ELECTROMEDICAL DEVICES
122
• 28310 GIMA UT AUTOMATIC
ultrasound therapy unit without head
GIMA UT is an automatic system for ultrasound therapy which
makes possible the use of ultrasound head with oscillation
frequency from 1 MHz to 3 MHz.
• 28301 GIMA UTC 2 AUTOMATIC
UTC 2 is a programmable driver unit for ultrasound transducers
with working frequencies from 1 up to 3 MHz together with
2 channels of electrotherapeutic current. UTC 2 delivers
continuous or modulated ultrasound with programmable
intensity and delivery time, suitable for thermo therapeutic
deep treatment of different pathologic conditions. UTC 2
transducer handpieces can be used under water. UTC 2 delivers
Dyadinamic, Faradic, Galvanic, Impulsive, T.E.N.S. and Bipolar
electrotherapeutical currents.
- high brightness graphic touchscreen display
- intuitive icons interface
- controls of unit by multifunction knob, keys or touchscreen
- possibility to upgrade
- wide range of preset protocols
- customized programmes
- multi frequency handpieces
- automatic identification of the connected accessory
- continuous or pulsed delivery
- combined with electrotherapy
- sequence of treatment phases planning for each channel
- independent channels
- safety control blocks the output current in case of accidental
disconnection of electrodes.
6 language software: GB, FR, IT, ES, DE, PT. Made in Italy.
• 28302 1-3 MHz ULTRASOUND HEAD Ø 15 mm
• 28303 CONNECTING CABLE for electrotherapy - spare
• 28304 CLIP RUBBER ELECTRODES 120x80 mm - box of 12
• 28305 CLIP RUBBER ELECTRODES 45x60 mm - box of 12
• 28323 VELCRO ELASTIC BAND 100x8 cm - spare
• 28312 1 MHz ULTRASOUND HEAD Ø 60 mm
1 MHz frequency is recommended for physiotherapy.
• 28313 3 MHz ULTRASOUND HEAD Ø 60 mm
3 MHz frequency is recommended for aesthetics.
Timer for treatment
time selection
Output for 1 or 3 MHz
ultrasound head
Switch for selection of pulse mode:
continuous or percentage pulsed
Power intensity knob
Output power
digital display
0051
28310
On/Off
switch
TECHNICAL SPECIFICATIONS
Treatment time: programmable from 1 to 30 minutes
Selectable pulse/time%: 10%-20%-30%-50%-100%
Pulse frequency: 2 pulses/second
Max. intensity: 3 W/cm
2
Operating voltage: 115/230 V - 50/60 Hz - switchable
Size: 360x265x150 mm Weight: 8 kg
Electrical safety class I BF - 93/42/EEC
Norms: EN 60601-1/IEC 601-2-5, EN 60601-2-5
Pulse frequency is 2 pulses/second. Modulation degree is
selectable from 10% to 100%, through a digital keyboard.
It is provided with digital adjustment of intensity with numeric
indication. Maximum output power is: 37.7 W (3 W/cm
2
).
Luminous read-out for distributed power.
Gima UT is recommended for: ultrasound lipoclasia, sports
medicine, arthritis, arthrosis, neuralgia and backpain.
Supplied with power cord and user’s manual.
Made in Italy.
GIMA UT AUTOMATIC: ULTRASOUND THERAPY UNIT
GIMA UTC 2:
COMBINED ULTRASOUND AND ELECTROTHERAPY UNIT
28312
TECHNICAL SPECIFICATIONS
Output frequency (MHz):
1.0 to 3.0
Max intensity (W/cmq):
3.0
ET channels:
2
Max output direct current (mA) 30
Max output pulse current (mA) 70
Max output voltage (Vdc)
100
Power supply (Vac/Hz)
90-240 / 50-60
Electrical input power (VA)
70
STANDARD ACCESSORIES
1-3 MHz ultrasound head Ø 35 mm
Connecting cable for electrotherapy 1-2 (28303)
4 rubber electrodes 120x80 mm
4 rubber electrodes 45x60 mm
3 velcro elastic belt: 8x40, 8x60, 8x100 cm
Power cable 2 m
28301
28301
28303
Connecting cable for electrotherapy
Standard 1-3 MHz ultrasound
head Ø 35 mm
