261
FIRST AID - PARAMEDICAL - EMERGENCY
Connectors to defibrillator of compatible pads
Multilanguage envelope: English, Italian, French, German, Spanish, Portuguese, Greek, Dutch, Russian, Swedish
STANDARD ACCESSORIES
Internal Ni-Cd high capacity battery
Carrying case
Patient cable 4 leads
Manual English, Italian, on request
Spanish, Turkish
Printer
1 paper roll
2 reusable paddles
Mains adaptor charger
Disposable paddle
*
+cable
*
*
Only for 33457
Optional paddles
for monitoring
Adult and pediatric
standards pads
33447
33448
TECHNICAL SPECIFICATIONS
Display:
- Large (5.7") high resolution backlight LCD display (320x240 dots)
- ECG through the discharge paddles (1 trace) or through 4 leads
patient cable (6 traces): I, II, III, aVR, aVL, aVF
- Automatic change over when plugging the patient cable
- Filters: 50/60 Hz, base line, low pass
- Heart rate indicator
Printer:
- Auto printing mode
- Integrated thermal printer for ECG traces and events documentation hardcopy
- Paper speed 5, 10, 25 mm/sec (paper width 58 mm)
Safety:
- Two hands safety shock release
- ECG input insulation CF class
- Internal discharge after 30 sec of standby after charge
Power supply: internal Ni-Cd high capacity batteries (charging time 95%: 2 hours)
universal mains adaptor charger 110/220 VAC, 50/60 Hz
Dimensions: 34x26x13 cm Weight: 5.5 kg Made in Italy
COMPATIBLE PADS
FOR OVER 80%OF DEFIBRILLATORS ON THE MARKET
COMPATIBLE PADS
A range of compatible pads for most defibrillators on the
market, BSI certified. Excellent adherence and adequate gel
thickness. Includes a couple of pads, cable and connector.
Maximum shelf life 2 years from production date.
Made in Italy.
GIMA
code
GIMA
code
BRAND
BRAND
MODEL
MODEL
33576 Agilent-Philips
- Heartstream/HeartStart XL M4735A
- Heartstream/HeartStart XL T M3500B
- HeartStart 4000 M5500B
(all with Philips cable M3508A)
33577 Agilent Hewlett-Packard
- Codemaster 100-XE-XL-XL+
- HeartstreamXL and XL T with cableM3507A
33448 Cmos Drake
- Futura
33448 CU Medical System
- i-PAD NF1200
33579 Drager
- Cardiolog 2000
33586 Esaote
- MDF SAED - MDF II
33579 Innomed
- Cardioaid 200B - 200 - 100 - XL+ - XL
33577 Laerdal Medical
- HeartStart 4000
33587 Medtronic-Physiocontrol
- Lifepak 9 connector quick-combo
- Lifepak 10 - 12 - 15 - 20 - 500 - 1000
33459 Metrax Primedic
- Heartsave AED - AED-M - 6 - 6S
- Defimonitor XD
33579 Nihon Kohden
-
7700 - 2202 - 2203 - 7531 - 8251
all with cable JC-755V
33587 Osatu Bexen
- Reanibex 200 - 700
33576 Philips Laerdal Medical
- Heartstream Fore Runner I AED models E, S, EM
- Heartstart FR1 AED 940010XX - 940020XX & 940030XX
- Heartstart FR2 AED M3840A & M3841A
- Heartstart FR2 AED, with ECG module M3860A & M3861A
- Codemaster M1722A/B, M1723A/B, M1724A & M2475B
(with Philips cable M3507A and pad adapter 05-200)
- Heartstart MRx (with Philips cable M3508A)
33588 Schiller
- Fred Easy
- Defigard DG4000 - DG5000 - DG6002
33586 Schiller
- Fred - Fred tele
- Defigard DG1002 - DG3002 - DG2000EDOS
33579 S&W
- Cardio Aid LS - MC - MC+
33579 Welch-Allyn
- AED10 - AED20
(pediatric adaptor Welch-Allyn 002173/4-U)
- PIC30 - PIC40 - PIC50
33589 Zoll Medical Corp
- Zoll PD 1200 - 1400 - 1600 - 1700 -
2000 - M series - E series - R series
33448
33588
33565
33579
33576
33586
33589
33577
33587
0086
RESCUE 230 BIPHASIC MANUAL DEFIBRILLATOR
Battery charging
car plug
on request
RESCUE 230 BIPHASIC MANUAL DEFIBRILLATOR
A range of 2 professional models with advanced features:
- BTE (Biphasic Truncated Exponential) discharge type
- impedance compensated energy delivery
- energy selection from 2 to 230 joule directly from the front panel
- charge time 5 sec for 230 joule with fully charged battery
- 100 shocks of 230 j with fully charged batteries
- charge/discharge control from the paddles
- ECG 'R' wave synchro mode or async mode
- large (5.7") high resolution backlight LCD display (320x240 dots)
- ECG through the paddles or through patient cable
- adjustable HR and SpO
2
alarms limits
Not for pediatric use <8 years or <25 kg
• 33447 RESCUE 230 BIPHASIC DEFIBRILLATOR
• 33457 RESCUE 230 BIPHASIC DEFIBRILLATOR WITH PACEMAKER
(rectangular pulse, pulse duration 22 msec, pulse max amplitude
150 V, stimulation frequency 30 to 150 BPM)
• 33448 DISPOSABLE PADDLES - box of 2 - adult
• 33449 CABLE FOR DISPOSABLE PADDLES
• 33439 SpO
2
PROBE • 33250 THERMAL PAPER
