263
FIRST AID - PARAMEDICAL - EMERGENCY
2 CHANNELS FOR
2 DOUBLE OR SINGLE
CUFF USE
DIGITAL PNEUMATIC TOURNIQUET SYSTEM
RIESTER INFUSION CUFFS
ECONOMIC INFUSION CUFF
• 32684 RIESTER INFUSION CUFF
- 500 cc - latex free
• 32685 RIESTER INFUSION CUFF
- 1000 cc - latex free
Pressure cuff for infusion with
high quality chrome-plated
gauge Ø 49 mm up to
300 mmHg.
Made in Germany.
• 33150 RIESTER PNEUMATIC TOURNIQUET with adult arm and
thigh cuff - latex free bladder
• 33151 CHILD CUFF 38x8 cm - latex free bladder
Reliable pneumatic tourniquet
used during amputations to
restrict blood circulation in
the limbs. It has a robust and
very accurate manometer to
provide exact measurements
and a particularly long service
life.
- sturdy metal pump to
produce pressure
- air in the cuff can
escape by opening the
release valve
- chromium-plated metal
manometer with easy-to-
read aluminium scale up to
700 mmHg.
Pneumatic
tourniquet
includes 2 cuffs
(upper arm cuff
57x9 cm and
thigh cuff 96x13
cm) with latex-
free bladders.
0124
• 32680 INFUSION CUFF -
500 cc
Infusion cuffs similar to above.
Latex bladder and bulb.
Made in Asia.
32680
Sturdy blue cotton
cuff washable at 60°
PNEUMATIC TOURNIQUET
33154
33152
33154
+
33155
33150
2 CHANNELS FOR
2 SINGLE CUFF USE
OR 1 DOUBLE CUFF
USE
cm
80x15
57x15
80x9
52x7.5
40x7
Double
Double
Single
Single
Single
32684
• 33152 DTS-2000S DIGITAL PNEUMATIC TOURNIQUET
2 channels for 2 single cuff or 1 channel for 1 single cuff
• 33154 DTS-2000W DIGITAL PNEUMATIC TOURNIQUET
2 channels for 2 double cuff or 2 single cuff
Both pneumatic tourniquets include 5 cuffs: double cuff 80x15 cm,
double cuff 57x15 cm, single cuff 80x9 cm, single cuff 52x7.5 cm,
single child cuff (40x7 cm)
• 33155 TROLLEY
• 33158 SINGLE CUFF 52x7.5 cm - spare
• 33159 SINGLE CUFF 80x9 cm - spare
• 33160 SINGLE CONE CUFF 70x10 cm
• 33161 SINGLE CONE CUFF 90x12 cm
Max pressure:
600 mmHg
Voltage:
AC 100-240 V ~ 50/60 Hz
Power consumption:
50W
Noise dB:
below 60 dB
Time range:
5~180 min
Compressor dimension/weight: 225x185xh 240 mm / 5.6 kg
Built in lithium battery:
life time 12~72 hours
TECHNICAL SPECIFICATIONS
System features
- automatic pressure control
- 2 channels:
2 ports for 2 single cuffs or 1 double cuff use
(33152)
4 ports for 2 double or single cuff use (33154)
- separate programme settings of 2 channels
- touch key pad controllers: easy checking
and cleaning
- self test of pressure sensor and system check
- self air pressure sensor calibration
- safety alarm system (cuff, pressure,
battery, time checking and alarm sound)
- auto battery power conversion in the
case of sudden AC power failure
5 CUFFS
INCLUDED
33159 33158
33160
