FURNITURE
87
27810
Side rails (couple)
27811
I. V. Stands
27812
Steel basket
27813
Oxygen bottle holder
GIMA
code
PATIENT TROLLEY ACCESSORIES
-
not included
• 27800 PATIENT TROLLEY
• 27801 PATIENT TROLLEY - removable top
Made of chrome plated steel tube, and washable self
extinguishing plastic material. Comes complete with mattress.
Mounted on 4 castors Ø 100 mm two of which with brakes.
Size: 180 x 54 x h 80 cm. Made in Italy. Load: 100 kg.
• 27850 TRENDELENBURG TROLLEY
Made of steel-alloy, oven painted ral 9010, with chrome plated
handles.
Adjustable height from 40 to 70 cm, with oleodinamic pump.
Trendelenburg up to 9°.
Anti-Trendelenburg up to 14° (with gas pump).
Plastic bumpers at four corners. Maximum load: 100 kg.
4 wheels of Ø 200 mm (2 with brake).
Size: 65x184 (internal) x h 50-70 cm, 72x191 cm (external).
27810
Side rails (couple) 100xh 28 cm
27853
I. V. Stands
27854
Oxygen bottle holder
27855
Mattress - black sky 3 cm thick in flame
retardant material - 184x64x3 cm
Oleodinamic pump
for height adjustment
Ø 200 mm wheels
Steel-alloy
Code 27810 side rails
(not included)
Bumpers at
all 4 corners
• 27819 WARD STRETCHER
Main features:
- Platform:
all-welded mainframe made of different sections steel
tube. Section frame made of oval steel tube 50x25x1.5 mm.
- Push/Pull handle:
Made in steel tube Ø 32x1.5 mm.
- Surface finish:
Epoxy gloss finish standard grey 7035
- Mattress platform section:
Two section mattress platform fitted
with removable chrome-plated grids made of 5 mm. Ø steel rods
and rectangular mesh 100x50 mm.
- Backrest:
Adjustable by means of a rack device. Fixed leg section.
- Castors
- Four castors Ø 200 mm made of grey synthetic rubber
two of which with independent brake.
- Bumpers:
Four bumpers at the
corners made of anti-acid and
anti-shock grey resin.
- Delivery stretcher with trolley:
If necessary the upper part is
detachable to enter ambulance
or other use.
External size: 202x71 xh 90 cm
Wired net height: 78 cm
Load: 135 kg.
Made in Italy.
27821
Side rails (couple) with automatic locking device
27822
I.V. Stand with two hooks
27823
Basket - chrome plated steel
27824
Oxygen bottle holder* - chrome plated steel
27825
Fireproof simulated leather mattress - class I - 182x64x4 cm
GIMA
code
WARD STRETCHER ACCESSORIES
27819
+
accessories
Detachable upper part
GIMA
code
ACCESSORIES
TRENDELENBURG PATIENT TROLLEY - STRETCHER
PATIENT TROLLEYS - STRETCHERS
Basket
Code 27812
(not included)
Oxy bottle holder
code 27813
(not included)
* for oxygen bottle up to 41 cm, Ø 15,5 cm
PROFESSIONAL WARD STRETCHER
Side rails code 27810
(not included)
27800 and
accessories
(not included)
27801
Removable top
on the trolley
Removable top
65 cm
110 cm
54 cm
27850
