PHARMACY - PATIENT AIDS
77
Bielastic, breathable, waterproof,
cover easy to clean. Made in
polyester fibre + PU
ANTI-DECUBITUS AIR MATTRESSES WITH PUMP
28513
28516
BUBBLE MATTRESS
Designed for the treatment and prevention of pressure sore
stage I in long-term and domiciliary therapies.
The PVC mattress is composed of 130 7 cm-high bubble cells,
particularly comfortable. Fixable to bed by extra flaps on both
top and bottom side. Cold-resistant -30 degrees.
PUMP SYSTEM
Special silent pump for an excellent
pressure regulation by a knob
on the device front panel. The
pump can be hung to any kind of
hospital bed frame by means of
two adjustable hooks. For use with
bubble or alternating cell mattresses.
Flaps length: 50x50 cm
(top + bottom)
TECHNICAL SPECIFICATIONS - MATTRESS
28513
28516
Total size:
200x90x7 cm
180x80x7.5 cm
Cell height:
7 cm (2.7")
7.5 cm (3")
Material:
PVC
Nylon+PVC
Thickness:
0.35 mm
≥ 0.35 mm
Number of cells:
130
24+1 spare
Suitable for persons up to:
100 kg
110 kg
GIMA
code
MATTRESSES AND PUMP
Bubble mattress
Pump for 28513
Kit bubble mattress+pump (28513+28514)
Interchangeable cell mattress
Pump for 28516
Kit cell mattress+pump (28516+28517)
Spare cell for 28516
28513
28514
28515
28516
28517
28518
28519
EN71 MEDICAL GRADE
0.35 mm PVC
INTERCHANGEABLE CELL-MATTRESS
Recommended for the prevention and treatment of pressure
sore stage I and II in long-term and domiciliary therapies.
The 24 7.5 cm-high Nylon+PVC cells provide superior comfort.
They can easily be replaced in case of breakage.
Manual and box in 10 languages: GB, FR, IT, ES, DE, PT, PL, HU, GR, Arabic
28514
TECHNICAL SPECIFICATIONS - PUMP
28514
28517
Size:
25x13xh 9.5 cm
Operating voltage:
220 V, 50 Hz
Working pressure:
50-105 mmHg
50-110 mmHg
Air output:
4-6 liter/min
5-8 liter/min
Cycle time:
6 min
Plastic casing:
Taiwan chimei ABS
TUV-CE IEC/EN60601-1; 60601-1-2
THERAPEUTIC ANTIDECUBITUS MATTRESSES UP TO LEVEL III
TECHNICAL SPECIFICATIONS
28501
28511
28512
Prevention efficacy (Norton scale)
low risk
medium risk medium-high risk
Prevention efficacy (NPUAP scale)
I level
II level
III level
Mattress size - cm
200x85x11
200x90x18
200x90x23
Mattress weight - kg
3.5
7
9
Max patient weight - kg
150
200
250
Deflation time (CPR)
10 sec.
10 sec.
10 sec.
Inflation time
25 min.
20 min.
30 min.
Power supply (compressor)
220/230 V - 50 Hz
Conformity to:
CEI EN 60601-1, CEI EN 60601-1-2
• 28501 EURO BASIC ANTIDECUBITUS SYSTEM - low risk
Euro Basic is an alternating low pressure system which includes
a three way compressor with pressure regulator and an overlay
mattress. To be used in prevention and therapy of ulcers caused
by decubitus.
Static or dynamic mode:
dynamic mode allow to continuously
change the contact areas and to distribuite the weight load.
CPR fuction
allows a quick deflation of overlay mattress.
• 28511 EURO SOFT EVO ANTIDECUBITUS SYSTEM - medium risk
• 28512 EURO SOFT PRO ANTIDECUBITUS SYSTEM - high risk
Euro Soft are alternating low pressure systems, suitable for
medium risk patients (28511) or high risk patients (28512)
Norton scale. They include a three-way digital compressor and
a replacement mattress.
- Static head elements, to improve patient's comfort
- Polyuretane foam base, 5 cm deep, to ensure sufficient
patient support in case of emergencies
- CPR function for easy and rapid deflation of mattress (10 sec.)
- Transport facility: the mattress will remain inflated for 10-12
hours in case of power failure or during patient transport
- Inclination sensor to avoid sacral sinking
- Radio translucent surface enables examination without
moving the patient
Bielastic, breathable, bacteriostatic antifungal,
waterproof, fireproof, cover easy to clean.
Made in polyester fibre + PU
28512
Compressor size:
27x23x13 cm
Compressor size:
30x18x13 cm
Mattress
made in nylon/
polyurethane
28501
Overlay mattress
18 elements -height 11 cm
28511
Mattress
17 elements - height 13 cm
28512
Mattress
20 elements - height 18 cm
Made in Italy
28501
Mattress made in
nylon/polyurethane
