ELECTROMEDICAL DEVICES
123
• 28326 MAGNETOTHERAPHY PROFESSIONAL - unit only
• 28327 KIT: 1 BELT + 2 PLATE TRANSDUCER - 100 Gauss
• 28323 VELCRO ELASTIC BAND 100x8 cm - spare
• 28325 CYLINDER Ø 24 cm - 100 Gauss
• 28329 CYLINDER Ø 50 cm - 80 Gauss
• 28328 CYLINDER Ø 60 cm - 80 Gauss
MAGNETOMED is an ELF (Extremely Low Frequency)
magnetotherapeutic unit designed for professional
ambulatory or at patient home applications.
It is useful in the therapies that require treatment repetitions
for a long period and/or long duration, or therapies on
traumatized or immobilized patient that have difficulty to
reach an outpatient phisiotherapy room.
Applications:
The main effects of the ELF magnetic therapeutic fields are:
- antiaedemic, antalgic, antiflogistic, regenerative
Main fields of application are: traumatology, rheumatology,
angiology, neurology, dermatology, endocrinology.
MAGNETOTHERAPY UNITS
: DOMICILIARY AND PROFESSIONALMODELS
28326
Size: 360x265x150 h mm Weight: 6 kg
ELF magnetotherapy
features:
low frequency,
negligible electric field,
low radiated power,
negligible thermic effects,
high tissue penetration
0051
Kit: elastic band 100x8 cm
+ couple of plate transducer
TECHNICAL SPECIFICATIONS
Working frequencies: 2,5,10,20,30,40,50,60Hz
Intensity control: 20, 40, 60, 80, 99%
Waveform:
rectangular
Time of treatment: 1-99 min
Active channels:
CH1 - CH2 - CH1+CH2
Operating Voltage: 115/230V
50/60 Hz switchable
Power:
220 VA
Norms: EN60601-1 (CEI) - 93/42 EEC
Plates and Cylinder
are not included
in standard
configuration.
• 28338 T-ONE EVO II ELECTROTHERAPY - 4 channels
101 programmes for over 300 applications
(pain, fitness, sport, beauty). T-ONE EVO II can generate
alternate impulses on its four channels to produce sequential stimulations or contractions. In this way
T-ONE EVO II stimulates kinetic chains for re-educational purpose, and can also be used in fitness
training. The high power of T-ONE EVO II can satisfy both the home users and the sportmen.
Main features:
- 4 independent channels for the connections of 8 electrodes
- constant current generator (can guarantee a constant current even when skin condition
changes, the device automatically stops in the event of accidental electrodes disconnection)
- compensated biphasic square wave: avoids hazardous thermic effect of polarization
- user feedback: T-ONE recognizes patient connection
- soft-touch easy to use keyboard
- on-line guide on display for fast instructions
- internal Ni-Mh rechargeable battery pack (1600 mAh)
- different treatments for man and woman
- maximum intensity 240 mA with 0.5 mA step regulation
- 5 languages menu (GB, FR, IT, DE ES) and 3 languages manual
(GB, FR, IT) ES manual on request
- compliance with 93/42/EEC MDD (medical device CE0476).
Tens rapid
Tens endorphinic
Tens sequential
Tens maximum value
Tens Burst
Cervical pain
Lumbal pain
Sciatalgy
Distorsion Contusion
Inflammatory
Vascularization
Decontraction
Hematoma
Regenerating skin
Atrophy prevention
Atrophy
16 Tens Programmes
11 Sport Programmes
9 Beauty Programmes
Lipolysis*
Refirming*
Tonification*
Definition*
Limbs modelling*
Microlifting
Relaxing massage
General recovery
Drain-up
Warm up*
Recovery*
Capillarization
Competitive/Counteractive*
Long effort*
Basic strength*
Speed*
Explosiveness*
Endurance
Tonic contractions
Phasic contractions
T-ONE EVO II
- 4 CHANNEL ALTERNATE CURRENT ELECTROTHERAPY
* These programmes allow 6 different modes: upper limbs, torso, lower limbs, for man and woman
Back light
display
Size: 76x125x34 mm
• 28300 MAG 2000 MAGNETOTHERAPY - 2 channels
MAG 2000 is an ideal device for domiciliary and professional magnetotherapy.
Two channels 150 gauss each to easily treat different body parts through
the highly appreciated elastic therapeutic belt with 3 solenoids.
35 programmes:
20 pre-set programmes for the treatment of several
pathologies, 14 programmes identified by the working frequency (from
1 to 100 Hertz) and an Autoscan programme with continuous frequency
variation for the treatment
of both hard and soft tissues
at the same time. MAG 2000
has the possibility to set the
intensity of magnetic field for all
the programmes up to
300 Gauss on 2
channels
(150 Gauss for single channel).
Operating power 110-240 V.
Supplied with elastic therapeutic belt with 3
solenoids and bag.
MAG 2000
LOW FREQUENCY, HIGH INTENSITY MAGNETOTHERAPY
Osteoporosis
Arthrosis
Arthritis
Cervical arthrosis
Articular Pain
Cervicalgias
Sprains
Fractures
Epicondylitis
Epitrocleitis
20 pre-set programmes
14 working freq.+autoscan
Intercostal Contusion
Lumbalgy
Lumbar pain
Shoulder arthrosis
Knee arthrosis
Periarthritis
Coxarthrosis
Muscular Atrophy
Muscular contracture
Osteonecrosis
1 Hz
3 Hz
5 Hz
10 Hz
15 Hz
20 Hz
30 Hz
40 Hz
50 Hz
60 Hz
70 Hz
80 Hz
90 Hz
100 Hz
Autoscan
-
-
-
-
-
28300
35 PROGRAMMES
28327
0476
STANDARD ACCESSORIES
4 connection cables (8 electrodes)
user manual (GB, FR, IT) and electrodes positions manual
5 electrodes packages
internal Ni-Mh rechargeable battery pack and battery charger carrying bag
