ELECTROMEDICAL DEVICES
124
• 28308 STIM BASE PLUS - 12 programs - 2 channels
Bipolar pulsing, square-wave current generator for muscle toning
and stimulation as well as pain relief. Stim base is microprocessor
controlled, with 2 output channels and 12 pre-set programs (5
sporting, 4 aesthetic and 3 rehabilitative). Sporting programs
deliver balanced stimulation to single flexion-extension muscle
actions. In aesthetic treatments the system uses the properties
of the applied DC current to induce vasodilatation, lymphatic
drainage, microcirculation renewal and toning with selective
modeling. Therapy programs allow resolution of muscles micro
trauma. Supplied in ABS case with all standard accessories
shown in this picture.
• 28317 KIT OF 4 ELECTRODES - spare - 4.5x8 cm
28308
0051
• 28306 IONO BASE - PLUS - 2 channels
Local administration of medicines by Ionophoretics, electric osmosis
and treatment of hyper hydrosis (sweating disease) and cellulitis.
Current generator for hydro galvanization, aesthetic shaping and
against cellulitis slight blemish. Microprocessor controlled, with
selection of parameters and internal programs it is characterized by
its simplicity and safety of use, although it maintains characteristics
of a professional equipment. Complete kit of accessories for
treatment (see photo). It comes with ABS case and velcro elastic
bands, rubber conductive electrodes 80x120mm and 50x50mm and
envelopes sponges for electrodes. Made in Italy.
• 28335 RUBBER ELECTRODES 50x50 mm - box of 10
• 28336 SPONGE BAGS for electrodes 50x50 mm - box of 10
IONO BASE PLUS
- GALVANIC IONOPHORESIS
MT BASE: MAGNETOTHERAPY
0051
28306
12-PROGRAMDIGITALSTIMULATOR
-forAESTHETIC,REHABILITATIONandSPORT
• 28321 GIMA MT BASE PLUS - magnetotherapy
Magneto Base Plus + is an ELF low frequency magnetotherapic
unit designed for domiciliary applications.
The most important effects of the magnetic fields are:
Antiedemigen / Analgesic / Antiphlogistic / Regenerative and
have applications in: traumatology, rheumatology, angiology,
neurology, dermatology, endocrinology.
The magnetic field produced is impulsive.
The internal generator produces square waveform electrical
current with frequency varying from 10 to 99 Hz and impulse
time varying so to obtain a field's intensity determinated from
10 to 80 Gauss.
Internal sound sensor of magnetic field and safety system in
case of short-circuit.
Two transducers can be connected at the same time (the field
produced by each transducer is half of the total).
It is supplied with all
accessories in a plastic case.
TECHNICAL SPECIFICATIONS
Waveform: square
Max. ratio emission/pause: 50%
Selectable magnetic field from 10 to 80 Gauss
Selectable frequency: from 10 to 99 Hz
Intensity of magnetic field: 80 Gauss (8mT)
Operating voltage: 230V/50-60 Hz
Size: 193x138xh 68 mm Weight: 1 kg
Safety class: II BF - Norms: EN60601-1 (CEI)
STANDARD ACCESSORIES
GIMA MT base unit
power cable
2 plate transducers 80 gauss - 120x70 mm
1 velcro elastic band 60xh 8 cm
Plate transducer 70x120 mm
1 pc.
Velcro elastic band 100x8 cm
1 pc.
28322
28323
1 velcro elastic band 100xh 8 cm
ABS carrying case
Manual (English, Italian)
28321
GIMA
code
ACCESSORIES FOR MAGNETOTHERAPY
Minimum
order
TECHNICAL SPECIFICATIONS
Size: 138 x 68 x 193 mm
Operating Voltage: 230 V - 50/60 Hz
Absorbed Max Power: 10 VA
Max Output Current: 20 mA
Safety class: II BF - 93/42/EEC. Made in Italy.
TECHNICAL SPECIFICATIONS
Size: 138x68x193 mm
Operating Voltage: 230 V - 50/60 Hz
Absorbed Max Power: 10 VA
Max Output Current: 60 mA
Safety class: II BF - 93/42/EEC. Made in Italy.
0051
