FIRST AID - PARAMEDICAL - EMERGENCY
• 34056 MULTIPOSITION AUTO STRETCHER
Multifunctional automatic stretcher for ambulance with easily
adjustable positioning system, for any emergency situation.
The stretcher can bend through 6 different grades, forwards
or backwards. The back of the stretcher is fixed by pneumatic
springs moving in the range of 0 to 60 degrees, also equipped
by front and back fixed supports. It can be locked into place
inside ambulance at proper position. Mattress, belts, side rails,
I.V. stand and fixing devices are included.
TECHNICAL SPECIFICATIONS
Maximum size (LxWxH):
198x53x93 cm
Minimum size (LxWxH):
198x53x34 cm
Packing size:
200x60x35 cm
Load:
159 kg
Net weight, Gross weight:
35 kg, 40 kg
Maximum angle of leaning forwards:
11 degrees
Maximum angle of leaning backwards:
25 degrees
The height scope of touching down (6 grades): 98 cm- 94 cm - 87 cm
77 cm- 60 cm - 34 cm
MULTIPOSITION STRETCHER
TECHNICAL SPECIFICATIONS
Size (LxWxH):
190x57x85 cm
Packing size:
198x60x25 cm
Load:
159 kg
Net weight, Gross weight:
32 kg, 40 kg
• 34070 WHEELCHAIR STRETCHER
Wheelchair stretcher with varied positions.
Lightweight emergency cot quickly
convert to any of four chair positions for
maneuvering in narrow hallways, elevators
and other confined spaces.
Stretcher is made in high quality
aluminium alloy.
Soft foam mattress and protective block
side, rust proof and easy to clean.
Mattress, belts, side rails, IV stand and
fixing device are included.
Leaning backwards
On loading (24 cm)
Leaning forwards
Fixing device
Fixing device
Fixing device in vehicle
• 34055 AUTOMATIC LOADING STRETCHER
Automatic stretcher to load and unload patients from
emergency vehicles, can be moved by only one person.
Specially designed with roll-in system to easily load and unload
patients from emergency vehicle without lifting them. Legs
fold under cot automatically as stretcher is rolled into the
vehicle. Lock-in operating position as cot is removed from
vehicle, left-hand and right-hand control levers unlock front
and back legs respectively so as to be folded when cot is
loaded. Polyethylene covered legs allow cot to roll smoothly
in and out of vehicle. Mattress, belts, side rails, IV stand and
fixing devices are included.
TECHNICAL SPECIFICATIONS
Maximum size (LxWxH):
193x60x88 cm
Minimum size (LxWxH):
193x60x21 cm
Packing size:
195x61x26 cm
Weight:
40 kg
Load:
159 kg
AUTOMATICLOADINGSTRETCHER
WHEELCHAIR STRETCHER
TECHNICAL SPECIFICATIONS
Maximum size (LxWxH):
198x54x93 cm
Minimum size (LxWxH):
198x54x30 cm
Packing size:
218x67x35 cm
Load:
159 kg
Net weight, Gross weight:
39 kg, 45 kg
34056
34055
34072
AUTOMATICMULTIPOSITIONSTRETCHER
34070
• 34072 FULL AUTOMATIC MULTIPOSITION STRETCHER
Full automatic multiposition stretcher.
Easily adjustable to 6 levels for any
emergency situation. Back wards and
forwards reclining, back and foot rest
adjustable to different positions.
Can be loaded into ambulance by one
operator only and locked at desired
position. Structure in high-stength
aluminium alloy. Soft foam surface
mattress, covered by special seamless
welded PVC. Protective block side rust proof
and easy to clean. Mattress, belt, side rails,
IV stand and fixing device are included.
