FURNITURE
82
• 27673 SPECIALISTIC BED with Trendelenburg - 40-80 cm
• 27672 SPECIALISTIC LOW BED with Trendelenburg - 23-63 cm
Three-joints, four sections bed with adjustable height from
40 to 80 cm or 23-63 cm with full electrical movements. All
welded mainframe made of rectangular steel tube 50x25x2
mm. Mattress platform with flexible wooden staves, complete
with mattress-hold guides. Backrest-section and leg-section
adjustable by means of two independent electric motors 24V
D.C. and push-button. Foot-section adjustable by means of a
rack device. Fixed pelvis-section. Removable head and foot-end
frames made of natural beech finish wood with solid corners
and edges. Comes complete with 2 vertical sliding bars with
upper/lower lock/unlock keys and lifting pole (27673 only). Legs
fitted with 4 castors Ø 100 mm with independent central brake.
Delivered in kit form (27673 only).
• 27676 WOODEN BEDSIDE TABLE
Manufactured by quality natural wood. Particularly
functional: with
drawer, 2 doors (can
be used from both
sides) and lateral tray.
Size: 53x45xh86.5 cm.
Lateral tray: 58.5x35 cm.
4 revolving castors (2 lockable).
ABS border.
Tray tiltable at 90°.
Possibility of Trendelenburg (12°)
and reverse-Trendelenburg (12°) movements
• 27652 1 JOINT BED - 1 crank - feet
• 27653 1 JOINT BED - 1 crank - castors
• 27656 3 JOINTS BED - 2 cranks - feet
• 27657 3 JOINTS BED - 2 cranks - castors
- All welded main frame constructed from
rectangular steel frame.
- Bed ends made in epoxy glass finish steel tube
- 1 joint/2 sections or 3 joints/4 sections
- manual movement by 1 or 2 cranks with retractable handles
- legs fitted with rubber/steel castors with independent brake,
3 of which revolving and 1 directional or plastic feet.
27657
27652
TECHNICAL SPECIFICATIONS
27652/3
27656/7
27658
27659
27660
Size of platform:
900x2000 mm
Platform height mm: 500
500
400/800
500
400/800
Height of bed ends mm:
950
External measurement:
920x2070 mm
Movement:
1 crank
2 cranks 2 cranks electric
electric
27660
PATIENT BEDS WITH 1 OR 3 JOINTS, MANUAL OR ELECTRIC
Collapsible support
Infusion pole and lifting pole Telescopic bed side rails
• 27658 3 JOINTS BED - 2 cranks - variable height - castors
• 27659 3 JOINTS BED - electric - castors
• 27660 3 JOINTS BED - electric - variable height - castors
- 3 joints/4 sections beds adjustable by means of 2 indepen-
dent cranks (27658) or electric motor 24 V DC and push botton
- height adjustable by hydraulic foot pump (27658) or electric
motor (27659/60)
Legs and other features as 27652
GIMA
code
ACCESSORIES FOR PATIENTS BEDS
Height adjustment of platform
from ground from 40 to 80 cm or
23 to 63 cm
SPECIALISTICBED3-JOINTS/4SECTIONS,ELECTRICAL,ADJUST.HEIGHT
27659
TECHNICAL SPECIFICATIONS
Size of platform: 900x2,000 mm
Platform height: 400-800 mm (27673)
230-630 mm (27672)
External measurement: 1,030x2,140 mm
Height of bed end from mattress platform: 50 mm
Max load: 140 kg
Operating power: 230V - 50Hz
EN 1970:2000
DIN EN 1970:2000-12
EN 60601-1:1990+ A1:1993 + A2: 1995
DIN EN 60601-1:1996-03
EN 60601-2-38:1996 + A1:2000
DIN EN 60601-2-38:2001-07
QUALITY
63
or
80
23
or
40
20°
70°
27673
27672
27676
27676
27663
Collapsible support - couple
27664
Universal “telescopic” bed side rails - couple
27667
Infusion pole with universal clamp
27668
Lifting pole with slot in system
27661
Kit for castors spare for 27653/57/58/59/60
27663
27668
27667
27664
