DIAGNOSTICS
179
Adjustable focus wheel
allows to
accomodate for variable ear canal lengths
and farsighted eyes a full view of the
tympanic membrane
WELCH ALLYN MACROVIEW
™
OTOSCOPE
WELCH ALLYN PANOPTIC
™
OPHTHALMOSCOPE
HEINE OMEGA
®
500
INDIRECT OPHTHALMOSCOPE
• 32100 MACROVIEW
™
HEAD - 23810
• 32101 LITHIUM ION HANDLE WITH AC CHARGING MODULE
3.5 V - 71902
This next-generation otoscope features advanced optics that
increase magnification while giving you a nearly full view of
the tympanic membrane - virtually eliminating the need for
panning. With its easy-to-focus eyepiece, MacroView allows
for enhanced visualization to help see past wax, locate fluid
behind the eardrum, and even perform exams without your
glasses.
- twice the field of view
- 30% greater magnification than a traditional otoscope
- nearly a full view of the tympanic membrane
- better clarity and definition of landmarks
- ability to adjust focus for variable ear canal lengths or
farsighted eyes
• 32106 KLEENSPEC
®
ADULT DISPOSABLE EAR SPECULA
4.25 mm - box of 850 pcs - 52434-UB
• 32105 KLEENSPEC
®
PEDIATRIC DISPOSABLE EAR SPECULA
2.75 mm - box of 850 pcs - 52432-UB
• 32135 SPARE HALOGEN BULB - 3.5 V - 06500 U
32100
32101
Default focus position
(the dot and the line)
Insufflation port
for
pneumatic otoscopy
Tip grip
ensures ear specula is fastened
securely and easily disposed
Advanced optics
give you 2X the field
of view and 30%
greater magnification
than a conventional
otoscope
Patented Axial PointSource™
Optics
: makes it easy to enter
undilated pupils, and provides a
25° field of view, resulting in a
view of the fundus that’s 5 X
greater than you see with a
standard ophthalmoscope in an
undilated eye
Patient Eyecup
:
establishes and
maintains proper
viewing distance,
provides image stability,
serves as a pivoting
point for panning
around the retina, helps
with orientation, and
screens out ambient
light. The eyecup is
cleanable and reusable
Dynamic
Focusing Wheel
:
adjusts the focus
in a continuous,
smooth action
for more precise
control and
optimum view.
Available focusing
range is -20 to
+20 diopters
PanOptic Soft
Grip
:
ergonomically
designed for
maximum comfort,
balance, and access
to controls.
Aperture Dial
: allows you to select
micro, small, and large spot sizes. Also
includes red-free filter and slit aperture,
half-moon aperture for corneal exams
Halogen HPX™ Lamp
:
provides whiter, brighter light
Glare Extinguishment
System
: prevents
interference from unwanted
glare and reflections
Welch Allyn 3.5 V Power
Sources
: compatible
with any standard 3.5 V
power source including:
desk charger handles,
convertible battery handles,
wall transformers and the
Lithium Ion Power Handle
5X
FIELD OF VIEW
Larger view
of the fundus
• 32110 PANOPTIC OPHTHALMOSCOPE HEAD - 11810
• 32101 LITHIUM ION HANDLE WITH AC CHARGING MODULE
3.5 V - 71902
PanOptic is a breakthrough concept in ophthalmoscopy. Thanks
to an innovative, optical design known as Axial PointSource™
Optics, it will greatly enhance your funduscopic examinations.
- fast easy entry into small, undilated pupils
- 5 X larger field of view than you see with standard
ophthalmoscopes in an undilated eye
- 25° field of view versus the 5° field of view of standard
ophthalmoscopes
- a 26% increase in magnification, making it easier to see
retinal details
- greater distance between
practitioner and patient means
greater comfort for all
• 32127 SPARE HALOGEN BULB
- 3800 U
Lithium-ion
handle with AC
charger module
compatible with
all Welch Allyn
instrument heads
3.5 V
PanOptic
Ophthalmoscope
Standard
Ophthalmoscope
• 31753 HEINE OMEGA 500 XENON-HALOGEN INDIRECT OPHTHALMOSCOPE 6V - C-044.33.539
With mPack pocket battery, plug-in transformer, headband rheostat and 90° angled adapter
- clearer, crisper views:
a new illumination system with Xenon Halogen Technology bulb produces less reflexes off
the cornea and clear, high resolution bright images of the fundus.
- enhanced variable pupil function:
allows for the precise, synchronized selection of observation and
illumination optics for any pupil size. This patented system has been optimized and will now provide
stereopsis in pupils ranging from 10 mm down to 1 mm.
-
fully featured:
3 Spot sizes: Large, Medium and Small. Integrated diffused light filter.
3 Integrated Filters: Red-free, Cobalt Blue, and Yellow.
-
Omega headband comfort:
articulating Rear Hinge provides vertical adjustment of the rear
band of the headband for individual placement.
• 31754 HEINE OMEGA 500 UPGRADE KIT from XHL to LED for 31753 - X-008.16.325
With this kit, an XHL OMEGA
®
500 can be easily converted to LED
• 31756 HEINE OMEGA 500 UNPLUGGED LED HQ INDIRECT OPHTHALMOSCOPE 6V -
C-008.33.535
With mPack battery integrated in headband, plug-in transformer, headband
rheostat and 90° angled adapter. Same feature as 31753 with:
- LED technology:
absolutely homogeneous, uniform illumination, up to 100% brighter
compared with XHL (xenon technology)
- rechargeable battery integrated
on the headband
- mPack rechargeable battery:
charging time 2 hours, operating time 8 hours
Light weight
only 450g
