FURNITURE
84
AN INTEGRATED SYSTEM OF TREVIRA
®
CURTAINS
A COMPLETE SEPARATION SYSTEM
A complete system to create separations inside hospital rooms
or outpatient wards.
System includes
4 STRUCTURES - include rings
- adjustable wall arms manual or electric
- window curtain rails
- cabin curtain rail
- trolleys with 1 or 2 curtains
3 SIZES TREVIRA
®
CURTAINS 6 COLOURS - do not include rings
Window curtains rails
Available in 2 size: 160 cm (45492) need curtains 175xh 145 cm
and 210 cm (45493) need curtains 225x145 cm
Cabin curtain rails
Size: 80x80 need curtains 225xh 180 cm
Swing arm curtains - manual
Swing arm curtain is adjustable horizontally (180°) and can be
bent down to 90° (45501 only) when not in use.
Telescopic tubular arm extension: open 210 cm, closed 88 cm
(45500) or 100 cm (45501).
Rings allow curtains to slide smoothly.
Swing arm curtains - electric
Adjustable horizontally (180°) by electrical control.
Telescopic tubular arm extension: open 188 cm, closed 90 cm.
Trolley curtains - 1 or 2 curtains
Trolley made of stainless steel
ISO 304 with 4 revolving castors
(2 lockable). It allows the use of
1 curtain 225xh 145 cm (45505)
or 2 curtains (45506) 1 long
225xh 145 cm and 1 short
175xh 145 cm. Arm can be bent
down to 90° when not in use
and curtain remains tied up.
Trevira
®
curtains
Trevira
®
curtains are flame-
proof (Class I), antiallergic, avoid bacterial growth, waterproof
and highly resistant to abrasion. Thick weft to avoid dust
infiltration and improve privacy, washable up to 60°C.
Available in 6 colours to match any need.
Custom-made curtains are available on request.
Made in Italy.
GIMA
code
STRUCTURE: ARM OR TROLLEY
WITHOUT CURTAINS
TREVIRA CURTAINS
Window curtain rail 160 cm
Window curtain rail 210 cm
Cabin rail 80x80 cm
Adjustable arm
Adjustable foldable arm
Electrical adjustable arm
Trolley for 1 curtain - foldable
Trolley for 2 curtains - foldable
45520
45530
Light blue
45521
45531
Blue
45522
45532
White
-
-
Beige
-
-
Green
45525
45535
Peach
Open rings
for window rails and cabin
Closed rings
for wall arms and trolleys
45492
45493
45495
45500
45501
45503
45505
45506
45510
45511
45512
45513
45514
45515
45508
45509
Long trolley Short trolley
arm/rail:
arm/rail:
225xh145 cm 175xh145 cm
COLOUR
Telescopic arm max
extension: 210 cm
Cabin
Electric arm
maximum extension:
188 mm
Light blue
Blue
White
Beige
Green
Peach
45500
+ 45510
45495
+ 45510
+ 27987
45503
45500
+ 45510
45501
+ 45510
45506
+ 45520
+ 45530
Height of trolley 165 cm
depth of base 45 cm
45506
+ 45525
+ 45535
45509 45508
225xh 180 cm
FOR WALL ARMS
AND CABIN
FOR TROLLEYS
AND WINDOWS
Windows curtains
45493
+ 45520
Long arm
Short
arm
SET OF 18 RINGS - SPARE
OTHER WING SCREENS see page 112
