FURNITURE
119
PODOLOGY CHAIRS
GAMMA/PODOLOGICAL CABINETS
• 28025 ELECTRIC PODOLOGY CHAIR - 3 motors - blue
Electrically controlled chair to independently adjust height,
backrest and footrests, by foot switch.
Head rest can be inclined, arm rests are movable.
Operating power: 220-240 V - 50/60 Hz.
Size: 186x56x58/89 cm
Maximum load: 170 kg
Weight: 83 kg
Gross weight: 96 kg
• 45232 STOOL - blue
• 45242 STOOL WITH BACKREST - blue
• 28030 GAMMA1 CABINET - 61x45xh 77 cm - small
• 28031 GAMMA3 CABINET - 108x45xh 77 cm - large
Practical service cabinet, equipped with tabletop in scratch-
resistant wood, drawers and doors, specifically designed to
keep tools and accessories sterile.
The base is provided with castors to facilitate movement and
ensure maximum ergonomics.
The cabinet is supplied with connections to the mains:
germicide compartment, lampholder and other electric sockets.
Power supply: 220 V - 50/60 Hz.
Made in Italy.
• 28020 PODOLOGY CHAIR - mechanical - white
This chair can move up and down and rotate.
Backrest and footrests are adjustable.
Heavy round base provides maximum stability.
Size: 170x57x54/68 cm
Maximum load: 170 kg
Weight: 46 kg
• 45231 STOOL - white
• 45241 STOOL WITH BACKREST - white
STANDARD FEATURES
Satin steel handles
Germicide compartment with tempered glass frontal panel and automatic
switch off when opening
Large compartment with extractable shelf (for micromotor)
Lampholder support Ø 12.6 mm suitable for loupe LED lamp (30737)
1 socket for lampholder
1 inner socket for micromotor
Micromotor handpiece holder
4 (28030) or 3 (28031) sliding drawers
1 (28030) or 2 (28031) wide compartments with door
1 drawer for bottles
4 castors
SIZES
Cabinet
Table top
Germicide
Large
28030 28031 28030 28031 compartment compartment
Length: 61 cm 108 cm 61 cm 108 cm
28 cm
28 cm
Width: 45 cm 45 cm 42 cm 42 cm
38 cm
28 cm
Height: 77 cm 77 cm
4 cm
15 cm
Rotation
0°~90°
Angle
0°~90°
Control panel
Sliding drawers
Germicide compartment
Lamp holder
Sliding drawer with
front in tempered
glass, thickness
5 mm with U.V.
screen
Large compartment
for micromotor
Sliding ledge
Door on side
compartment
Up and down
54-68 cm
28020
Angle
Extension
Extension
up to 15 cm
Angle 0°~80°
Angle 0°~10°
Angle
0°~90°
Up and down
58-89 cm
Rotation 0°~240°
28025
28030
28031
Extension
Angle 50°~90°
45232
45241
