ELECTROMEDICAL DEVICES
128
• 28080 POCKET ULTRASONIC
NEBULIZER
• 28081 MEDICINE CUPS - box of 50
• 28082 RESPIRATORY ACCESSORY
KIT (adult and pediatric mask,
mouthpiece, flex tube)
Small, handy, light weight, portable
nebulizer, that
can operate with
standard AA batteries
(conventional
or rechargeable) instead of expensive
dedicated rechargeable batteries or
AC adaptor 100-240 V. Two adjustable
nebulization rate. Provides optimal
treatment for all kinds of medication
with different density. Supplied in a
nylon carrying bag with AC adapter
adult and child mask, mouthpiece 10
medicine cups, and transformer.
28106
28117
28113
28115
28114
28121
28122
0476
ULTRASONIC NEBULIZERS
Thanks to the innovative electronic technologies these easy-
to-use ultrasonic nebulizers provide a quiet, fast and portable
operation with optimal particle size.
Portable:
small and lightweight, it allows patients to perform
treatments anytime and anywhere.
Optimal particle size:
particle size determines the extent to
which the medication can be inhaled by the patient into the
deep lung tissue.
Approx 90% of particles generated by Family or Pingoo have
the optimal 1-5μ (microns) size.
Fast treatment:
with its high-efficiency design,
it allows a quick treatment time, most within 6 minutes, with
limited power consumption.
Low noise level:
treatments are
not only fast but are
virtually silent due to
its advanced ultrasonic
technology.
8 languages user
manual: English,
French, German,
Italian, Spanish,
Portuguese, Greek and
Arabic.
STANDARD ACCESSORIES
Adult facemask (only Family)
Pediatric facemask
Nasal prong, Mouthpiece
Connection tube
Medication cups
Transformer (220-240V-12V DC)
Carriyng bag
User manual
Optional battery
Family ultrasonic nebulizer
Pingoo ultrasonic nebulizer
Re-chargeable battery Ni Cd 12 VDC - Family
Re-chargeable battery Ni Cd 12 VDC - Pingoo
Spare Kit: includes adult and paediatric facemask,
nasal prong, mouthpiece and tube
Medication cups Family (box of 15 pcs.)
Medication cups Pingoo (box of 15 pcs.)
POCKET ULTRASONIC NEB HOMECARE
ULTRASONIC NEB
TECHNICAL SPECIFICATIONS
Operating voltage: 230 V-50 Hz
Power consumption: ≤ 30 VA
Medication cups capacity: ≤ 10 ml
Nebulization rate: 3 speed adjustable 0.3-0.6 ml/min
0.6-0.9 ml/min
0.9-1.2 ml/min
Particle size: 3-5 μ (microns)
Ultrasonic frequency: 2.5 MHz±100Khz
Size: 220x110x205 mm - 1.3 Kg
• 28085 HOMECARE ULTRASONIC NEBULIZER
• 28086 MEDICINE CUPS - box of 50
• 28082 RESPIRATORY ACCESSORY KIT
(adult and pediatric mask,
mouthpiece, flex tube)
Desktop ultrasonic nebulizer
for homecare. Supplied
with flexible nose,
adult and child mask,
mouthpiece and 10
medicine cups.
-
3-speed nebulization
rate control
- provides
optimal treatment for all
kinds of medication with
different density.
- Specialized design
-
with swivel air outlet to
suit all kinds of treatment.
STANDARD AA
BATTERY OPERATED
115
mm
65 mm
43
mm
0476
0476
28106
GIMA
code
ULTRASONIC NEBULIZERS
28117
FAMILY AND PINGOO ULTRASONIC NEBULIZERS
28106
Size 22x50x132 mm
Weight 250 g
28085
28080
TECHNICAL SPECIFICATIONS
Operating voltage: DC 6 V (4xAA alkaline batteries)
AC adaptor: input: 100-240 V - 50/60 Hz AC/Output: 12 V / 700 mAh
Rechargeable battery: 4xAA NiMH rechargeable batteries / 2000 mAh (90 minutes)
Ultrasonic Frequency: 2.5 mHz
Medication cups capacity: ≤ 6 ml
Nebulization rate: 2 speed adjustable
- 1st level - 0.3 ml/min - 2nd level - 0.5 ml/min
Particle size: 3-5 μ (microns)
Treatment time: 5-6 min (2-3 ml)
Sound level: ≤ 50 db
TECHNICAL SPECIFICATIONS
Operating voltage: 220-240 V 50/60 Hz Power: 10 W
Ultrasonic frequency: 2.5 MHz
Nebulization time: 0.2-0.7 ml/min depending on medication density
Medication cups capacity: max 8 ml Family, max 4.5 ml Pingoo
Automatic switch-off
Particle size: 5 μ (microns) average
Three programmable flow levels
Noise level: <40 dB
28114
