DIAGNOSTIC TESTS - LABORATORY
13
• 31001 BIOLOGICAL MICROSCOPE - 40X to 1600X
High level microscope with high resolution and transmission
Main features:
- compensation-free binocular head
- eyepiece WF 10X, P16X
- semi-plan achromatic objectives 4X, 10X, 40X (s), 100X (s, oil)
- quadruple nosepiece
- mechanical stage double layers 140x140 mm /
movement range 75x50 mm
- power supply: switchable110-220 V, 50 Hz
• 31005 SPARE BULB (for 31000 and 31001)
• 31000 BIOLOGICAL MICROSCOPE - 40X to 1000X
- 30° compensation free binocular head
- eyepiece 10X (Field 18 mm)
- achromatic objectives 4X, 10X, 40X(S), 100X (S, oil)
- total magnification 40X, 100X, 400X, 1000X, depending on objective
- interpupillary distance adjustment: from 55 to 75 mm
- mechanical stage, double layers 125x135 mm
- movement range: 75x35 mm
- Abbe condenser with iris diaphragm and filter
- halogen lamp 6 V, 20 W - brightness adjustment
- power supply: switchable110-220 V, 50 Hz
• 31005 SPARE BULB (for 31000 and 31001)
Fine focusing knob
Binocular
system
Quadruple
nosepiece and
objectives
31000
Fine focusing knob
minimum division
0.002 mm
Large Operating Space with
Backwards Nosepiece.
Sharp Image with high quality objectives.
Easier comparison test with dual
slides finger of mechanical stage.
Precise focusing system.
BIOLOGICAL MICROSCOPES - MAGNIFICATION 40X-1600X
• 24035 XC-2000 CENTRIFUGE
Very silent centrifuge with 6 tube positions, provided with
electronic counter to allow precise speed setting from 1000 rpm
to 4000 rpm (500 rpm increments). It is supplied with metal
holder for 6 tubes of 10 ml and holder for 6 tubes of 15 ml.
Operating time is adjustable from 1 to 60 min.
Strong ABS structure.
• 24040 TEST TUBE 10 ml
box of 100 pcs
• 24031 UNIVERSAL CENTRIFUGE - 8 tubes fixed rotor
• 24032 UNIVERSAL CENTRIFUGE - 6 tubes horizontally
pivoting rotor
• 24040 TEST TUBES 10 ml - box of 100 pcs
The universal centrifuges are the perfect solution for laboratories
and doctors' offices. They feature a ZERO-RPM locking lid for
safety, digital programming of time ranging from 1-99 minutes
and speed ranging from 500-3300 rpm they accomodate 6 or
8 tubes (3-15 ml). Achieve up to 1364 g. Taking to a perfect
separation by centrifugation. They have a
DC motor and come with a 110-220
V auto switching power supply.
Made in USA. Manual GB, IT.
TECHNICAL SPECIFICATIONS
Power Supply: 220 V - 50 Hz
Power:
80 W
Speed:
Approx 1,000-4,000 rpm (increased in increments of 500 rpm's)
Time:
1-60 min
Capacity:
15 ml or 10 ml x 6
Max. RCF:
1,790 g
TECHNICAL SPECIFICATIONS
Nominal speed:
500-3300 rpm (step of 100 rpm)
Normal RFC:
31-1364
Maximum volume: 120 ml
Maximum power: 12 W
Fuse: 7.2 A
Recommendations
Speed
Time
Whole blood
3300
10 min
Urine
1800
5-10 min
CENTRIFUGES FOR PLASMA, URINE AND BIOLOGICAL LIQUIDS
24035
A
Lid
B
ON/OFF switch (DC power jack)
C
Run button
D
Stop/Open button
E
Speed setting
F
Time setting
G
Emergency release hole
H
Lid latch
24031
Size:
27x37x37 cm
24031-2
31001
UNIVERSAL CAMERA
FOR MICROSCOPES
see code 72566 page 176
