VETERINARY
315
• 33305 VE-100 - 1 channel ECG
• 33306 VE-300 - 3 channel ECG
• 33336 ECG-Viewer software (GB, IT, FR, ES, RU, PT, PL, TU) for 33306
- complete digital design
- LCD display waveforms, parameter configuration
- high resolution thermal printer
- built in rechargeable Li-ION battery for 3 hours use (AC/DC
supply)
- complete digital filter, avoid baseline drift, AC, EMG interfere
- baseline automatically adjustable, optimizes printing position
- selectable auto/manual operation
Features of VE-300 only
- 7 leads simultaneous acquisition
- automatic ECG parameter measu-
rement and analysis
- support USB ink-jet printer for 7
leads printing
- 120 patient data storage and
transfer by USB flash disk, Ethernet
or series port
- review and management of ECG
data on Window PC with software
(optional 33336)
Internal software: GB, IT (33305/6), DE, FR, ES (33305 only)
• 32963 THERMAL PAPER ROLL 50mm x 25m for 33305
• 32964 THERMAL PAPER ROLL 80mm x 25m for 33306
• 33318 RE-CHARGEABLE LITHIUM BATTERY 2200 mAh
• 33319 5-LEAD VETERINARY ECG CABLE - spare
• 80600 GIMA VET DOPPLER - FIXED 8 MHz probe
New doppler for detecting blood flow in small peripheral ves-
sels with its unique 8 MHz probe ideal for veterinary practitio-
ners for routine blood pressure measurement on pets.
Flow signals are easily located using the lightweight narrow
beam transducer while internal signal processing minimizes
noise artefacts.
• 25588 VET RECTAL
THERMOMETER
Designed to be
ergonomically correct for
animals. Setting for pets, pigs,
cattle and other animals.
• 32545 REGALITE VET - black
Top quality single head stethoscope.
Patented multi-frequency "ring-o-
raised™" diaphragm system. Chromed
plated chestpiece with "SUPERFLEX"
inner spring binaural and 1 piece
moulded PVC, latex free, tubing 90 cm
long. Supplied in deluxe box, with
spare soft eartips and one spare
diaphragm.
TECHNICAL SPECIFICATIONS
Measurement range: 32 ~ 43 °C
Accuracy: ± 0.1 °C (35 ~ 39 °C);
± 0.2 °C (<35 °C~ >39 °C)
Battery life is approximately 5000 readouts
Dimension: 190x110x35 mm
32545
90 CM
LONG Y TUBE
80007
80000
80001
THERMOMETER
VETSTETHOSCOPE
VETERINARY DOPPLER
INSTRUMENTS
80000
Durante forceps - 15 cm
80001
Terza palpebra forceps - 11 cm
80002
Long Hartmann - 14.5 cm
80005
Mouth opener - 7 cm
80006
Mouth opener - 11 cm
80007
Mouth opener - 15 cm
80010
Rodent mouth opener - 6 cm
80011
Rodent mouth opener - 8.5 cm
33306
192x64 pixel LCD
VE-300 data transfer
TECHNICAL SPECIFICATIONS
33305
33306
Lead
standard 7 lead
Acquisition mode
single
7 leads simultaneously
Frequency response
0.05 Hz ~ 150 Hz
Sensitivity
2.5, 5, 10, 20 (mm/mV)
Input impedance
>10 MΩ
>50 MΩ
Filter
EMG Filter 35 Hz (-3dB)
EMG Filter 25/35/45Hz / OFF
AC/DFT Filter 50/60Hz (-20dB) DFT Filter 0.05/0.15/0.25/0.5 Hz
Low pass Fliter 150/100/75 Hz
AC Filter 50/60 Hz
Recording mode
Auto/Manual
Auto/Manual/Rhythm/OFF/USBPRT
Safety standard
IEC I/CF
Power supply
AC: 100-115-220-240 V, 50/60 Hz
Built-in rechargeable Li-ion battery: voltage=14.4 V
More than 3 hrs, continuously operation under battery supply
Thermal paper
5 mm x30 m
80 mm x20 m
Paper speed
25/50 mm/s (± 3%)
5/6.25/10/12.5/25/50 mm/s (± 3%)
Size
300x260x75 mm
Weight
2.3 kg (with battery)
2.5 kg (with battery)
Display
192x64 pixel LCD
192x64 pixel LCD
External input/output
Input: ≥100 kΩ; Sensitivity: 10 mm/V ± 5%
output: ≤100 kΩ; Sensitivity: 1 mm/V ± 5%
Communication interface RS232
Ethernet, RS232, USB
STANDARD ACCESSORIES
5-lead veterinary ECG cable (Ø 4mm, banana connector, IEC)
Veterinary clip electrodes (set of 5, match Ø 3-4 mm ECG cable)
1 Paper roll
Rechargeable lithium battery (2,200 mAh)
Manual: GB, IT - on request FR, ES, DE
TECHNICAL SPECIFICATIONS
Ultrasound
Frequency:
8 MHz continuous wave
Transducer: 2 crystal narrow beam
Output power:<15 mW/cm
2
SATA
Audio Response: 300 Hz - 4 kHz
Unit Controls
Keys:
1 key (for unit on/off)
Controls:
rotary volume
Indicators:
yellow battery low LED
Power supply
Battery 9V Alkaline (not included)
Expected battery life: >9 hours
Output
Headset: Audio output for optional
headset (not included)
Material: ABS / Noryl
Size:
150x75 mm
Weight: 299 g (with transducer)
Classification: Class I Type B - IEC 60601-I
VETERINARY ECG - 1 AND 3 CHANNEL
80010
TOP QUALITY:
MADE IN UK
3 YEARS
WARRANTY
80600
80002
