ELECTROMEDICAL DEVICES
126
WIRELESS MINITENS
• 28345 MINITENS - pain-relieving patch
• 28346 SPARE PATCH ELECTRODE 62x53 mm
A new innovative concept: simple, effective and always available.
First electronic pain-relieving patch resulting from combination
of modern cellular electrophysiological knowledge and
an ancient physical technique: acupuncture. A powerful
microprocessor and a performant stimulation programme allows:
- recovery of electrical exchanges on either side of the cellular
membrane and of block of the pain sensation conveyance to the brain
- relax and boost of the activity of nerves, muscles, tendons and joints.
The form of the electrical stimulations is physiological, it
relieves pain quickly, deeply and naturally.
25
mm
MINITENS is attached to an
interchangeable self adhesive
electrode, called "patch"
Button
- to turn power ON
- to increase stimulation
intensity (+)
Can be used on children
from age of 5
Button
- to turn power OFF
- to decrease stimulation
intensity (-)
3V battery CR2032 compartment
(under the cover)
Main body of device
55 mm
0434
MIO IONOTENS,
2 CHANNELS
MIO-VEIN -
CALF STIMULATOR
• 28380 MIO-IONOTENS 37 programmes
New 2 channel stimulator for the customers who need
an easy to use device with high output power and a complete list of
TENS programmes, rehabilitation programmes and free memories.
Portable and easy to use device with backlit display and digital
keyboard. It is equipped with internal rechargeable battery (long-
lasting) and belt clip. MIO-IONOTENS has 14 TENS programmes, 10
rehabilitation programmes including 3 ionophoresis treatments
and 13 free memories (adjustable frequency, width impulse and
time). Supplied in a carrying bag, with 2 cables, ionophoresis kit,
1 set of 4 pre-gelled electrodes (41x41 mm), 1 set of 4 pre-gelled
electrodes (40x80 mm), belt clip, internal rechargeable battery,
battery charger, user manual (GB, FR, IT, ES).
• 28381 IONOPHORESIS KIT - spare
(1 elastic band, 2 silicone conductive electrodes, 2 sponges)
• 28382 I-TECH PHYSIO PROFESSIONAL STIMULATOR
Professional stimulator with 2 indipendent channels
- compensated biphasic square wave: current quantity from
positive pole to negative one is constant to avoid hazardous
thermal effect of polarization
- monophasic square wave
- incontinence and ionophoresis programmes
- denervated treatment
- programmable TENS - EMS memories
- adjustable frequency, width impulse, time, ramp
- remaining therapy time and programmes instructions shown
on the LCD
- internal rechargeable battery pack (removable)
- maximum intensity 200 mApp;
• 28381 IONOPHORESIS KIT (2 silicone conductive electrodes,
2 sponges, 1 elastic belt)
• 28372 GELLED ELECTRODES 46x47 mm - bag of 4
• 28373 GELLED ELECTRODES 48x80 mm - bag of 4
• 28378 MIO-VEIN CALF STIMULATOR
2 channels FES device (Functional Electrical Stimulation) to stimulate calf muscles and help the
correct venous circulation. Its stimulation reactivates calf muscular pump that is mainly responsible
of venous return. Calf muscles contraction promotes the compression of superficial and deep veins.
As a consequence blood reaches the heart more easily. Mio-Vein can be used not only to help the
natural blood flow but also to prevent venous insufficiency and deep vein thrombosis. Moreover
it can be used in presence of lower limb edemas, venous ulcers and venous diseases. It is an
important support to compressive stocking therapy and finally to venous stasis treatment.
Main features:
- two independent channels for the connection of 4 electrodes
- easy to use digital keyboard
- adjustable intensity
- on-line guide on display for fast instructions
- reflective LCD display
- FES specific programme for venous stimulation
- operating with internal rechargeable battery
- 60 mA maximum intensity
- width impulse 30-240 μs
Supplied with 2 connections cables, 4 oval electrodes for calf,
belt clip, Ni-Mh rechargeable battery, battery charger, user
manual (GB, FR, IT, ES), carrying bag.
• 28379 OVAL ELECTRODES - set of 2 - 130x76 mm
0476
0476
Dimensions:
114x68x26 mm
28378
28380
Backlit display
I-TECH PHYSIO PROFESSIONAL
2 CHANNELS STIMULATOR
Supplied a carrying bag with:
- rechargeable battery and battery charger
- 1 set of 4 pregelled electrodes 48x48 mm
- 1 set of 4 pregelled electrodes 50x90 mm
- 2 silicon conductive electrodes 60x90 mm
- 2 sponges 70x100 mm
- 1 elastic belt for electrodes fastening
- 2 cables, 2 mm connection male plug
- 4 cable splitter 2 mm male and female plug
User manual (GB, IT, ES)
Digital
easy
to use
keyboard
PROGRAMMES:
20 NEMS
14 TENS
15 BEAUTY
9 UROLOGY
27 REHABILITATION 13 FREE MEMORIES
0476
