VETERINARY
314
• 33936 VETERINARY ECOGRAPH 10" SVGA monitor with two
probe connectors, cine memory card, without probes.
- image reversing: left/right, up/down, positive/negative
- zooming: X1.0, X1.2, X1.5, X2.0 with scroll-up depth control
- measurements: distance, circumference, area, volume
(bladder volume, thyroid volume), 15 body marks.
- reproduction software: Bovine: BPD, CRL, Trunk diameter,
Equine: GA, Canine: GS, CRL, HD, BD, Feline: HD, BD
Ovine: BPD, CRL, Trunk, Diameter
- power supply: 230V/50 Hz (110V/60 Hz on request)
• 33967 SONY PRINTER UP-897 MD
• 33994 ECO1 VET ULTRASOUND with 1 probe connector, without probe, 3 USB ports,
VGA port, video port.
• 33995 ECO 3 VET ULTRASOUND with 2 probe connectors, without probe, built in
rechargeable lithium ion battery (2 hours), 3 USB ports, VGA port, video port.
Display Modes:
B, B/B, 4B, M, B/M
Grey scale:
256 levels
Scanning depth:
240 mm max (depending on probe type) only 33994
Image Technology:
Compound Imaging, Trapezoid imaging, Chroma, i-image, THI,
SRA, (only 33995)
Cine Loop:
256 frames
Image Storage:
permanent storage on built-in memory, and USB disk (33994), 8G ( 33995)
Zoom:
4 steps
Software packages: Canine:
GS. CRL, HD, BD.
Feline:
HD,BD.
Equine:
GS,
Bovine:
BPD,CRL, Trunk Diameter.
Ovine:
BPD, CRL, Trunk Diameter.
Power Supply:
100-240V, 50Hz~ 60Hz
Manual: GB, IT, on request FR.
• 33997 MICROCONVEX 6.0 MHz (4.0-8.0 MHz) PROBE
• 33998 CONVEX 3.5 MHz (2.5-5.0 MHz) PROBE
• 33999 LINEAR 5.3-10.0 MHz PROBE
GIMA
code
PROBES
33932
33938
33939
Frequency (MHz)
Applications
Outlook
Scanning
Method
Main
freq.
4-Step
Multi-
frequency
Ob/Gyn
Abdominal
Cardiology
Convex
Linear
Rectal
Micro-
convex
3.5
5
5
2.5/3.5/4.0/5.0
3.5/5.0/6.0/7.0
3.5/5.0/6.0/7.0
Ovine
Canine
Equine
Bovine
Ovine
Feline
Canine
O
O
O
O
O
O O
O
Lightweight:
only 7 Kg
(size: 42x27x25 cm)
PORTABLE ULTRASOUND UNIT FOR VETERINARY APPLICATIONS
CHISON ECO 1 AND ECO 3 VET ULTRASOUNDS
CHISON SONOTOUCH -
THE FUTURE FOR VETERINARY ULTRASOUND
• 33912 SONOTOUCH VET B/W ULTRASOUND
• 33913 SONOTOUCH VET COLOUR
ULTRASOUND
10" LED touch screen - button free
- sharp and bright images visible
outdoor under sunlight
- waterproof front panel
Easy measurement
- VET software
- measurement accuracy to under 1 mm
- take measurements with your
fingers, no trackball, no stylus
Powerful
- built-in lithium battery lasts
up to 2.5 hours
- starts in 30 seconds, shuts
down in 2 seconds.
Many applications
- over 25 VET preset applications
- select species and presets by visual icon
Quality images
- refine the image with easy, touch-driven TGC, focus and depth
Small animals
Large animals
Multifunctional stand
- desk stand with adjustable angle
- stand convertible into an integrated carrying
handle
33922
33923
33927
GIMA
code
PROBES FREQUENCY (MHz)
Main application
Scanning
Method
Main
freq.
Probe
band
width
ABDOMINAL
OB/GYN
UROLOGY
CARDIOLOGY
INTESTINE
EQUINE
MSK, TENDON
CONVEX
LINEAR
MICRO-CONVEX
3.5
7.5
6.0
2.5 - 5.0
5.0 - 10.0
4.0 - 8.0
O O
O
O
O
O
O
33922
33923
33927
33995
