC + iPad
GIMA
code
Management
SCREENING AND DIAGNOSTIC AUDIOMETERS
Manual:
GB, FR, IT, ES, DE, PT.
33635
- TDH-39 supra-aural headphones
- B71 bone vibrator
- Patient response switch
- Plastic cover sheet
- Medical grade power supply
- User Manual
STANDARD ACCESSORIES
- TDH-39 supra-aural headphones
- B71 bone vibrator
(33615/6/8 only)
- Patient response switch
- Clip-on microphone for operator
-to-patient communication
- Jack/jack cable (Ø 3.5 mm) -
33618 only
- Inventis Daisy Patient Record Mana-
ger, with Daisy Maestro module
- Noah Maestro module
- USB connection cable
- Medical grande power supply
- User Manual
STANDARD ACCESSORIES
• 33635 BELL PLUS DIAGNOSTIC AUDIOMETER - air + bone + mask
Bell is a basic diagnostic audiometer performing fast and accurate
air and bone conduction threshold examinations.
Simple operation, fast and reliable automatic examination mode,
user-friendly interface and easy portability make Bell the ideal in-
strument for private clinics, multi-specialist clinics and occupational
medicine application.
- pure tone audiometry in AC and BC
- Hughsone-Westlake auto threshold test
- colour graphic display·
- internal memory for 100 patients
- cost effective solution
- Supplied with air conduction phone and vibrator for bone conduction.
Made in Italy
PICCOLO PORTABLE AUDIOMETERS
Piccolo is a basic diagnostic audiometer offering air, bone and
speech audiometry functions.
Piccolo can be controlled either from a computer running Win-
dows or, for the first time ever, from an iPad
®
.
Lightweight, compact design, powerful, user-friendly software
and Noah connectivity combine to make Piccolo the ideal choice
for professionals on the move.
- three different models available:
Basic
(AC only) for Pc use
Plus
(AC/BC) for Pc or Pc-iPad
®
use (Aero version)
Speech
(AC/BC/Live Speech) for Pc-iPad
®
use
- iPad
®
control (includes Aero option, 33616, 33618 only) through
the Maestro App. Wireless Bluetooth connectivity
- computer control through the dedicated Noah or Daisy
module. USB connection port
Software language:
GB, FR, IT, ES, DE, PL, PT.
Manual:
GB, FR, IT, ES, DE, PL, PT, NL.
- small and light weight
- power supply through the USB
connection, when controlled by
computer.
Made in Italy.
