DIAGNOSTIC TESTS - LABORATORY
14
TECHNICAL SPECIFICATIONS
Power:
rechargeable battery (battery charger supplied 100 ÷ 240 V plug in)
Dimensions: 136 mm (L) x 215 mm (W) x 122 mm (H)
Weight:
approx 1.2 Kg.
• 24025 MICROHEMATOCRIT CENTRIFUGE - 180 sec.
Economic system, easy to use, fully automatic with LED
indicators, no vibration, silent, rapid and provided with
rechargeable battery. Useful for: small labs, office labs, blood
drawing areas, pediatric, neonatal settings, dialysis centers,
emergency room labs, veterinarians, sample prep for stat
chemistries.
• 24026 CAPILLARIES for microhematocrit - tube of 500
made of glass 9 microliters
Length: 32 mm - Ø 1.5 mm
• 23990 LACTATE SCOUT+
Pocket device for fast, accurate and reliable lactate measurement.
Easy to use:
- only 0.5 μl of capillary blood required
- pre-calibrated sensors
- device calibrated by simple coding
- lactate measurement, date/time, mode, temperature and
memory ID on a single display
Fast and accurate:
- enzymatic amperometric detection method
- results within 10 seconds
- measuring range: 0.5 - 25 mmol/L (±3%)
Performance measurement:
- single and step-test measurements (resting/exercise/recreation)
- stopwatch and countdown timer functions
Integrated bluetooth technology and PC software:
An USB key allows easy transfer to PC where a 4 language
(GB, DE, IT, ES) software allows easy data management.
Supplied with nylon bag, 10 lancets, 6 strips, control solution,
2x1.5 AA batteries, USB key, English manual, CD manual and box
(GB, FR, IT, DE, ES, DK, FI, NO, RU, SE, TR, CN), quick CD manual
and box (BG, CZ, EE, GR, HR, HU, LT, LU, LV, PL, PT, RO, RS, SI).
• 23991 STRIPS - tube of 24 pcs
• 24513 ONE-STEP SAFETY AUTOMATIC LANCETS - box of 100
• 23994 HEMO CONTROL
Fast, simple and accurate determination of hemoglobin and
hematocrit in whole blood:
- two tests in one
- fast results in 25 to 60 sec
- limited sample volume 8 μl
- graphical touch screen
- no calibration required, automatic self test
- memory: 4,000 results including date and time
- Hb con-low, Hb con-norm, Hb con-high
- integrated rechargeable battery (100 hours)
- multilanguage software
(GB, FR, IT, DE, ES, PT, PL)
Supplied with transformer (to recharge
battery), control cuvette and kit for cleaning.
English manual, CD manual
(GB, FR, IT, DE, ES, PT, PL, RU)
• 23995 HEMOGLOBIN MICROCUVETTES - box of 50
• 24513 ONE-STEP SAFETY AUTOMATIC LANCETS -
box of 100
Integrated
bluetooth
connectivity
Pocket size:
91x55x24 mm
Weight: 80 g
Measuring range:
0.5 - 2.5 mmol/L ±3%
Stores up + 250 results
Easy handling in 3 steps
Easy handling in 3 steps
Remove sensor and place into analyzer
Prick finger and collect blood by touching sensor
Put microcuvette into analyzer
Results appear in 10 seconds
Read results on display in 25-60 sec
HEMO CONTROL:
HEMOGLOBIN MEASURER AND HEMATOCRIT
TECHNICAL SPECIFICATIONS
Measurement method: photometric, azidemethemoglobin
Measuring range:
0-25.6 g/dL; 0-15.9 mmol/L
Sample volume:
8 μl
Sample material:
venous, arterial or capillary blood
Precision:
<2%
Linearity:
0-20 g/dl ±0.3 g/dl
>20 g/dl ±0.7 g/dl
Calibrated to NCCLS standard
Operating power:
110-250 V - 50/60 Hz; integrated battery (approx 100 h use)
0123
Compact size only
160x160x68 mm
Weight: 700 g
Large illuminated LC-touch screen
for intuitive device handling
Made in
Germany
MICROHEMATOCRIT CENTRIFUGE
23990
23994
Collect 8 μl blood sample
24026
24025
LACTATE SCOUT+:
FAST AND ACCURATE LACTATE MEASUREMENT
