MEDICAL LIGHTS
173
TECHNICAL SPECIFICATIONS
Power consumption: 15W
LED life: 30,000 hours
Light intensity: 30,000 lux at 50 cm, 10,000 lux at 1 m
Colour temperature: 5,200 °K ± 5% at 1 m
Illuminated field at 50 cm: Ø 200 mm
External diameter of the reflector: 135 mm
Temperature increase in the operating area at 1 m: 1°C
Adjustable height with castors: 600 mm - max 1600 mm
Power supply: 230V - 50 Hz - 50 VA (110 on request)
Weight: 10 kg
Made in Italy
Norms: CEI 62-5, IEC 60601-1
CE, 93/42 EEC
• 30710 ESALED - on trolley
COLD LIGHT LAMP WITH LED TECHNOLOGY SHADOWLESS TYPE
- 6 white LED of 2.5W each 24V - 30,000 lux at 50 cm distance
Six LEDS light sources of 2.5W each with glass lens to
optimize the light performance. Thanks to many indipendents
light sources it is possible to assure shadowless light and
low radiated energy temperature. ESALED is suitable for
examination purposes, it is unsuitable for surgery room.
Other fixing system, available (wall, rail, table).
• 30769 TROLLEY FOR ESALED - spare
ESALED SHADOWLESS, COLD LIGHT LAMP -
30,000 LUX AT 50 CM
30710
30710
PRIMALED COLD LIGHT LAMP WITH 9 LED LENSES
Appealing design and advanced technology.
Design:
the round and ultra-flat shape of the light makes the
product ergonomic and suitable for any type of installation,
from the doctor’s surgery to the intensive-care unit.
Ergo-Spring:
the movement of the articulated tubular arm
is servo-assisted by a torsion spring which ensures ease of
movement and stability.
80,000 lux:
unique performance with 80,000 lux at 50 cm.
Light intensity adjustment:
six different adjustment levels by
the keys on the frontal panel.
4,500-5,000 °K Colour temperature selection:
the comparison
between the two colours (K) increases the visibility of details.
Shadow suppression:
the radial layout of the lenses and the
large-diameter lamp (195 mm) allow shadow suppression and
three-dimensional lighting.
Adjustable courtesy-light:
integrates ambient light with
traditional concentrated light.
Sterilizable removable grip:
allows best asepsis.
Cold light:
the reduced emission of IR rays by the LEDs as well
as the low power consumption allow minimum heat emission.
Disinfection:
the smooth and rounded shape of the dome and
structure make it easy to clean and disinfect.
50,000 hours LEDs life:
the top aluminium dome allows
heat exchange, thus reducing the work temperature and
considerably increasing the life cycle of the single LEDs.
Fully certified:
complies with IEC 60601-1 and 60601-1-2 general
medical standards and to special standard IEC 60601-2-41 93/42
EEC and 2007/47 EC and is CE marked as a Class I medical device.
Mechanical testing and user safety:
die-cast aluminium and
tubular steel structure. The articulated arm has undergone
mechanical testing for 40,000 continuous movements to ensure
maximum safety for the user during use.
Light continuity:
the modular design of the LED power circuit
ensures light continuity even in case of a LED fault.
30777
30753
30778
30784
30786
30797
Primaled light - trolley
Primaled flex light - trolley
Primaled light - ceiling
*
Primaled light - wall
Primaled light - rail (25x10) and clamp
Autoclavable handle
GIMA
code
PRIMALED
TECHNICAL SPECIFICATIONS
LED life: 50,000 hours
Light intensity: 80,000 lux at 50 cm, 20,000 lux at 1 m
Colour temperature: 4,500-5,000 °K
Colour rendering index: 95 Ra
Illuminated field at 50 cm: Ø 140 mm
External diameter of the reflector: 190 mm
Temperature increase in the operating area at 1 m: 1°C
Adjustable height with castors: 600 mm - max 1,600 mm
Power supply: 80-240V - 50/60 Hz
Electric absorption: 21VA
Weight: 10 kg (trolley included)
Made in Italy
The following functions
are controlled by the keys
on the membrane keyboard:
- on/off
- selection of the 5,000°K and 4,500°K colour temperatures
- 6-level adjustment of the light intensity
- courtesy light
PRIMALED COLD LIGHT LAMP
- 80,000 LUX AT 50 CM
*
Battery group available on request
Trolley base
Wall clamp
Rail clamp
30753
30778
30777
