FURNITURE
118
44706
LED ULTRA SLIM X-RAY ILLUMINATORS
- DESKTOP AND WALL
TECHNICAL SPECIFICATIONS
Colour temperature: Cool white 7,200°K
Brightness: 3,500 cd/m
2
Power supply: 230 V - 50/60 Hz
LED life: 80,000 hours
Conformity to Low Voltage Directive 2006/95/CE
Conformity to Electro Magnetic compatibility 2004/108/CE
Conformity to EEC directive 2007/47 medical Device Class I
All components UL, DVE, IMQ approved
Made in Italy
PANELS ADJUSTMENT
Panel rotation
Horizontal rotation 270°
Horizontal rotation 10°
Horizontal rotation 10°
Inclination
Adjustable
forward/backward
height
LED ULTRA SLIM OPTOMETRIC CHARTS
New generation of optometric charts with same specifications
as above X-ray illuminators. Made in Italy.
GIMA
code
LED ULTRA SLIM OPTOMETRIC CHARTS - WALL
Viewing area
External size
44710
Armagnac - 5 m 25.5x63 cm 34x72x4 cm
44711
Monoyer - 3 m 25.5x63 cm 34x72x4 cm
44712
Mixed decimal - 3m 25.5x63 cm 34x72x4 cm
44713
Children - 3 m 25.5x63 cm 34x72x4 cm
GIMA
code
DESKTOP LED SLIM VIEWERS
viewing area
External size Weight
kg
Switches
Types
Length Height Depth
44705
Light box 42x36 cm x1
46x1 50.5 3 6
1
1 panel
44706
Light box 42x36 cm x2
46x2 50.5 3 20
2
2 panels
44707
Light box 42x36 cm x3
46x3 50.5 3 26
3
3 panels
LED TECHNOLOGY SLIM X-RAY ILLUMINATORS
The new generation of LED X-ray illuminators with
colour temperature of 7,200°K for superior viewing
and reading of radiography.
Complete elimination of light flickering and 3,500
cd/mq luminance for more uniform light diffusion.
Frame in antiscratch anodized aluminium.
Film gripping system incorporated.
Dimmer for luminance adjustment from 30% to 100%.
- FAS: automatic switching on/off at the positioning/
removal of the film.
Economic advantages:
- LED life 80,000 hours, with low maintenance costs
- low energy consumption compliant with European law
Double support for horizontal or vertical wall
mounting or desktop.
Fully adjustable desktop model:
Position of panel can be totally adjusted:
- height adjustment 13 cm
- inclination 35° (+25°/-5°)
- vertical or horizontal positioning (44705 only)
- horizontal rotation 10° (270° for 44705 only)
d
e
p
t
h
:
9
c
e
n
t
i
m
e
t
r
e
s
l
e
s
s
t
h
a
n
s
t
a
n
d
a
r
d
m
o
d
e
l
s
Standard
Slim
3 cm
12 cm
GIMA
code
WALL LED SLIM VIEWERS
viewing area
External size Weight
kg
Switches
Types
Length Height Depth
44700
Light box 42x36 cm
46 50.5 3 4
1
1 panel
44701
Light box 42x72 cm
82 50.5 3 8
1
2 panels
44702
Light box 42x108 cm
118 50.5 3 12
1
3 panels
44703
Light box 42x144 cm
154 50.5 3 16
1
4 panels
80,000 HOURS
LED LIFE
44702
44701
44703
44700
44705
44707
44710
44711
44712
44713
LED ULTRA SLIM
OPTOMETRIC CHARTS
