FURNITURE
89
STAINLESS STEEL, RADIOSURGICAL OPERATING TABLES
Designed to satisfy surgical functionality, practicality, quickness
and easy maintenance. They allow, with proper accessories, to
satisfy every basic surgical activity
- Table top
Divided in 5 sections (head, back, pelvis, 2 indipendent leg
sections) with stainless steel structure and plexiglass to allow
x-ray permeability and easy cleaning.
Table top is pre-arranged for the insertion of x-rays holders
all over its length. Accessories holder (25x10 mm) in stainless
steel, covers table top length on both sides.
- Telescopic column
Square and of limited size, covered by anodized aluminium
(27560) or stainless steel (27562/4/5/6)), it allows up and down
movement (approx. 70-100 cm) by a foot pedal placed at the
base through a closed oleodynamic circuit with oil-tight pump
avoiding any oil leakage (27560/2/4) or by remote control
(27565/6).
- Mattresses
They cover all the table top lenght, made in a long lasting
material, sterilizable in autoclave, x-ray translucent and
elastics. They are independently removable.
- Base
For Solaris, it is moveable by four large antistatic castors, 2
directional and 2 pivoting with brake. For Gima and Gima TR
(mechanical and semi-automatic) base is completely made of
GIMA
code
OPERATING TABLES
TECHNICAL SPECIFICATIONS
Table top size
Height
Lifting system
- Trendelenburg
- Reverse Trendelenburg
- Lateral tilt right-left
Table top composition
- Head section
- Back section inclination
- Pelvis section size
- Leg section
Table weight:
Operating table capacity:
Made in Italy
stainless steel to ensure perfect stability. It is provided with
a locking system to the floor through a foot bar. Transport is
allowed by 3 antistatic wheels, one pivoting and 2 directional.
- Movements
For Solaris: Trendelenburg and Reverse/Trendelenburg with a
“quick hydraulic action” and lateral tilt right-left 20° by crank.
For Gima and Gima TR same table movements as above, work
through a mechanical system moved by two cranks, positioned
at the side, easily retractable, for semiautomatic by remote
control.
- Longitudinal translation
Both Gima TR models offer manual longitudinal translation
of table top of about 300 mm to allow total elimination of
column encumbrance for 100% transparency of top.
- Full range of accessories.
All tables come with mattress
included, semiautomatic also includes control (with 1 m cable)
batteries and crank for emergency of engine.
27560
27562
+ accessories
90% RADIOTRANSPARENCY ON TOP
100% STAINLESS STEEL
COMPLETE MOVEMENTS
27570
27572
27573
MECHANICAL AND SEMI AUTOMATIC OPERATING TABLES
Independently
opening, extractable,
inclinable legs
Several adjustment, up and
down for all sections
27560
200x48 cm
70-100 cm
Mechanical
30°
30°
20°
-40° +80°
by gas spring
90 kg
200 kg
27562-27564
200x48 cm
75-105 cm
Mechanical
35°
25°
25°
-20° +80°
by gas spring
160 kg
250 kg
27565-27566
200x48 cm
75-105 cm
Electric
35°
25°
25°
-20° +80°
mechanical
160 kg
250 kg
extractable and inclinable (+25° -90°)
size 48x51 cm
size 48x49 cm
divided in two independent sections
with following manual movements
• opening right/left of 0°/90°
• inclination +30° -90°
• both parts are easily independently extractable
27560
Solaris operating table - mechanical
27562
Gima operating table - mechanical
27564
Gima TR operating table with longitudinal
translation of table top - 100% radiotransparency
27565
Gima operating table - semiautomatic - need 27559
27566
Gima TR operating table - semiautomatic
with longitudinal translation of table top - 100%
radiotransparency - need 27559
ACCESSORIES FOR ALL OPERATING TABLES - 100% stainless steel
27568
Wristlet with clamp - couple
27569
Rectangular s/s gynaecological basin - 200x320x150 mm
27570
Two-hook adjustable IV stand (needs clamp 27571)
27571
Clamp for IV stand
27572
Arm holder adjustable 90-180° with cushion and clamp
27573
Drape support with adjustable height with 2 clamps 27576
27576
Clamp for drape support - spare
27574
Leg holder with radio transparent valve and
cushion - couple (needs 2 clamps 27575)
27575
Clamp for leg holder
ACCESSORIES FOR SEMIAUTOMATIC TABLES (27565-6)
27558
Infrared control
27559
Battery charger
Suitable for any
surgical activities
Lateral movement
right-left
27568
27565
Trendelenburg and
Reverse/Trendelenburg
Back section inclination
up and down
