MEDICAL LIGHTS
174
30754 LUXIFLEX on trolley - halogen
30756 LUXIFLEX on trolley - LED
Stylish and versatile light for
examination and minor surgery
procedures in health-centres, clinics and
hospitals. Suitable also for veterinary
examinations and procedures.
Safe low voltage operation with
electronic transformer lodged at the
bottom of the lamp. Flexible arm and
5 castors trolley allow easy use and
movability. Class II. Made in Europe.
30757 SPARE BULB LUXIFLEX - halogen
30742 MINIMED ON TROLLEY - halogen
30743 MINIMED ON TROLLEY - LED
Low voltage and high definition, intense
light. Flexible arm for versatile use.
Supplied on a sturdy 4 castors stand for
easy movability. Made in Italy.
30744 SPARE BULB - 50 W - halogen
50,000 LUX - Halogen
15,000 LUX - LED
30775
HALOGEN AND LED LIGHTS
FOR EXAMINATION ANDMINOR SURGERY
Rail
Wall
B
Table
30747 SOLESUD 2 on trolley - halogen
30748 SOLESUD 2 wall - halogen
Suitable for gynaecology, examination
and head-bed. Aluminium reflector
equipped with 2 halogen dichroic
bulbs, 20W 12V 10° IRC protected by
a tempered glass, hermetically sealed
against dirt and fluid spray and with
ergonomic handle for movement.
Bulbs switch on simultaneously and, in
case one breaks, light is always assured.
Arm movement servo-assisted by a
torsion spring provide lightweight
movement and stability of position.
A light beam of 180 mm diameter at
a distance of 50 cm allows precise and
reliable examinations.
Base with 5 rotary spokes, 900 mm high.
3 Pin British Plug available on request.
Made in Italy.
30769 SPARE TROLLEY - base Ø 61 cm
30775 RAIL CONNECTION WITH
CLAMP
30764 SPARE BULB SOLESUD 2 - 20 W
B
30742
30742
20,000 LUX
30743
Model
SOLESUD 2
SIMPLEX
LUXIFLEX
MINIMED
Type of lighting
halogen
halogen
LED
halogen LED
halogen LED
Consumption (Watt)
2x20
35
3x1.4
35
10
50
12 (4x3)
Life of the bulbs (hours)
5,000
5,000
50,000
5,000 25,000
Light intensity at 50 cm (lux)
40,000
30,000
35,000
50,000 15,000 38,000 20,000
Light intensity at 1 m (lux)
8,000
8,000
13,000
-
-
-
-
Colour temperature ± 5% at 1 m (K)
3,000
3,000
4,200
4,000 3,000
3,100
6,500
Light field size at 50 cm (Ø mm)
180
100
140
ExternalØ ofthereflector (mm)
104
105
86
Colour
white
white
white
white white
white
white
Norms
IEC 60601-1 IEC 598-2-25 IEC 60601-1 EN 60601-1-2
IEC 60601-1
Marks
CE 93/42
CE 2006/95 CE 93/42
CE 93/42
CE 93/42 CE 93/42
Weight (kg)
6
5
5
9
9
Operating voltage V
230
230
100-240
230
230
Operating Hz
50/60
50
50/60
Operating voltage on request V-Hz
110 - 50/60
110 - 60*
-
*minimum 50 pcs.
30760 SIMPLEX on trolley - halogen
30761 SIMPLEX wall - halogen
30762 SIMPLEX table with clamp
Versatile lamp equipped with a halogen
dichroic bulb 35W 12V placed inside the
aluminium reflector and protected by a
tempered glass. Electronic transformer
integrated in the base with lead
retainer with spiral protection and
bipolar light switch with green indicator
light. The flexible arm (60 cm) ensures
easier light positioning and is covered
with a smooth white shrink-wrap sheath
for easier cleaning and disinfection.
30759 SIMPLEX on trolley - LED
Thanks to three independent light
sources shadow can be reduced and
provide a deep cylindrical light with
highly reduced heat irradiation.
Each LED integrates a resistance to
ensure the continuous operation of
the lamp even in the rare case of a LED
fault. Other specifications as halogen
model. Made in Italy.
30766 SPARE BULB SIMPLEX - IRC 35 W
30768 SPARE TROLLEY - base Ø 61 cm
30775 RAIL CONNECTION WITH
CLAMP
B
D
30347
40,000 LUX
WITH 2 BULBS
Manual in:
GB, FR, IT, DE, ES, PT
30754
Height 50 cm
(arm) + 95 cm
(trolley)
Adjustable
height
60-160 cm
Electronic transformer integra-
ted in the base with double
safety fuse
30747
30760
Adjustable
height
60-160 cm
30759
30760
35,000 LUX
LED
30,000 LUX
HALOGEN
