DIAGNOSTIC TESTS - LABORATORY
8
24062
• 24051 URILYZER
®
100 URINE ANALYZER - with printer
• 33250 PRINTER PAPER 57 mm x Ø 50 mm - box of 5 rolls
Urilyzer
®
100 is a small urine test strip reader that offers a
broad range of optimized features.
The intuitive user interface improves data entry and allows
manual entry of colour and turbidity from a predefined list or
by an additional comment.
Moreover, the system provides the user with a high level of
customization with flexible testing and reporting options.
The intelligent database-driven data management provides
multiple filter options.
To be used with urine strips 24062 and 24063 only.
CD manual in GB, DE, IT, SE, NO, DK.
24060
24061
24063
• 24069 10 PARAMETER STRIP - tube of 100 strips
• 24071 11 PARAMETER STRIP - box containing 5 pouches of
3 strips
• 24072 11 PARAMETER STRIP - tube of 50 strips
These strip are also compatible with Bayer CLINITEK-100 reader
- global check/screening for general health condition
- measures level of Leukocytes, Nitrite, Urobilinogen, Protein,
pH, Blood, Specific Gravity, Ketone, Bilirubin, Glucose, Ascorbic
Acid (24071 and 24072 only) in 1 strip
- check for healthy nutrition, urinary tract infection, tumors,
kidney damage, gout, fever, cirrhosis, viral hepatitis, liver
disease, congestive heart failure, jaundice, diabetes and acute
renal failure.
For professional use only.
24069
24071
24072
GIMA VISUAL URINE STRIPS
WARNING: SHORT EXPIRY DATE FOR TESTS
. Tests have 24 months expiry at production time. Our stock may vary from 10 to 22 months.
24061
FOR PROFESSIONAL USE
Urine test strips
with ascorbic
acid protection
pad for glucose
and blood tests
TECHNICAL SPECIFICATIONS
Measurements: 50 meas./hour in normal mode 120 meas./hour in fast mode
Memory:
1000 patient test results and 500 QC Test results
Display:
3.5" QVGA Touch-screen LCD
Printer:
Low noise thermal printer with paper roll for about 280 meas
Printout:
Current number measurement, Date and time, Serial No. of
the meter, patient-I-D, Asterisk on pathological results, Para
meters can be printed in Sl-units, Conventional units and
arbitrary units
Accuracy:
Meter adjustment in 5 levels according to individual requirements
Type:
Reflectance photometer wavelengths: 505, 530, 620, 660 nm
Interfaces:
RS232 serial port, USB A, USB B, PS2
(external keyboard, barcode reader), microSD card
Dimensions/Weight: 190x260x77 mm (WxDxH) / 1.5 kg
Power supply: 100-240 V, 50-60 Hz
Made in Hungary
GERMAN TECHNOLOGY
AND ACCURACY
ANALYTICON URINE ANALYZER
AND
URINE STRIPS
Touch screen
intuitive interface
Easy, clean and safe automatic
start of measurement by strip detection
ANALYTICON COMBI SCREEN
®
PLUS and SYS- urine strips
Urine strips for visual test or for use with Urilyzer
®
100 and
CombiScan 100 (24062 and 24063 only).
• 24060 COMBI SCREEN
®
PLUS - 3 parameters - tube of 100 strips
• 24061 COMBI SCREEN
®
PLUS - 10 parameters - tube of 100 strips
• 24063 COMBI SCREEN
®
PLUS - 11 parameters - tube of 100 strips
Results can be
read directly on
the strip (after
about 60 seconds)
and compared
with the label
on the bottle.
Combi Screen
®
Plus offer ascorbic
acid protection
for glucose and
blood tests.
Offers
relevant reduction
of false negatives due to interference with
ascorbic acid
. Supplied in aluminium tube
in single carton box. For professional use.
Manual in GB, FR, GR, IT, ES, PT, NL and
DE available on request.
Made in Germany.
• 24062 COMBI SCREEN
®
SYS - 11 parame-
ters - tube of 150 strips
Same as code 24063 but without ascorbic
acid protection PAD on glucose and
blood.
24051
*
Ascorbic acid protection pad
**
No ascorbic acid protection pad
Leucocytes
Nitrite
Urobilinogen
Protein (albumin)
pH
Blood
Specific gravity
Ketones (acetoacetic acid)
Bilirubin
Glucose
Ascorbic acid
24062
24063
24061
24060
•
•
•
•
•
•
**
•
•
•
•
**
•
•
•
•
•
•
•
*
•
•
•
•
*
•
•
•
•
•
•
•
*
•
•
•
•
*
•
•
•
*
GIMA
code
