NEW PRODUCTS
IV
• 33220 SINGLE CHANNEL ECG 100G
- large LCD display waveform and data
- high-resolution thermal printing array system
- frequency response is as high as 150 Hz
- capable of printing continuously on channel trace and
annotations including lead mark and parameter such as
sensitivity, paper speed and filter operation status
- high resolution digital filter inhibits baseline drift without
affecting ECG waveform
- floating input circuit meets IEC safety standard
- rechargeable battery supporting more than 50 patient
examinations
- internal software: GB, FR, IT, ES, DE, TR
- manual: GB, IT (ES on request)
• 33225 RECHARGEABLE BATTERY - spare
• 32968 PAPER ROLL 50 mm x 20 m - box of 20
• 33221 3 CHANNEL ECG 300G
- 3.5" TFT colour LCD screen
- 12 leads simultaneous display
- thermal printing system
- AC and DC power supply
- high capacity built-in lithium rechargeable battery
- battery power supports up to 150 ECG continuous records
- built-in Database
- built-in memory can store more than 1000 cases
- digital signal processor for filter
- auto-measurement, auto-analysis, auto-interpretations
- ECG-Sync software, USB connection to PC
- internal software: GB, FR, IT, ES, DE, TR, PL, PT, RU, KZ
- PC software: GB
- manual: GB, IT (ES, FR on request)
• 33226 RECHARGEABLE BATTERY - spare
• 32969 PAPER ROLL 80 mm x 20 m - box of 10
TECHNICAL SPECIFICATIONS
ECG 100G
ECG 300G
ECG 600G
ECG
instrument
Input
Safety Type
Class I, type CF applied part, which has defibrillation-proof applied part
Lead
Standard 12 leads
Input way
Floating and defibrillation protection
Patient leak current
<10μA
Sampling rate
1000Hz
A/D conversion
12bit
Frequency response
0.05Hz~150Hz (-3dB, + 0.4dB)
Time constant
>3.2s
CMRR
>60dB, >100dB(Add filter)
Enduring polarization voltage
±500mV
Noise level
<15μVp-p
Dispose
Wave Data
EMG interference filter
35Hz (-3dB)
25Hz/35Hz (-3dB)
AC filter
50Hz/60Hz (≥20dB)
Waveform
output
Recording way
Thermal printing system
Thermal printing system (32spots/mm)
Recording paper
50mm(W)×20m(L)
80mm(W)×20m(L)
110mm(W)×20m(L)
Sensitivity
5, 10, 20mm/mV
2.5, 5, 10, 20, 40 mm/mV
Paper speed
Auto-record: auto leads changing
Auto-record: 25mm/s, 50mm/s
Rhythm record: 25 mm/s, 50 mm/s
Manual-record: 25 mm/mV,
50 mm/mV
Manual-record: 5, 6.25, 10, 12.5, 25, 50 (only
33221), 100 mm/mV (only 33222)
Power
supply
AC
110-220V, 50/60 Hz
DC
7.4V, 3700 mAh rechargeable lithium polymer battery
Fuse
2 pcs
φ
5×20mm AC time lag; T250mA/250V(Power Supply:220V)
Form
Size
315 x 215 x 77 mm
Net Weight
2.25 kg
1.7 kg
STANDARD ACCESSORIES
ECG cable - 1 set
Limb electrode clamp - 1 set
chest electrodes - 1 set
Ground wire
Power connection
Paper roll
USB connection and PC
software (only 33221 and
33222)
• 33222 6 CHANNEL ECG 600G
- 7" TFT, colour LCD touch screen
- 12 leads simultaneous display
- digital isolation technology and signal processing solution,
digital filter
- patient management, name, age and id, detail analysis report
- built-in lithium rechargeable battery
- thermal printing system provides more than 10 printing modes
- can print 90 minutes and print out 150 ECG continually
- ECG-Sync software, USB connection to PC and built-in memory
can store more than 1000 cases
- auto-measurement, auto-analysis and auto-interpretation
- internal software: GB, FR, IT, ES, DE, TR, PL, PT, RU, KZ
- PC software: GB. Manual: GB, IT (FR on request)
• 33226 RECHARGEABLE BATTERY - spare
• 32970 PAPER ROLL 110 mm x 20 m - box of 10
33222
33221
33220
DIGITAL SINGLE, 3 OR 3/6 CHANNELS ECG
USB connection allows
real-time transmission to PC,
remote data analysis and
diagnosis, management and
printing through the PC
USB connection allows
real-time transmission to PC,
remote data analysis and
diagnosis, management and
printing through the PC
