273
AUTOMATIC VENTILATOR 118
FIRST AID - PARAMEDICAL - EMERGENCY
TECHNICAL SPECIFICATIONS
Drive
100% pneumatic
Ventilation mode
Controlled
Respiration frequency
5 to 35 breaths/min.
Inspiratory-expiratory phase time I:E 1/1.5 ±10%
Flow
2 to 20 l/min adjustable
Oxygen concentration
From 60 to 100%
Safety valve
From 20 to 60 mbar
Vacuum manometer
-20 to +70 mbar
Medical gas power supply
3.5 bar ± 0.5
Non-rebreathing valve
Autoclavable
Connector
15/22
Dimensions
295x160xh 155 mm
Weight
3 kg.
Ambient pressure
600 to 1200 mbar
Structure
Varnished aluminium with exoxy powder
Panel
Permanent polycarbonate
34033
34031
TECHNICAL SPECIFICATIONS
Drive
Electronic
Mode (visual sign)
5-35 BPM
Flow
2 to 20 l/min
I/E Ratio
1:2
Oxygen concentration
60%-100% Patented system
Mechanical overpressure relief 15-60 cm H
2
O - adjustable
Medical gas supply
3,5 bar ± 0,5
Battery operation
Approx. 4 hours
Audible and visual alarms
Low battery - gas supply
Other indications displayed
Medical gas supply
Alarm reset
30 sec.
Manometer
-20 +70 cm H
2
O
Vacuum sensor
Switch
External/Internal source
12 V DC
Dimensions
295x160x155 mm (34030), 455x147x363 (34031)
Weight
3.0 kg (34030), 12 kg (34031).
STANDARD ACCESSORIES
Patient circuit (corrugated tubing with non re-breath valve)
Adult face-mask
Antibacterial filter
Oxygen tube 100 cm - UNI adaptor
2l oxygen cylinder (34034 only)
Guedel canule, tongue holder (34034 only)
Pressure reducer (34034 only)
Aluminium/nylon case (34034 only)
Manual: English, Italian
• 34030 ELECTRONIC VENTILATOR 170
• 34031 KOMPAK ELECTRONIC VENTILATOR
Automatic ventilator designed for: first aid,
ambulances, inter and intra-hospital
transfer of critically ill patients. It is a time
cycled, pressure limited, electronically
controlled ventilator with an intermittent
flow pneumatic unit. It provides stable tidal
volume and respiratory rate. The wide range
of volume and respiratory frequencies allows
use for both children and adults. It is equipped
with a newly conceived mixer which allows a stable
separation between oxygen and ambient air regardless
of the ventilation rate and respiratory pressure. An additional
valve allows the patient to breathe ambient air when the unit
is not operating. The patient circuit is provided with a low
resistant valve, it is autoclavable and easy to use; the non-
rebreathing valve is equipped with a special pressure reducing
device that makes it suitable for both children and adults.
Compact, light-weight, easy to regulate thanks to a clear
interface, provided with alarms it has no parts in motion: thus
it allows patient safety even if used by personnel with limited
training.
Made in Italy.
Kompak ventilator with transport case.
An aluminium and nylon case containing ventilator, oxygen
cylinder with pressure regulator ready for use.
• 34035 CORRUGATED PVC TUBE - 117 cm
• 34036 PATIENT CIRCUIT (valve+corrugated tube)
• 34037 BATTERY
STANDARD ACCESSORIES
Patient circuit (corrugated tubing with non re-breath valve)
Power cable
Oxygen tube
Manual: English, Italian, French
2 l oxygen cylinder (34031 only)
Aluminium/nylon case (34031 only)
Adult face-mask
Battery
UNI adaptor
Pressure reducer (34031 only)
34030
LED for battery condition
and feeding screening
Airway pressure
limit selection
knob
Minute/Volume
selection knob
• 34033 AUTOMATIC VENTILATOR 118
• 34034 KOMPAK AUTOMATIC VENTILATOR 118
Small dimensions sturdy, lightweight, ideal for any
emergency situation: first aid, ambulance, patient
transport. The 118 Ventilator is totally controlled by
intermittent pneumatic time cycled flow pressure
(IPPV) limited thanks to the introduction of a new
oscillator together with a new over pressure valve.
The wide range of volumes and respiratory frequency
permit use for both adult and paediatric patients. The
exclusive system allows stable mixing of oxygen with
atmospheric air at any ventilation/minute, frequency
and insufflation pressure. The compact and lightweight
aluminium shell that has already undergone years of severe
testing permits improved control of the airway pressure
along with easier access for inspection of technicians making
the device safe for use even for those operators without
specific specialisation. Thousands of ventilators already in use
worldwide warrant the reliability of this device. The control
instruments are positioned to allow a clear and immediate
reading in exactly the position you would logically look for
them; indicators are reduced to the essential. Made in Italy.
Kompak ventilator with transport case.
An aluminium and nylon case containing ventilator, oxygen
cylinder with pressure regulator ready for use.
• 34035 CORRUGATED PVC TUBE - 117 cm
• 34036 PATIENT CIRCUIT (valve+corrugated tube)
34034
ELECTRONIC VENTILATOR 170
