262
FIRST AID - PARAMEDICAL - EMERGENCY
Display:
- High contrast TFT colour LCD 5.7" (320x240 pixel)
- ECG through the discharge paddles (1 trace)
or through 5, 10 leads patient cable for 6, or 12
traces and SpO
2
value
Automatic change over when plugging the
patient cable
- Filters: 50/60 Hz, base line, EMG
- Heart rate indicator
ECG monitoring
Bandwidth: 0.5 to 120 Hz (-3db) with filters off
ECG trace parameters:
- Speed 5, 10, 25, 50 mm/sec.
- Gain 5, 10, 20 mm/mV with patient cable;
auto with paddles
- HRdigitalreadoutonthedisplayfrom20to300bpm(±2%)
Alarm: HRmax settable 250 bpm, HRmin settable 20 bpm
Pulse oxymetry (SpO
2
) 33540-1-5-6-7-8-9, 33597-8 only
- Oxygen saturation range: 0 to 100%
- Pulse rate range: 18 to 300 pulses per minute
- Accuracy SpO
2
: 70-100% ± 2 digits for adults
using the finger clip sensor
- SpO
2
Alarms (min. 65%)
Non-invasive pacemaker (33543-4, 33591, 33547-8-9)
- Rectangular wave
- Operating mode: fixed on demand
- Pulse rate: 30 ppm to 250 ppm adjustable in steps of 5 ppm
- Impulse duration: 22 ms
- Pulse Current: 0 to 150 mA adjustable in steps of 5 mA
- Amplitude: MAX 150 V
NIBP (33547-8-9 only)
- Technique: oscillometric
- NIBP accuracy: meets ANSI/AAMI SP10-2002, EN 1060-4
- Patient application: adult/pediatric/neonatal
- Systolic range: Adult: 40-260 mmHG
Pediatric: 40-160 mmHG
Neonatal: 40-130 mmHG
- Range MAP: Adult: 26-220 mmHG
Pediatric: 26-133 mmHG
Neonatal: 26-110 mmHG
- Diastolic range: Adult: 20-200 mmHG
Pediatric: 20-120 mmHG
Neonatal: 20-100 mmHG
Printer:
- Auto printing mode
- Integrated thermal printer for ECG traces and
events documentation hardcopy including SpO
2
in%
- Paper speed 5, 10 and 25 mm/sec.
- Paper width: 58 mm
Safety:
- Two hand safety shock release
- Ecg input insulation CF class
- Internal discharge after 30 sec. of standby after charge
Power supply:
internal Ni-Mh high capacity batteries
(charging time 95%: 2 hours)
universal mains adaptor charger 110/230 VAC, 50/60 Hz
Dimensions: 36x24x34 cm Weight: 5.5 kg
TECHNICAL SPECIFICATIONS
RESCUE LIFEMANUALANDSEMIAUTOMATICDEFIBRILLATORS
Bright display, high contrast, wide-angle TFT LCD colour
display 5.7" to view simultaneously up to 3 ECG channels
Data management. Simple commands,
extremely intuitive and easy to use.
Immediate access to main setup
parameters using only trim knob
and function keys
Adult and pediatric
reusable paddles
Ergonomic design. Impact proof, compact and lightweight.
Comfortable and washable carrying bag keep all accessories at hand
and protects Rescue Life during the emergency procedures
Fast connection.
User can choose between
ergonomic reusable
paddles or disposable
pads for AED defibrillation.
Both types are equipped
with a single fast lock
connection for reliable
rescue operations
ECG cable
SpO
2
sensor input
RESCUE LIFE BIPHASIC DEFIBRILLATORS
Rescue Life is an external defibrillator with monitor. It is
designed to be used by out-of-hospital and hospital users.
Lightweight, transport facility, attractive line, ergonomic
shape, studied in every details. It is a complete acute cardiac
care response system designed for Basic Life Support (BLS) and
Advanced Life Support (ALS) patient management protocols.
The IPX4 standard permits the operation under adverse
climatic situations. Rescue Life is totally MADE IN ITALY.
SpO
2
and pacemaker
Range includes models with pacemaker and SpO
2
. ECG module
for monitoring (not for diagnosis) includes up to 12 derivations
Standard 5 leads patient cable (for I, II, III, aVL, aVR, aVF) or
optional 10 leads patient cable (for 12 derivations)
NIBP
The NIBP option is focused on advantage A+ module of
SunTech Medical that provides the highest NIBP performance
during movements. Suitable for adult, pediatric and neonatal.
TFT LCD colour display 5.7"
Bright, high contrast, wide-angle colour display for
simultaneous view of up to 3 ECG channels
Data management
The memory is based on a flash disk of 2 GB for
2,000 recorded hours for all AED models
Asynchronous and synchronous
- In
asynchronous
defibrillation, Rescue
is advised on patients with the following
symptoms: unconsciousness, absence of normal
breathing and lack of detectable pulse.
- In
synchronous
defibrillation, Rescue Life is
advised on patients with ECG's reporting Atrial
Fibrillation.
Operation modes
- In
manual mode
RESCUE LIFE is intended for
use by health care professionals and emergency
rescue personnel who have been trained in
advanced cardiac life support. Only 3 steps:
energy selection, energy charge and shock.
- In
AED mode
, RESCUE LIFE is intended for
use by personnel authorized by a physician or
medical director. The voice prompts and display
messages are assisting the operator during
CPR operations, charging automatically to 150J
when a shockable ECG rhythm is detected.
- In
advisory Mode
, the system alerts when the
shock is necessary leaving the energy level and
charging choice to the operator.
Clinic test
Available in our web site
*
On request we can offer Rescue Life and Rescue Life AED in Spanish and French
**
On request we can offer Rescue Life and Rescue Life AED with SpO
2
+NIBP,
SpO
2
+Pacemaker (available in GB, FR, IT, ES)
33590 33537 33538
*
Rescue life defibrillator
33597 33540 33541
*
Rescue life defibrillator with SpO
2
33591 33543 33544
*
Rescue life AED defibrillator with pacemaker
33598 33545 33546
*
Rescue life AED defibrillator with SpO
2
33547
33548
33549
*
Rescue life AED defib. SpO
2
+NIBP+Pacemaker
33539
**
Rescue life AED defib. other configuration
*
33448
Disposable paddles - box of 2 - adult
33458
Disposable paddles - box of 2 - pediatric
33593
Cable for disposable paddles
33594
ECG cable 10 leads
33595
Rescue life bag
33250
Thermal paper
33596
12V car light adapter - inverter
English
Italian
Other
languages
*
RESCUE LIFE DEFIBRILLATOR
RESCUE LIFE ACCESSORIES
GIMA
code
MADE IN ITALY
Internal Ni-Mh batteries
Printer
1 paper roll
Patient cables 5 leads
2 adult and pediatric reusable paddles 2 disposable pads (AED only)
Manual: English, Italian
Main adaptor charger
STANDARD ACCESSORIES
AVAILABLE WITH:
- SpO
2
- NIBP
- PACEMAKER
YOUMAY ORDER UNIT
WITH 1 TO 3 OF ABOVE
PARAMETERS
0068
