MEDICAL LIGHTS
175
• 30737 LOUPE LED
MAGNIFYING LIGHT
Smartly designed cold light
LED lamp with 5-dioptres
magnification.
5 wheels base and articulated
arm allow easy movement.
Manual in GB, FR, IT, ES, PT, DE
Made in Europe.
• 30736 DERMALED
MAGNIFYING LAMP
Cold light LED lamp with
5-dioptres magnifying lens
and brightness adjustment.
It comes with a high stability
5 wheels base and an
articulated arm for easy
movement and fixing of the
lamp.
Suggested for dermatology
and beauty treatments.
Made in China.
Heigth
50+50 (arm) +
95 cm (trolley)
TECHNICAL SPECIFICATIONS
Type of light:
LED
Dioptres:
5
Lens:
Ø 12.7 cm
Operating voltage: 230 V - 50 Hz
Class II
Electrical security: UNI EN 60601-1
(1990)
Electromagnetic compatibility:
EN 60601-1-2
(1993)
TECHNICAL SPECIFICATIONS
Type of light:
LED
Voltage:
8 W
Dioptres:
5
Operating voltage: 100-240 V - 50/60 Hz
Net/Gross weight: 10-12 kg
93/42
30740
SOLENORD
Suggested for dermatology.
It is equipped with a biconvex optical
magnifying glass diameter 120 mm.
The cold fluorescent light allows
prolonged use. Light source protection
in plexiglass. Spring arm and 5 castors
trolley allow easy adjustability.
Fluorescent round lamp 230 V.
Made in Italy.
MAGNIFYING FLUORESCENT COLD LIGHTS -
3 DIOPTRES
GIMANORD
Magnifying glass self-illuminating
fluorescent cold light 3 dioptres (0.75X).
Suggested for dermatology, it is
equipped with a biconvex optical
magnifying glass Ø 120 mm. The cold
fluorescent light allows prolonged use.
Polycarbonate screen for protection of
the light source. Available also with wall
support. Made in Italy.
Magnifying glass
Ø 120 mm
30750
30751
Model
SOLENORD
GIMANORD
Type of lighting
fluorescent
Consumption (Watt)
22
Life of the bulbs (hours)
6,000
Light intensity at 50 cm (lux)
550
Light intensity at 1 m (lux)
275
Colour temperature ± 5% at 1 m (K)
4 550
External diameter of the reflector (Ø mm) 230
Temperature increase at 1 m (°C)
0
Norms SOLENORD
IEC-601-1
Norms GIMANORD
IEC-598-2-25
Marks SOLENORD
CE 93/42
Marks GIMANORD
CE 2006/95
Weight (kg)
7
Operating voltage V-Hz
230 - 50
Adjustment height with castors base:
min-max cm
60-180
SOLENORD on trolley
SOLENORD wall
GIMANORD desk model - with clamp
GIMANORD on trolley
Spare fluorescent lamp - 22W
Spare plexiglass shield
Trolley - spare (A)
Wall connection (B)
Rail connection with clamp (C)
Table connection (D)
30740
30741
30750
30751
30767
30771
30769
30774
30775
30776
GIMA
code
MAGNIFYING LIGHTS
SPARES AND FIXING SYSTEMS
FIXING SYSTEMS
On request we can supply all lamps with wall,
table or rail (1,000 mm) connection
FIXING SYSTEMS
On request we can supply all lamps with wall, table or
rail (1,000 mm) connection
Trolley
Rail
Wall
B
Table
30736
30737
LED MAGNIFYING LAMP
- 5 DIOPTRES
Power supply unit integrated in the base with double
safety fuse, lead retainer with spiral protection and
bipolar light switch with green indicator light.
93/42
