FIRST AID - PARAMEDICAL - EMERGENCY
IV clamp
included
VOLUMETRIC INFUSION PUMP
AUTO SYRINGE PUMP
TECHNICAL SPECIFICATIONS
Flow volume setting range
1~1000 ml/h (1 ml infusion interval)
0.1~999.9 ml/h (0.1 ml infusion interval)
Flow volume error margin
±5%
Infusion limit volume range
1~9999 ml
Total estimated volume range
1~9999 ml
K.V.O rate (Keep Vein Open)
1 ml/h ~ 10 ml/h adjustable
Pump method
Peristaltic method
Size (WxDxH)
100x190x250 mm
Weight
3.5 kg (battery included)
Rapid flow volume (Purge)
1-1000 ml/h adjustable
Bolus
1~1000 ml/h adjustable
Alarm features
Air in line, occlusion, flow error (free flow), door
open, K.V.O. (Infusion completion), standby,
low battery, alarm, device malfunction (CPU error),
empty container (with optional drop sensor)
Special features
Keypad lock, retain memory, remaining time, alarm
repeat, open system, K.V.O., purge, bolus, occ. level,
history call-back.
Power
AC 230V, 50/60Hz and DC9.6V inner source adapter
DC 12 / 24V - 2A Switchable at 110V / 60Hz - with
adapter 35204
Maximum power consumption
40VA
Electric protection levels
Class II B, inner source device, CF type
Waterproof level
IPX2
Battery type
Ni-Cd rechargeable
Battery using time
4 hrs (when infusing 125 ml/h)
Battery recharging time
Minimum 6 hours.
Battery life
approx 6 months
TECHNICAL SPECIFICATIONS
Flow volume setting range
Syringe 10ml: 0.1-300 ml/h
Syringe 20ml: 0.1-400 ml/h
Syringe 30ml: 0.1-500 ml/h
Syringe 50ml: 0.1-1,200 ml/h
Flow volume error margin
±3%
Infusion limit volume range
0.1~999.9ml (0.1 ml infusion interval)
Total estimated volume range
0.1~999.9ml (0.1ml infusion interval)
K.V.O rate(Vein maintaing function)
1-10 ml/h adjustable
Size (WxDxH)
220x130x108 mm
Weight
2 kg (battery included)
Rapid flow volume(Purge)
0.1~1200 ml/h adjustable
Bolus
: adjustable 0.1~1200 ml/h
0.1~1000 ml
Alarm features
Occlusion, K.V.O. (infusion completion),
standby, near empty, low battery, device
malfunction (CPU error), clamp/handle le-
ver/slider disengaged, syringe disengaged.
Special features
Keypad lock, shortcut key, retain me-
mory, remaining time, alarm repeat,
open system, K.V.O., purge, bolus, anti
bolus, occ. level, history call-back.
Power
AC 230V, 50/60Hz and DC9.6V inner
source adapter DC 12 / 24V - 2A
Switchable at 110V / 60Hz - with
adapter 35204
Maximum power consumption
18VA
Electric protection levels
Class II B, inner source device, CF type
Waterproof level
IPX2
Battery type
Ni-MH rechargeable
Battery using time
2 hours
Battery recharging time
Minimum 6 hrs.
Battery life
about 6 months.
0120
• 35205 SYRINGE PUMP SP-8800
SP-8800 provides easy syringe installing through one-touch method
by slider hook, simple and easy setup process with its numerical
silicon keypad. Color LCD displays infusion information dramatically
shortcut key manages easy approach for frequent functions. K.V.O.
rate, purge rate, bolus and anti bolus can be setup as operating
application. Supplied with battery.
Flexible flow volume setting.
Full program dosage feature (optional):
it automatically calculates
flow rate by patient's weight, injection's mass and melting.
Keep Vein Open (K. V. O.) feature:
When reached to the preset value,
it converts to low flow speed of 0.1 ml/h automatically to prevent
flow route clog due to blood coagulation.
Standard compatibility with 6 major brands of syringes:
Setting feature
enables you to choose from following syringe brands: BD, TERUMO, RAYS,
PENTAFERTE, KOVA. Each pump can be calibrated for up to 10 different syringes. Alarm and notification feature: It notifies
errors and emergencies with LED light and buzzer. Simultaneous visual and audio alarm. Occlusion error range setting: You can
set the pressure level of occlusion stage to High, Medium and Low by patient's age condition. Suitable also for VET use.
• 35210 Ni-MH BATTERY- spare • 35204 ADAPTER 110 V - 60 Hz - for 35205
• 35211 DOSAGE AND PROFILE PROGRAM need Serial Number
• 23857 BD SYRINGES 50 ml LL - box of 60 - BD 300865
IV clamp
included
English and
Italian manual
English and
Italian manual
Easy and quick in-
stallation of syringe,
just in five seconds
Automatic set-up system (flow
rate, time, delivery volume)
Colour display
Colour LCD
0120
• 35200 INFUSION PUMP IP-7700
This pump using peristaltic method is a cutting-edge pump realizing high flow precision with
compatibility with I.V. set of various brands through ultrasonic bubble detection.
IP-7700 provides simple and easy setup process with its numerical silicon keypad. FND and
color LCD provides complete information and user gets the information at one glance.
Most infusion condition such as K.V.O. rate, purge rate and bolus can
be setup as operating application. Supplied with battery.
Main features
- Light and compact design:
light as 3.5 kg, compact design, and easy to use.
- Standard compatibility with 4 brands of IV SET:
TERUMO (TS PA 200L), BD
(A122), KOREAN VACCINE, ARIES. Each pump can be calibrated for up to 10 different IV set.
- Flexible flow setting and easy operation method:
Flow-setting range
of 1~1000 ml/h, 0,1~999,9 ml/h is available for wide range settings and numerical
keypad is easy to use for setting flow-volume.
- Full program dosage feature (option):
it can calculate the right flow rate for a patient and
inject promptly.
- Easy recognition of alarm:
it notifies errors and emergencies with LED light and buzzer,
simultaneous visual and audio alarm system.
- Notifying remaining battery:
battery LED is attached to notify charged
battery showing remaining battery and when to recharge.
- Keep Vein Open feature:
when reached preset value, it converts to low flow speed of 3ml/h
(when IV set is 15, 19, 20 drops/ml) or 1ml/h (when IV set is 60 drops/ml) automatically to
prevent flow route clog due to blood coagulation.
- Ultrasonic air bubble detector
- Suitable also for VET use
• 35202 DROP SENSOR - for more accurate dropping control (suggested for ICU and new born)
• 35211 DOSAGE AND PROFILE PROGRAM need Serial Number • 35203 Ni-Cd BATTERY - spare
• 26073 I.V. SET ARIES - box of 150 (6 bags of 25) • 35204 ADAPTER 110 V - 60 Hz - for 35200
Automatic setup system (flow
rate, time, delivery volume)
Numerical silicone key pads
CALIBRATION TO ANY
IV SET BRAND
Please send 5 samples of
your pump use IV set.
Delivery in 40 days
CALIBRATION TO ANY SYRINGE BRAND
Please send 5 samples of your syringe.
Delivery in 40 days
