DIAGNOSTICS
184
GIMA
code
MODULAR DIAGNOSTIC STATION - XENON
31800
Ri-Former Diagnostic station 3.5-230V
*
50/60 Hz-standard
(include 2 handle oto and ophthalmo head, ear specula dispenser, clock)
31805
Ri-Former Diagnostic station 3.5-230V
*
50/60 Hz-large
(include 31800 + sphygmomanometer)
*available on request 120V - 50/60 Hz
RI-FORMER MODULAR DIAGNOSTIC STATION
The modular diagnostic station can be individually combined
according to requirements and the room situation, it is variably
extendable to the right and the left.
The basic ri-former
®
module is available with one handle and
can be supplemented with up to 4 further handle modules.
- 3.5V Xenon or LED illumination creates lighting conditions
similar to daylight
- optimum electronic efficiency using an adjustable dimmer
- constant output voltage independent from the mains supply
prolongs the service life of the lamps and guarantees
optimum light intensity
- automatic switching on/off of handles when
removing or replacing them in the handle unit
saves energy and increases the service life of
the lamps
- non-slip, ergonomically designed handles with
rheostat: infinitely variable regulation of
brightness as well as manual switching on/off
possible on the handle
- spiral cord expandable up to 3 m
- developed and manufactured in Germany.
MODULAR DIAGNOSTIC STATION - LED
RI-FORMER MODULES AND HEADS
RI-FORMER
®
THE MODULAR DIAGNOSTIC STATION 3.5V
31815
Set 31800 or 31801
Set 31805 or 31806
31822
31809+31812 31810+31813 31820
Made in Germany
31809
31811
31813
For up to
5 handles
Clinical validation
Memory for 12
measurements
31823
LED illumination: bright, white light with a nearly unlimited lifetime!
With its monochromatic white light (5500° Kelvin) the lamp in
the ri-scope
®
L provides cold light and true-color.
Lamps with LED technology have a lifetime of at least 10,000
hours (compared to 20-30 hours with halogen and Xenon
lamps) and are extremely energy-efficient.
Li-ion batteries - greatest power in the smallest space!
Considerably higher charging capacity, longer lifetime, light-
weight, these are the big advantages of Li-ions batteries;
wich provide sustained high performance for up to 1200
charging cycles. LEDs powered by lithium batteries can burn
for up to 50 hours.
• 31830 RI-SCOPE L2 F.O. LED OTOSCOPE - 3,5 V
The newest generation ri-scope
®
L otoscopes
with optical glass
and reduced reflection
combines excellent optical properties
and unparalleled performance with the reliability and
efficiency of LED/lithium-ion technology.
- Fibreoptics for optimal beaming and transmission of the light.
- Bi-directional swivelling, sealing optical glass 3X
31830
31832
31840
31834
31830
RI-SCOPE
®
L: LED + Li-Ion BATTERIES
Table recharge station (with wall holder)
recharge 2 ”C“ handles with Li-Ion batteries.
- Suitable for pneumatic test (supplied without ball).
- C handle runs Li-Ion batteries, not included.
Supplied in deluxe hard case with one spare lamp, 4 reusable
ear specula and 3 disposable ear specula.
Spare ear speculum: use above 31817-31819 (autoclavable) or
31485 to 31499 (disposable) page 190.
• 31832 RI-SCOPE L2 XENON OPHTHALMOSCOPE - 3,5 V
The enhanced basic model with separately engageable red-
free, blue and polarization filters for each aperture.
- Diopter wheel with 29 corrective lenses Plus 1-10, 12, 15, 20, 40
Minus 1-10, 15, 20, 25, 30, 35
- Easy-to-operate aperture hand-wheel with semi-circle, small/
medium/large circle, fixation star, and slit
- Includes filter wheel engageable for all apertures with symbol
display, red-free filter, blue filter and polarization filter
• 31826 XENON L1/L2/L3 OPHTHALMOSCOPE BULB 3,5 V - spare
• 31834 RI-SCOPE L2 LED OTOSCOPE + L2 XENON
OPHTHALMOSCOPE 3.5 V - C handle
• 31841 ”C“ SIZE Li-Ion BATTERY
• 31840 RI-CHARGER L 230 V
31809
Basic diagnostic station 1 handle 3.5 - 230V
*
50/60 Hz
31810
Extension module 1 handle
31811
Ri-scope L2 F.O. otoscope head - Led 3.5V
31812
Ri-scope L1 otoscope head - Xenon 3.5V
31813
Ri-scope L1 ophthalmoscope head - Xenon 3.5V
31814
Ri-scope F.O. retinoscope head - Xenon 3.5V
31815
Ri-scope F.O. dermatoscope head - Led 3.5V
31817
Ri-scope L1, L2 ear speculum Ø 2.5 mm
*
- autoclavable 134°C
31819
Ri-scope L1, L2 ear speculum Ø 4 mm
*
- autoclavable 134°C
31820
Ri-spec ear specula dispenser - specula not included
31822
Sphygmomanometer with basket
31823
Ri-thermo N infrared thermometer with 40 covers
31824
Probe cover for 31823 - box of 100 - spare
31825
Xenon L1 otoscope bulb 3.5V - spare
31826
Xenon ophthalmoscope L1, L2, L3 bulb 3.5V - spare
31801
Ri-Former Diagnostic station 3.5-230V
*
50/60 Hz-standard
(include 2 handle, LED oto and ophthalmo head, ear specula dispenser, clock)
31806
Ri-Former Diagnostic station 3.5-230V
*
50/60 Hz-large
(include 31801 + sphygmomanometer)
*available on request 120V - 50/60 Hz
31814
Red-free
filter
Slit, Fixation star, large circle,
medium circle, small circle, semi circle
Blue filter Polarization
filter
*Box of 10
