MEDICAL LIGHTS
176
• 72562 VIDEODERMATOSCOPE+SOFTWARE
• 72564 DENTAL SCOPE+SOFTWARE
• 72566 USB CAMERA for MICROSCOPE/COLPOSCOPE+SOFTWARE
A line of pocket, portable digital
microscopes for diagnostic applications
in laboratory, colposcopy, dermatology
and dental fields. Suitable to capture
photograph, video or time-lapsed video
with a click of a button.
Save file format in jpg, bpm or avi.
Multilanguage manual: English, Italian,
Spanish, French, German.
TECHNICAL SPECIFICATIONS
Resolution: 1.3M pixels
Adjustable Magnification: 72562: 10X-50X, 200X
(continuous magnification without changing lenses)
72564: 20X-30X
(continuous magnification without changing lenses)
Illumination: built in 6 or 8 white LED (ON/OFF controlled by software)
Frame rate: up to 30fps, 15fps at 1.3M pixel
Interface: USB (PC) 2.0
Polarized: ON/OFF
DinoCapture multilanguage software included (English, Italian, Spanish,
French, Greek, Portuguese, German, Arabic, Chinese, Romanian, Polish,
Japanese, Swedish, Thai)
Size: 10x Ø 3.2 cm - weight: 95g
PRODUCT REQUIREMENT
Compatible with Windows 2000/XP, Vista, Win7 and MAC X computers (10.4 or further)
256MB RAM
CD-ROM drive
Hi-speed USB 2.0 port
PORTABLE DIGITAL MICROSCOPES
72562
0068
Accurate measurement
and calibration capability
Includes two big contact
caps and one stand
72566
72564
Mirror not included
0068
Universal configuration
suitable for most microscope
and colposcopes
TECHNICAL SPECIFICATIONS
Length long wave 360 nm
Norms: CEI 62-5, IEC 601-1, CE 93/42/EEC
Operating voltage: 230 V-50 Hz (60 Hz on request)
(not available at 110 V)
• 31189 POCKET WOOD LIGHT
Pocket ultraviolet light, to detect skin disorders.
Also provided with replaceable fluorescent lamp. Power 6 V.
Works with 4xAA batteries with 4-6 hours autonomy.
• 31190 FLUORESCENT BULB - spare
Size: 16 x 5 x 2 cm
Arm
length
40x40 cm
31189
ECONOMIC WOOD LAMP POCKET WOOD LIGHT
WOODBLUELIGHT
VISTAWOODBLUE LIGHTS:
TROLLEYANDMANUAL
93/42/EEC
93/42
• 31191 WOOD BLUE LIGHT - manual
Special blue fluorescent light for
the detection of details and colours
invisible under normal light system.
Made in Italy.
• 31193 1.5XMAGNIFYING LENS - optional
• 31194 NEON BULB 6W - spare
(210x Ø 25 mm)
• 31196 VISTA WOOD LAMP - handle
• 31197 VISTA WOOD LAMP - trolley
A Wood lamp is a diagnostic tool to diagnose
the condition of skin. Different skin conditions
under ultraviolet rays of the Wood lamp
appear in different colours. These new models
have polishead glass magnifying lens 10.5x7 cm
- 3 dioptres.
9W special compact fluorescent at
approximately 360 nm wavelength.
Operating voltage: 230 V - 50 Hz.
Manual in GB, FR, IT, ES, PT, DE.
Made in Spain.
Upper and
lower side of
Vista Wood
lamp
31197
31200
31196
• 31200 WOOD LAMP
Ultraviolet light for skin condition diagnosis and analysis.
Size 30x21x7 cm. Made in China.
