DIAGNOSTIC TESTS - LABORATORY
11
• 24502 SALIVA ALCOHOL TEST STRIPS - box of 25 strips
GIMA Saliva Alcohol Test Strip is a rapid highly sensitive test
for the determination of relative blood alcohol concentration
in saliva specimens.
- results in just 2 minutes
- color chart provides approximate relative
blood alcohol concentrations (BAC)
from 0.02% to 0.30%
- no instrumentation is required
- saliva testing avoids urine collection
- short expiry date (average 8-10 months)
- professional use
SALIVA ALCOHOL STRIPS
24502
• 24491 FIT-133 ALCOHOL TESTER with printer
• 24494 BLOWING TUBES -
box of 100 pcs.
• 24495 PAPER ROLLS for 24491 - box of 10
Professional
fuel cell sensor
breath alcohol
tester with printer and touch screen.
The fuel cell is a porous disk with a thin
layer of platinum black on both faces and
any alcohol that comes in contact with the
cell's surface is broken down chemically.
For each molecule of alcohol that is broken
down a given number of electrons are freed
during the process.
The numbers of electrons generated are in
proportion to the amount of alcohol.
BREATH ALCOHOL TESTER PROFESSIONAL
ALCOHOL TESTER
24503
24500
SELF MONITORING
Large display to read
exact value of
your breath
(3 colour backlight)
TECHNICAL SPECIFICATIONS
Range: Low & 0.15 ~ 1.50 ‰ BAC or 0.075 ~ 0.75 mg/l
Accuracy: ±0.2‰ BAC full range under alert level
Battery: 3 x 1.5V AAA batteries (not included)
Display: Graphic & Digital display with 3 decimal points (eg. 0.025%BAC)
Tolerance compensation: Pre-alert function together with tri-colour backlighting
Breath sampling: less than 5 seconds continuous breath sample
Recycle time: about 20 seconds
Unit Dimensions: 107x45x25 mm approx.
Weight: 50g (without batteries)
Alert level calibrated: 0.5 ‰ BAC or 0.25mg/l
• 24500 ALCOHOL TESTER
Compact device to measure your alcohol
concentration in your breath.
Digital/graphic interface and animation,
one-hand operation.
‰ BAC and mg/l values.
Supplied in carton box with 3 blowing
tubes Ø 7 mm and one cleaning cap.
• 24501 BLOWING TUBE - box of 12 pcs.
• 32200 "AAA" BATTERIES -
blister of 4 pieces
• 24503 COUNTER DISPLAY - Italian
• 24504 COUNTER DISPLAY - English
TECHNICAL SPECIFICATIONS
Display:
Colour 3.2 TFT LCD with touch screen and grafic waveform
Keyboard:
5 keys operation: "Up", "Down", "Left", "Right", "OK"
Power Supply:
Rechargeable AA battery (about 2500 mAh)
Heat warm up:
Chamber & Sensor warm up automatically
Auto flow monitoring: Flow detect automatically
Storage environment:
-40 Degree C to +85 Degree C
Operating environment: -20° to +70°. (optimal -20° to +40°)
Record PC download:
PC Download through USB cable (CSV file)
Compatibility:
Windows XP, 7
Memories:
10,000-18,000 memories for approx 3,000 full tests:
drive name, vehicle number, inspector name, test result
with stamp data and time, location, calibration data, ...
Measurement precision: Standard deviation ±0,025 mg/L or ±5%
of the measurement
Drift: typically <0,8% of the measurement value/month
• 24499 POCKET ALCOHOL TESTER
Pocket, easy to use alcohol tester
POCKET ALCOHOL TESTER
TECHNICAL SPECIFICATIONS
Range: Low & 0.2 ~ 1.5 %BAC
Accuracy: ± 0.2‰ BAC at the calibrated point (alert level)
Power input: 2 x 1.5V AAA batteries (not included)
Display: Digital display
Tolerance compensation: pre-alert function when close to
alcohol limit
Auto power off: 2 minutes
Breath sampling with auto flow detect: about 6 seconds
continuous breath sample
Cycle time: about 20 seconds
Alert level calibrated: 0.5% BAC
POCKET,
ONLY
8.5x3x1 cm
Size: 188x78x33 mm
Weight: 300 g
Counter display
fits 6 tester
1
7
4
5
2
3
6
9
10
11
12
• 24564 DRUG KOP - box of 1 test
• 24565 DRUG KOP - box of 10 tests
A new colorimetric test to screen out quickly and accurately the major substances contained in
illicit drugs and some pharmaceuticals.
This test measures and detects the following 21 DOA with concentration of 5 mg: Amphetamine,
Benzphetamine, Cocaine, Codeine, Dextromethorphan, Diphenhydramine, Doxylamine, Heroin,
Hydrocodone, Ketamine, LSD (containing a secondary amine), Mephentermine, Methadone,
Methamphetamine, Morphine, Opium, Phencyclidine (PCP), Promethazine, Thebaine, Tryptamine,
Tyramine. Not suitable for Cannabis.
Test can be performed in surfaces and drinks
, it does not require reagents and gives immediate results.
Very stable from - 15°C to 50°C.
WIPE DRUG TEST FOR HOME CARE USE
SELF MONITORING
24564
1. Saturate the
reaction pad
2. Read results in
2 minutes
24502
Alcohol tester
1
is supplied
with integrated printer,
25 mouth pieces
2
,
1 large mouth piece
3
,
power supply
4
, power sup-
ply 100-240V, 50/60 Hz
5
,
USB car adaptor
7
, wireless
transmission module for
FIT-133 printer
6, 9
, carrying
pouch
10
, 4 rolls of paper
11
,
charger
12
.
