FURNITURE
85
• 27645 LIFTING STAND
Tubular painted steel frame with
adjustable chromed steel joint. Can
be fully disassembled to reduce size.
Three main height adjustments.
Triangle hangs from belt with
adjustable lenght.
LIFTING STAND
27645
• 27636 EXTENDABLE BARIATRIC BED - electric, 4 sections
Four section electrically driven bed frame in durable steel
construction with adjustable height and TR-RTR. Made in Italy.
- Trendelenburg 18° and Reverse Trendelenburg 18°
- mattress platform positioning: backrest 0°-54°, legrest 0°-24°
- manual handset with locking key+supervisior to adjust sections
- electric CPR function
- armchair position with excellent comfort
- carer controlled lock out function for all controls
- battery backup
- central braking system with a three position pedal on foot
side for greater control: steering / swivelling / braking
• 27638 LIFTING POLE with integrated IV hooks
• 27639 RETRACTABLE BLANKET TRAY
• 27640 IV POLE
• 44810 FLAME RETARDANT BARIATRIC MATTRESS - 4 pieces
with waterproof transpirant cover.
Load 300 kg. Density 40 kg/m
2
.
Size 90x200x18 cm (2 sides 15x200x18, 1 foot 15x120x18)
• 44800 HEIGHT ADJUSTABLE ELECTRIC BED
3 joint, 4 section Hospital bed, with electronic adjustment
of height and platform, Trendelenburg and Reverse
Trendelenburg positions (15°). All steel components are epoxy-
coated with anti-microbial additive. Back section regulation
using electric actuators with anti-crushing and rototranslation
function to avoid abdominal crushing. Both bed sides have CPR
manual levers for emergency manoeuvres.
Foot rest adjustment by click mechanisms allowing 6 positions.
Internal side rails controls for patient use and caregiver.
Remote control to maintain position or disable by magnetic key.
The keypad allows adjustment of backrest, bed surface height,
legs and foot rest, comfort position, Trendel and reverse Trendel.
• 44801 LIFTING POLE
• 44802 IV POLE
• 44803 FLAME RETARDANT MATTRESS with waterproof cover
Load 280 kg. Density 35 kg/m
2
. Size 85x195x18 cm.
BARIATRIC ELECTRIC BED
Sections, height, TR and
RTR electric
adjustments
Floor clearance 15 cm
Twins castors
Ø 15 cm
Bed weight
150 kg
Four corner bumpers
integrated into the
frame
Easily removable
head & foot boards
with blue HPL
(light blue, yellow
or green colour
available on request)
4 multi position and removable
siderails, colour co-ordinated to
bed frame
Two sockets
for IV pole at
head side
HEIGHTADJUST. ELECTRICBED
Compartments
for patient lift
bar and
IV probe
4 containing sector side rails, made in
technopolymer, and single collapsible
4 castors Ø 150 mm with
central brake system
with directional control
TECHNICAL SPECIFICATIONS
Minimum/maximum height surface: 380-780 mm
Maximum backrest regulation: 70°
Maximum leg/foot height regulation: 30°
Trendelenburg/reverse trendelenburg: 15°
Minimum/maximum height: 835-1235 mm
Maximum total width/lenght: 1010/2260 mm (bumpers and siderails included)
Worksurface width/lenght dimension 880/2000 mm
Power supply: 220 V - 50 Hz Dynamic lift capacity: 230 kg
SWL: 270 kg
IEC protection class: I / B IP code (protection rating): IP66
Made in Italy
TECHNICAL SPECIFICATIONS
Bed upper frame dimensions: - fully retracted - 226x100 cm (bumpers included)
- fully extended - 242x128 cm (siderails included)
Mattress platform adjustments: - fully retracted - 200x90 cm
- intermediate position - 200x105 cm
- fully extended - 200x120 cm
- foot extension - from 200 to 216 cm
Lowest-Highest position:
41-81 cm
Bed weight:
175 kg Load capacity: 400 kg
Electrical shock protection:
Class 1
Liquid ingress protection: IP 66
27753
Length 134 cm
Adjustable base
63-105 cm
HYDRAULIC AND ELECTRICAL LIFTERS
Maximum
load
200 kg
Sling support
min h 82 cm
max h 177 cm
• 27749 HYDRAULIC LIFTER -
max load 200 kg
Lifting movement through a
hydraulic pump operated by
adjustable side control lever.
Descent movement by
independent exhaust-valve.
Adjustable base 63 to 105 cm
controlled by a manual
device for an easy access to
narrow places. Painted steel
frame. Anti trauma push-
handle. 2 rear castors Ø 100 mm,
with independent brake and 2 front castors Ø 80 mm.
Equipped with tetraplegic sling (27767). Made in Italy.
• 27752 ELECTRICAL LIFTER 170 - max load 170 kg
• 27753 ELECTRICAL LIFTER 200 - max load 200 kg
Same as code 27749 but with electrical controls.
Up and down movements through an electric motor
24V D.C. and push button. Battery fed with current
transformer with an emergency push-button for the
immediate stop of the movement and free up/down
piston-stroke. Supplied with universal sling (27752) or
tetraplegic sling (27753).
• 27757 UNIVERSAL SLING - spare - load 170 kg
• 27767 TETRAPLEGIC SLING - spare - load 200 kg
Made of polypropylene, anti-allergic, non toxic, washable.
Weight
50 kg
Sling support
min h 104 cm
max h 188 cm
27749
Adjustable base
63-105 cm
Length
134 cm
27752
Electric patient Iifter;
feeding battery,
adjustable base.
Max load 170 kg
LOAD 400 kg
Moulded
removable
head and foot
boards with integra-
ted handle useful for
movements
27757
27767
