FURNITURE
86
DONOR ARMCHAIR
• 27557 DONOR ARMCHAIR - blue
Strong and stylish armchair with structure made with oval,
round and square metal section tubing (legs oval tubing
50x25x1.5; central frame square tubing 30x30x1.5, cushions
round tubing 20x1.5 diam.). Structure fully coated with white
epoxy powder. High density polyurethane foam platform
with wooden base covered by leatherette upholstery. Both materials are flame
resistant Class 1 IM. Synchronized adjustment of the two cushions by a gas pump
(600 N). The backrest inclination ranges from +60° to -5° in Trendelenburg
position, leg rest from -80° to +5°.The arm-rests have a joint allowing inclination
during use, can be height adjusted and, when removed, can be rotated up to
180°. Four adjustable feet ensure maximum stability. Made in Italy
•27553 IV STAND
•27556 COUCH ROLL HOLDER
TECHNICAL SPECIFICATIONS
BASIC
EVOLUTION
Safe working load
160 kg
180 kg
Weight
97 kg
107 kg
Castor diameter
12.5 cm
15 cm
Castor braking system
Individual on each castor Central pedal-operated
Directional system
yes
yes
Side rails width reduction
yes
yes
Collapsible head end rail
no
40°
Tilt for water discharge
5°
5°
Discharge hose length
150 cm
150 cm
White ral colour
9003 structure,
minimum thickness
70/80 micron.
Glossy finish.
27837
SHOWER MATTRESS
• 27836 SHOWER MATTRESS
It allows bed-ridden, elderly or disabled patients to be washed
and cared for in their personal hygiene with running water
directly on their bed, without any need for transfer/lift.
Inside the "Shower Mattress", the patient can be showered
with water coming from the tap via an extension hose or using
the special pressurized water tank provided with flexible hose
and shower head. Once finished, the water is drained into a
suitable container. Complete with plug and flexible hose for
quick water drain.
•27837 WATER TANK
Pressurized water tank complete with flexible hose and
shower head operated by button.
• 27838 SHOWER EXTENSION HOSE
Flexible, 6 m hose complete with button-operated shower
head and tap adapter.
27838
27836
• 27814 BASIC SHOWER TROLLEY - hydraulic
• 27815 EVOLUTION SHOWER TROLLEY - hydraulic
• 27816 EVOLUTION SHOWER TROLLEY - battery
• 27817 EVOLUTION SHOWER TROLLEY - hydraulic with
tilt head section
• 27818 PILLOW - 55x55x14/2 h cm
The stretcher can be used for both transport and showering.
The hydraulic version can be height-adjusted by means of
a foot pump on either side. The whole frame has a special
cataphoresis anti-corrosion treatment, the mattress base is
made of ABS plastic; stainless steel side rails and fasteners.
Safety side rails are provided with a locking device and can be
easily folded down by one hand when transferring patients
from bed to stretcher. The head end rail can also be dropped
to be used by patients taller than 188 cm (Evolution only).
Width can be effortlessly reduced by attendants when
transporting through doorways by folding down the side rails.
The stretcher has a drain hole with a 150 cm water drainage
hose. Water drainage is made easier thanks to the possibility
for the carer to tilt the mattress base by means of a gas spring
control. Castors have a central braking system (Evolution only).
There is also a directional lock to facilitate transport.
Safe working load: 180 kg.
Backrest tilt up to 63°
only for 27817
Reduced
width
Pillow with 15° tilt,
55x55x14/2 h cm
27814
27815
Model with electrical height adjustment.
24 V rechargeable battery and hand control.
The battery charger 110/220 V - 50/60 Hz is included.
Model with tilting head section (27817) - hydraulic.
Available version with tilt adjustable backrest by manual control
and piston, with hydraulic height adjustment.Made in Italy.
188-203 - EVOLUTION
188 BASIC
27818
SHOWER TROLLEY
- HYDRAULIC AND ELECTRIC HEIGHT ADJUSTMENT
