272
FIRST AID - PARAMEDICAL - EMERGENCY
BASKET STRETCHER
• 34094 TWIN SHELL BASKET STRETCHER - orange
• 34098 BASKET STRETCHER - orange
Robust, resistant and flexible, it is ideal for a wide range
of rescue operations in mines, at altitude and in water. A
revolutionary production technique ensures uniform thickness
of the entire length of the stretcher. The shell is in high-density
polyethylene and is joined to an aluminium framework for better
strength. The handles for transport, integrated in the structure, are placed along the entire
perimeter. The grommets for the fixing of the spring catches of the harnessing are in stainless
steel. Inside the shell there is a removable mattress, applied with Velcro
®
, made in closed-
cell EPDM, which makes it impermeable to both blood and water. High density polyethylene
guarantees shatterproofness and sanitization. It can contain a spine board. Comes with nylon
rope along entire perimeter, three 50 mm nylon belts with quick-release buckles, water resistant
and closed-cell mattress, footrest in pre-formed polyethylene with position regulator.
Twin shell basket stretcher
It can be transversally divided in half to improve the storage and transport. To ensure a
perfect hold between the two shells, have been inserted four nylon cones and a security
system protected by a protuberance placed in the mould itself.
• 34099 LIFTING BRIDLES
Adjustable, can be used for horizontal and vertical patient lifting. Manufactured in durable
woven nylon with sound steel attachment hardware and brass locking mechanism.
• 34100 FLOTATION SYSTEM
• 34096 CARRYING BAG for 34094
FOLDING STAIR CHAIR AND EVACUATION CHAIR
TECHNICAL SPECIFICATIONS
34059
34058
34061
FOLDING EVACUATION
SKID
Height (open/closed):
92 cm
98/78 cm
154/104 cm
Width:
48 cm
41 cm
52 cm
Depth with retracted handles:
59 cm
-
Depth with extended handles: 125 cm
open 80 cm
Depth when folded handles:
19 cm
closed 31 cm
Weight:
10 kg
12 kg
10 kg
Load:
165 kg
116 kg
150 kg
34059
34058
34098+34099
34098
34094
• 34058 EVACUATION CHAIR - orange/chrome
Designed and built for emergency patient removal from confined spaces. Folded it can be stored
in most ambulances. Manufactured from chromed steel with brakes on the front wheels.
Seat cover made of vinyl coated nylon, easily washable. Folds in one
movement, equipped with two quick-release patient restraints.
• 34059 FOLDING CHAIR - black/yellow (orange/chrome on request)
A cost effective choice for moving patients through difficult situations. Four
non-slip grip handles make lifting the patient safer and easier.
Two large rear wheels provide easy manoeuvering. Tough, black, vinyl coated
seat cover easy to clean, resists stain and provides bacteriostatic protection.
Supplied with a set of 3 plastic buckle belts. Made in Italy
• 34061 SKID EVACUATION CHAIR - with braking slide
Skid-Ok a new ultra compact evacuation chair with innovative aluminium
frame and tubular trellis swing fork. New concept materials and components
make the chair lightweight and easy to manoeuvre to offer top performance
in any scenario.
Reclining armrests with rubber finish improve comfort. The innovative self
braking slide system offers the operator total control during the stair
descent. Manufactured in welded aluminium with polished finish.
Adjustable seat strengthened with Spentex
®
.
Skid-OK is supplied with 2x50 mm polypropylene belts. Made in Italy.
34061
Height
open/closed
154/104 cm
WHEELCHAIR STRETCHERS
Adjustable
handle (+30 cm)
TECHNICAL SPECIFICATIONS
Folded size: 91x52x19.5 cm
Open size: 91x52x71 cm
Wheelchair size: - back height: 91 cm - width: 52 cm
- seat height: 48 cm - width: 52 cm
Loading:
150 kg
Weight: 8.5 kg
• 34060 WHEELCHAIR STRETCHER - 2 wheels
• 34074 WHEELCHAIR STRETCHER - 4 wheels
Specially designed for confined areas such as narrow hallways
or multiple landing stairways; anywhere access is seriously
limited. Made in light aluminium with waterproof orange
sheet. Two rearstationary wheels Ø 12 cm (34060) or 4 wheels,
2 with brake (34074) two back handles and four front handles,
2 adjustable 30 cm, facilitate transport on most floor types. 2
quick lock safety belts immobilize patient during transport.
Locking safety latch maintains chair position during use.
34060
34060
Foldable
up handle
Foldable
down handle
TECHNICAL SPECIFICATIONS
34098
34094
Size (LxWxH): 215x65x19 cm 118/215x64x19 cm
Load capacity:
280 kg
280 kg
Weight:
13.5 kg
17 kg
34098+34100
34074
