DIAGNOSTIC TESTS - LABORATORY
5
Italian English Spanish English
Greek
French Portuguese French
23890 23891 23892 23881
Glucose monitor Plus-meter only
23895 23896 23897 23886
Glucose monitor Plus-kit
ON CALL
®
PLUS GLUCOSE MONITOR
GIMA
code
23910
23912
23913
23914
23915
23919
23917
23916
Glucose Strips - box of 25 strips
Glucose Strips - box of 50 strips
Glucose Strips - box of 100 strips
Control Solution
Auto lancet device "On Call"
Auto lancet device - AST method
Lancets 28G for 23915 - sterile - box of 25 pcs
Lancets 28G for 23915 - sterile - box of 100 pcs
Accessories and consumables for GLUCOSE MONITOR
mg/dL
mmol/L
• 23917 GIMA LANCETS - 28G - sterile - box of 25 pcs
• 23916 GIMA LANCETS - 28G - sterile - box of 100 pcs
Lancets are fine needles that can be used with code 23915,
23919 and most of lancet devices in the market to draw a
blood sample for glucose testing. Multilanguage box: GB, FR,
IT, DE, ES, PT, GR, PL, Arabic.
• 23915 AUTO LANCET DEVICE "ON CALL"
• 23919 AUTO LANCET DEVICE - AST method
Reusable auto lancet plastic device, adjustable tip, allows
precise configuration of lancet penetration.
AST method allows to check blood glucose levels not only on
fingertips, but also on palm, forearm, upper arm.
GIMA
code
SURGILANCE
™
SAFETY LANCETS - NEEDLES
Colour
Depth of
penetration
Blood Flow
Finger Stick
Glucose
Hematocrit
Minimum
order
Gauge
LANCETSANDLANCETDEVICE
ONE-STEP SAFETY AUTOMATIC LANCETS - NEEDLES
Multi purpose capillary blood sampling devices for all testing
requirements. The one-step safety lancet is easier to use, no
arming is required, and safer, once lancet is used it is rendered
inoperable. High-speed delivery and penetration method
minimizes patient pain and operator error.
Latex-free, hypo-allergenic, disposable, sterile.
24515
36598
SAFETYAUTOMATICLANCETS
Advanced technology glucose monitors.
Available as unit only or complete kit.
Kit includes 10 strips, code chip, control solution, 10 sterile
lancets, lancet device, clear cap (for testing on forearm or
palm), carrying case, user manual, logbook.
Main features:
- accurate result in just 10 seconds
- only 1 μl sample size
- automatic calibration with code chip
- plasma calibration results
- advanced data management with 7, 14, 30 days average
- affordable for frequent monitoring
- flexibility to test on the forearm, palm or fingertip
23891
23915
23919
Easy calibration
with chip PLASMA
calibration results
GLUCOSE MONITORS
FOR DAILY DIABETES TESTING
23896
- BIOSENSOR TECHNOLOGY
- 10 SECOND TEST TIME
- ONLY 1 μL BLOOD SAMPLE
TECHNICAL SPECIFICATIONS
Measurement Range 20 to 600 mg/dL or 1.1 to 33.3 mmol/L
Sample Sites - Size
Finger tips, Forearm or palm - 1 μL
Test Time
Approximately 10 seconds
Power Source
One 2032 or equivalent 3.0 V coin cell battery
Battery Life
12 months or approximately 1,000 tests
Memory Plus
Up to 300 records with time and date
Easy sample
application with
capillary action
0123
glucose monitor -
see page 2
24513
Yellow 1.0 mm G26 5-10 μl • • box of 100
24514
Grey
1.8 mm G23 10-20 μl • • box of 100
24515
Orange 2.2 mm G22 20-40 μl • • • box of 100
23916
• 36598 ALCOMED PADS -
box of 100
• 36599 ALCOMED PADS -
carton of 10000 (100 box of
100 pads)
Alcohol saturated pads with
70% isopropyl alcohol for skin
preparation prior to injection.
Bag size 50x50 mm,
folded pad 32.5x30 mm,
open pad 65x30 mm.
ALCOHOL SWABS/PADS
INSULINE PEN NEEDLES SEE PAGE 40
