ELECTROMEDICAL DEVICES
120
3 compression modes
TECHNICAL SPECIFICATIONS
DOCTOR LIFE AIR COMPRESSION THERAPY SOLUTIONS
All human body is supplied
by peripheral circulation of
blood and lymph
Doctor Life system helps
patients to recover from their
disease by improving blood
and lymph circulation and
metabolism
Doctor Life system consists
of air chambers and an
air pump offering air
compression massage to legs,
arms or waist.
SEMIPROFESSIONAL MODEL (Home-Hospital)
• 28450 DL850 PROFESSIONAL SYSTEM with 2 legs (102x35 cm),
1 arm - 6 chambers (87x25 cm), double hose and cable
This system can operate with 8 compression modes.
Every chamber can have a different pressure or can work only
with 1 selected chamber. Graphic LCD display. Inflation and
interval time control by two separate keys.
- pressure sensor
- digital timer (10, 20, 30, 40 min)
- digital pressure gauge (10~180 mmHg)
TECHNICAL SPECIFICATIONS
- Pressure sensor
- Use time: 0~90 minutes
- Hold time: 0~6 seconds
- Interval time: 0~19 seconds
- Body size: 370x390x190 mm
- Body weight: 13 kg
- one touch connection hose plug
- body size: 190x250x210 mm
- body weight: 3 kg
28430
Medical indications
• DVT (Deep Vein Thrombosis)
• Lymph edema
• Post-paralytic
• Limb convulsion
• Venosclerosis
• Chronic venous insufficiency (CVI)
• Post-mastectomy
• Post-trauma
• Spinal cord injury
• Varicose veins
• Sciatica
• Sprains
• Diabetes
• Cellulite
Home care indications
• Lymph edema
• Diseases caused by interrupted blood
circulation
• Fat dissolution
• Pregnant woman's limb treatment
• Benumbed feet or hands
• Cold feet or hands
• Settlement of stress
• Exercise effects
• Insomnia
• Healthier body and elastic skin
• 28453 LEG CUFF 92x31 cm
• 28458 DOUBLE HOSE - to use two leg cuffs at the same time - spare
• 28459 LEG EXTENSION ZIPPER - 10 cm extra extension
• 28454 ARM CUFF - 6 CHAMBER 87x25 cm - spare
• 28455 WAIST CUFF 128x51 cm
HIGH CLASS PROFESSIONAL MODEL
D
rainage,
C
irculation &
M
assage
Possibility to use 2 leg cuffs
in the same time with double
hose (code 28440)
You can use
contemporaney 2 leg cuffs.
For this function you need
double hose (code 28458)
• 28430 DL 2002 D BASIC with 2 legs (98x38 cm) - 4
chambers 1 single and 1 double hose and cable
This system can operate with 3 compression modes.
• 28435 LEG 93x32 cm
• 28434 LEG EXTENSION ZIPPER - 10 cm extra extension
• 28440 DOUBLE HOSE - to use two leg cuffs at the same
time - spare
• 28436 ARM CUFF unique size - 86x29 cm
• 28437 WAIST CUFF 130x38 cm
25 cm
102 cm
35 cm
87 cm
93 cm
Leg cuff (28435)
Standard arm (28454)
Standard leg (28453)
Arm cuff (28436)
32 cm
29 cm
86 cm
Universal cable included
is suitable for leg,
arm and waist cuff
Waist cuff 130x38 cm (28437)
