PHARMACY - PATIENT AIDS
78
ANTI-DECUBITUS PVCWATER MATTRESS
TECHNICAL SPECIFICATIONS FOR MASTER PUMP - RINT PLUS PUMP
Size: 330x150x120 mm
Weight: 1.95 Kg
Operating voltage: 230 V - 50 Hz
on request 110 V - 60 Hz
Power Consumption: 8 W - CLASS II
Working pressure: 60-135 mm/Hg
Suitable for mattress: bubble or section
Regulations: IEC-601-1 class II Type B
Made in Italy
User manual in English Spanish, French, Italian,
German
• 28492 AIR MATTRESS WITH BUBBLES
This air mattress is divided in bubble sections which inflate
and deflate alternatively latitudinally through the alternative
compressor. The continual movement given by the pressure
pumped inside is useful to prevent minor bedsore problems.
28482
• 28482 MASTER PUMP SYSTEM - with pressure adjustment
• 28483 KIT MASTER (AIR MATTRESS 28492 + MASTER PUMP 28482)
Made of stiff and strong ABS, it may be placed on the ground,
as it has rubber feet, or hung at the edge of the bed.
A control handle makes pressure regulation easier: air amount is
adjustable to suit patient weight from 40 to 120 kg.
The mattress should inflate totally in about 20 minutes.
Air output 2.5 l/min. Master pump can be used with bubble or
interchangeable section mattress.
Flame retardant PVC.
Master pressure pump
may be placed on the
ground or hung at the
edge of the bed.
• 28493 AIR MATTRESS - with interchangeable sections
It has 20 sections which can be inflated or deflated
alternatively. Easy and practical to use, it is ideal for patients
with minor bedsore problems.
Elements are jointed in-between and fixed to a PVC sheet.
• 28494 INTERCHANGEABLE CELL - spare for 28493
Press studs which attach each section to the supporting sheet
allow an easy exchange in case of damage.
• 28495 RINT PLUS AIR MATTRESS - interchangeable cells
Rint Plus Mattress is made of a strong and soft PVC, realized
with 17 big interchangeable bars. The integrated CPR function
(Cardio Pulmonary Reanimation) allows the immediate
emptying of the 17 bars. It is supplied with bi-elastic, liquid
proof and permeable to water-steam cover. Made in Italy.
• 28498 RINT PLUS PUMP SYSTEM - with pressure adjustment
Same as Master pump but with special valve for use with Rint
Plus Mattress.
• 28496 INTERCHANGEABLE CELL -
spare for 28495
• 28497 COVER - spare for 28495
Patient Weight
50 kg - 110 lbs
50-80 kg - 110-176 lbs
80-150 kg - 176-330 lbs
Pressure
40 mm/Hg
70 mm/Hg
100 mm/Hg
• 28499 WATER MATTRESS
It is made in PVC with a stabilising inflatable external structure to
prevent excessive water "wave motion" and of 3 independent units.
The water mattress distributes the total pressure on the whole
supporting surface, making this less than the average arterial
pressure, avoiding the exposure of the skin to pressure risk.
Easy to use, it is placed over the usual mattress and it
is washable. It is sold with a manual pump,
2 disinfectants and an inflation tube.
Size: 190x85 cm. Weight 4 kg. PVC thickness 0,4 mm
28492
28493
TECHNICAL SPECIFICATIONS MATTRESSES
28492
190x85 cm
160x85 cm
3 Kg
0.4 mm
-
80/90 kg
28493
190x85 cm
160x85 cm
5.2 Kg
0.4 mm
20
100 kg
28495
200x90x10.5 cm
170x90 cm
5.5 Kg
0.4 mm
17
120 kg
Total size:
Inflatable size:
Weight:
PVC thickness:
Number of elements:
Suitable for persons up to:
Low noise, long
lasting pump made
with high quality
materials
Thanks to height of cells,
Rint Plus can be used also with medium risk patients.
28499
PVC rigid edge
inflatable with air
Each water section measures
60x70 cm
ANTI-DECUBITUS AIR MATTRESSES TO PREVENT SORES
MADE IN ITALY
0.4 mm PVC THICKNESS
28495
28498
