DIAGNOSTICS
183
• 31841 ”C“ SIZE Li-Ion BATTERY
• 31840 RI-CHARGER L 230 V
31836
31836
Table recharge station (with wall holder)
recharge 2 ”C“ handles with Li-Ion batteries.
E-SCOPE
®
: RIESTER OTO-OPHTHALMOSCOPES
RI-SCOPE
®
SLIT XENON RETINOSCOPE
• 31550 E-SCOPE
®
OTOSCOPE - XENON 2.5V - black in pouch
• 31552 E-SCOPE
®
F.O. OTOSCOPE - LED 3.7V - white in rigid case
E-scope otoscope are available with direct xenon halogen illu-
mination or F.O. LED.
- Sealing precision optics pivoting to both sides with
triple magnification for superior view
- Compatible with ear specula from other major brands
- Suitable for performance of pneumatic tests (sup-
plied without connector and insufflator)
- Available in black or white finish
• 31556 E-SCOPE
®
OPHTALMOSCOPE - XENON 2.5V -
black - in rigid case
• 31557 E-SCOPE
®
OPHTALMOSCOPE - F.O. - LED 3.7V
- white - in rigid case
E-scope ophthalmoscopes are available with xenon
or LED illumination.
- with 2.5V halogen illumination and with innovative 3.7V LED
illumination for higher-contrast and more efficient diagnosis
- dioptre disc with 18 corrective lenses
(± 1,2,3,4,6,8,10,15,20 dioptres)
- easy-to-use aperture wheel with six different apertures
(fixation star, large circle, small circle, red free filter, blue filter,
semi circle)
- high performance optics with aspherical condenser
- spectacle protection
- parallel optical path
- dust-protected
• 31558 E-SCOPE
®
DIAGNOSTIC KIT
Oto-ophthalmoscope set, LED 3.7V, white colour, in rigid case.
• 31560 E-SCOPE
®
OTOSCOPE - XENON 2.5V BULB
• 31561 E-SCOPE
®
OTOSCOPE - LED 3.7V BULB
• 31562 E-SCOPE
®
OPHTHALMOSCOPE - XENON 2.5V BULB
• 31563 E-SCOPE
®
OPHTHALMOSCOPE - LED 3.7V BULB
• 31836 RI-SCOPE SLIT XENON RETINOSCOPE - 3,5 V - C handle
Ri-scope retinoscope measures the refractive power of the eye.
The slit-light retinoscope with a light beam in the form of a line,
simplifies detection and diagnosis of astigmatic refractive flaws,
such as near and far-sightedness, as well as astigmatism.
The reflex in the form of a line is moved vertically to the axis across
the pupils of the patient with a slight oscillating movement.
A shadow moves in the same or opposite direction.
Co-movement (plus lines): the patient is far-sighted.
Counter movement: the patient is near-sighted.
Easy to operate with knurled thumb screw.
The line image can be focused with the controls and turned 360°,
angle read-out displayed on the integrated scale.
Supplied with two fixation card for dynamic retinoscopy, one spare
bulb in a deluxe hard case with safety catch.
31552
31556
Dioptre
adjustment
wheel
Reusable
speculum
(for disposable
speculum see
page 190)
3x magnifying pivoting lens
31558
Fixation bar Large circle Small circle Red free filter Blue filter
Semi circle
31550
31557
INNOVATIVE LED
3.7V ILLUMINATION:
- real colour 5,500K white light
- long life LED bulbs: up to
20,000 hours
- low battery consume: up to
50 hours operation through IPC.
IPC (Integrated Power conver-
ter) converts the voltage of
conventional AA size batteries
into the optimum voltage
required for LED
Bulb life
Xenon
Xenon LED
LED
20 h
20000 h
50 h
3 h
Battery life
(2 x alkaline)
Halogen
LED
Dioptre display
Aperture
wheel (back)
Made in Germany
Made in Germany
